Sony 158WGC10A Quick Start Manual

4-454-824-12 (1)
Identifying the Parts
Portable Wireless Server

Quick Start Guide

Thank you for your purchase. This Quick Start Guide
is designed to easily get you set up so you can start
enjoying the benefits of the device.
Read this Quick Start Guide when using this unit with
a smartphone or tablet.
When using this unit with a computer, download
"Quick Start Guide for Computer users" from the
following web site.
http://www.sony.net/pws/
WG-C10 Series
© 2013 Sony Corporation Printed in China
Setting Procedure
Step1: Charging this Unit
Step2: Installing the App
Expressions in this Guide
Connecting by Wireless LAN for the First
WG-C10
Step3:
Time
Smartphone/tablet
Step4: Security Set-up
Lamp Indicator of this Unit
Step5: Reconnecting to the Wireless LAN
Battery indicator lamp
Charging indicator
Lamp condition
Examples of Use
Amber
Amber -> off
Wi-Fi Storage
Remaining battery level indicator in use
Wi-Fi
Lamp condition
connection
Green, blinking slowly Battery level is high
View &
Smartphone
Transfer Green, blinking
content
Memory card Red, blinking rapidly
Off
Transfer
USB memory
content
Tablet
WG-C10 Wireless LAN indicator lamp
Lamp condition
Green
Green, blinking
PC
Off
Battery Charger
Memory card access lamp
USB
Lamp condition
connection
Amber, blinking
Power feeding
Smartphone
WG-C10
USB Card Reader
USB
connection
Memory card
Transfer
content
PC
WG-C10
Step1: Charging this Unit
This unit has a built-in rechargeable battery pack.
Wireless LAN
Charge this unit before use.
indicator lamp
Charge this unit from a computer or with a USB AC
Battery indicator lamp
adaptor (sold separately).
(power) button
When charging from a computer
Connect this unit to your computer with the USB
Strap holder
cable (supplied).
RESET (reset) switch
Memory card slot
Memory card access lamp
USB A port
For charging a smartphone or
tablet
For connecting to a USB
memory or digital still camera
USB micro B port
For charging this unit
For connecting to a
computer
Approximate charging time: Approx. 8 hours
The MAC address and serial number shown
Charging underway:
on the label on the bottom of this unit may
be needed for various settings. Write them • Wireless LAN function cannot be used.
down in the below space.
• You can do up to Step2.
When charging with a USB AC adaptor
MAC address
(sold sepalately)*
Connect the USB cable (supplied) to this unit and
the USB AC adaptor (sold separately or the one
supplied with your device), and connect the USB AC
Serial number
adaptor to the wall outlet (wall socket).
Approximate charging time: Approx. 3.5 hours
(When using AC-UD10)
Approximate charging time varies depending on
the USB AC adaptor (sold separately) used.
This unit
Charging underway:
Device
• Can read and write data to a memory card via a
wireless LAN.
• USB devices connected to this unit cannot be
used.
• You can do from Step2 onward.
* A USB AC adaptor is not supplied with this unit.
For more information about USB AC adaptors that
Status
have been confirmed to work with this unit, see the
Charging underway
Help Guide (http://rd1.sony.net/help/pws/c10/
gb/).
Charging is complete
When charging is complete, the battery indicator
lamp turns off.
Status
When charging is complete, remove the USB cable.
Battery level is medium
Step2: Installing the App
Battery level is low
Battery runs out or power-off
To operate this unit, install PWS Manager onto your
device.
See the Help Guide (http://rd1.sony.net/help/pws/
Status
c10/gb/) for compatible operating systems and a
list of devices that have been confirmed to work
Wireless LAN is starting up
with this unit.
Wireless LAN is on
1
Power-off
Install the app.
Search for PWS Manager in
Google Play or the App Store
Status
and install it.
Accessing memory card
Note
The app is free. However, there may be a
communication fee for downloading.
After installing, tap [Complete] and the icon is
displayed.
After installing, the icon is displayed.
* iOS is the operating system of iPhone, iPad
After installing, go Step3 without launching the
app.
Step3: Connecting by Wireless
Connect this unit to your device by wireless LAN.
Do this setting after installing the PWS Manager
app.
Note
When this connection is made, the internet
connection of your device is disconnected. To
reconnect to the internet, see the Help Guide.
Battery indicator
lamp (amber) 1
Turn on the power.
During charging:
On
Press and hold down the
Charging
complete: Off
seconds or more).
USB cable (supplied)
When this unit's start-up
is complete, the green
wireless LAN indicator lamp
stops blinking and remains
lit.
2
From the setup menu of your device,
turn Wi-Fi on and open the Wi-Fi
Networks screen.
3
Tap this unit's SSID [WG-C10-XXXXXX]*
from the list of Wi-Fi networks to
connect.
* "xxxxxx" is the last 6 digits of the MAC
address.
The MAC address is shown on the back side
of this unit.
4
Confirm the connection.
Android
Connection is completed when "Connected"
is displayed under the selected SSID and
displayed at the top of the screen.
iOS
Connection is completed when there is a
tick to the left of the selected SSID and
displayed at the top of the screen.
This unit is now connected to your device by
wireless LAN.
PWS Manager
Android :
iOS *:
and iPod touch.
LAN for the First Time
(Power) button (for 3
Android iOS
Settings Wi-Fi
Wi-Fi
ABC123456
Wi-Fi ON
Secured with WPA (protected network
available)
Choose a Network...
WG-C10-XXXXXX
Secured with WPA2 ABC123456
BBBBBB WG-C10-XXXXXX
000000 BBBBBB
Secured with WPA2 (protected network
available)
000000
AAAAAA
Secured with WPA/WPA2 (protected AAAAAA
network available)
DEFGH789 DEFGH789
Secured with WPA/WPA2 (protected
network available) XXXXXX
XXXXXX
EEEEEE
Secured with WPA/WPA2 (protected
network available)
CCCCCC
Scan Add network
Android iOS
Wi-Fi
Wi-Fi Settings
ABC123456
Wi-Fi ON
Secured with WPA (protected network
available)
Choose a Network...
WG-C10-XXXXXX
Connected
ABC123456
BBBBBB WG-C10-XXXXXX
:
is
:
is
