IP Gateway Card

Getting Started

KX-TDA0480
Model No.
Thank you for purchasing the Panasonic Model KX-TDA0480, IP Gateway Card. Please read this manual before
installing the IP Gateway Card and save this manual for future reference.

Advertisement

Table of Contents
loading

Related Manuals for Panasonic KX-TDA0480

Summary of Contents for Panasonic KX-TDA0480

  • Page 1: Getting Started

    IP Gateway Card Getting Started KX-TDA0480 Model No. Thank you for purchasing the Panasonic Model KX-TDA0480, IP Gateway Card. Please read this manual before installing the IP Gateway Card and save this manual for future reference.

  • Page 2: Table Of Contents

    Table of Contents Overview ..................3 Example Network Diagramme ................4 Network Devices and Numbering Plan............... 5 1.2.1 Numbering Plan Example ................. 6 Physical Installation..............9 Installation......................10 2.1.1 Names and Locations ..................10 2.1.2 DIP Switch Settings ..................10 2.1.3 Installing the IP Gateway Card to the Hybrid IP-PBX ........11 2.1.4...

  • Page 3: Overview

    Gateway Card, will allow organisations to route both voice and fax communications over digital data networks. The KX-TDA0480, designed to be easily integrated into existing LAN/WAN environments, seamlessly bridges Public Switched Telephone Network (PSTN) and analogue telephone with digital data networks without interrupting or compromising ongoing data communications.

  • Page 4: Example Network Diagramme

    1.1 Example Network Diagramme Example Network Diagramme The following diagramme illustrates a simple VoIP network connecting Hybrid IP-PBXs at 2 different locations. The IP Gateway Card converts outgoing voice or fax signals into IP data packets for transmission. On the incoming side, it reverses this process and translates the packets back into appropriate voice or fax signals.

  • Page 5: Network Devices And Numbering Plan

    1.2 Network Devices and Numbering Plan Network Devices and Numbering Plan Once the installation of IP Gateway Cards begins, network configuration information needs to be on-hand. The following diagramme illustrates devices found in an IP network. Referring to this example, consult your network administrator to obtain necessary information to configure your own network.

  • Page 6: Numbering Plan Example

    1.2 Network Devices and Numbering Plan Notes • Recommended IP Networks: the IP Gateway Card's quality of performance depends on the type of network in use. For instance, transmission delays due to congestion on the network and inadequate service characteristics of Internet Service Provider (ISP) can both contribute to loss in voice communications.
  • Page 7 1.2 Network Devices and Numbering Plan PBX Numbering Information PBX numbering information is necessary to setup phone numbers for a VoIP network. Configure the numbers conforming to existing PBX numbering systems. Description Los Angels Chicago Office Office PBX Office A unique number (ranging from 1 to 8 digits) Code assigned to identify each Hybrid IP-PBX within a network.
  • Page 8 1.2 Network Devices and Numbering Plan Calling from Chicago to Los Angels To extension 201 via IP network Los Angels PBX IP trunk no. extension no. office code Dial 801. Dial 35. Dial 201. To local telephone 456-7890 via IP network through local PSTN Los Angels PBX Los Angels PBX IP trunk no.

  • Page 9: Physical Installation

    Section 2 Physical Installation Getting Started...

  • Page 10: Installation

    2.1 Installation Installation 2.1.1 Names and Locations Indication Lights LED1 LED8 IP Link Connector Serial (RS-232C) Connector 2.1.2 DIP Switch Settings The default DIP Switch settings are as illustrated below. Confirm that the switches are in the default positions before installing the IP Gateway Card. Dip Switch 1 2 3 4 5 6 7 8...

  • Page 11: Installing The Ip Gateway Card To The Hybrid Ip-Pbx

    2.1 Installation 2.1.3 Installing the IP Gateway Card to the Hybrid IP-PBX 1. Insert the card along the guide rails. Guide Rails 2. Holding the card as shown on the left, push the Back Board release lever in the direction of the arrow so that the card is made to engage with the connector on the back board securely.

  • Page 12: Indication Light (Led)

    2.1 Installation 2.1.4 Indication Light (LED) LED1 Green/Red Channel Status LED 1 Off: Power Off LED 2 Green Flash: Normal (channel used) Red On: During reset LED 3 Red Flash: Out of Service LED 4 LED 5 LED2 Green Online Status On: On-line mode LED 6 Flash: Emergency maintenance mode...

  • Page 13: Cable Connection

    2.2 Cable Connection Cable Connection 2.2.1 RS-232C Cable Connection To initialise a newly installed IP Gateway Card using the Maintenance Console Software (see 4.2 Creating New Group and Gateway), a computer or terminal must be connected directly to the unit using an RS-232C serial (cross) cable with DB9 Female to DB9 Female connectors. Turn the computer power OFF.
  • Page 14 2.2 Cable Connection Getting Started...

  • Page 15: Trunk Programming Of The Hybrid Ip-Pbx

    Section 3 Trunk Programming of the Hybrid IP-PBX Getting Started...

  • Page 16: Trunk Programming Of The Hybrid Ip-Pbx

    3.1 Trunk Programming of the Hybrid IP-PBX Trunk Programming of the Hybrid IP-PBX In order to assign Trunk Group Number to the IP trunk of the Hybrid IP-PBX, follow the procedure below. Note It is assumed that you have already installed the PC Programming Software in your PC. 1.
  • Page 17 3.1 Trunk Programming of the Hybrid IP-PBX 7. Enter CO Name (max. 20 characters) and Trunk Group Number (01-64) for the desired "Trunk (CO) Number", then click [OK] to enable the setting. 8. Select "Connect" "Disconnect" to end configuration. Getting Started...
  • Page 18 3.1 Trunk Programming of the Hybrid IP-PBX Getting Started...

  • Page 19: Logical Installation (Maintenance Console Software)

    Section 4 Logical Installation (Maintenance Console Software) This section describes the logical installation process involving the following operations: (1) create New Groups and Gateway units, (2) configure common DNS Data, (3) configure unit-specific Office Data, and (4) upload configuration files and reboot the units. Getting Started...

  • Page 20: The Maintenance Console Software (Mcs)

    4.1 The Maintenance Console Software (MCS) The Maintenance Console Software (MCS) MCS provides easy-to-use installation and management of the IP Gateway Card. This section describes the procedures to install and configure the IP Gateway Card for basic use. Use the MCS when installing the IP Gateway Card for the first time to establish the unit's new IP addressing through direct RS-232C link to the unit.

  • Page 21: Starting Mcs And Logging-In

    4.1 The Maintenance Console Software (MCS) 3. When the installation is complete, 3 icons will be created. 4.1.2 Starting MCS and Logging-in 1. Double-click "IVG MCS" icon. Initial screen appears. 2. Type mcs (default password), then click [OK] to log-in. To change the default password, see 4.1.5 Changing the Password.

  • Page 22: Serial Port Setting

    4.1 The Maintenance Console Software (MCS) 4.1.4 Serial Port Setting If a port other than COM 1 is used to connect the IP Gateway Card and the computer, the MCS serial communications parameter must be reconfigured. 1. Select "Tools" "Options". 2.

  • Page 23: Changing The Password

    4.1 The Maintenance Console Software (MCS) 4.1.5 Changing the Password 1. Select "Tools" "Options". Click the "Password" tab. Enter the Current password. Enter and confrim the New password, then click [OK] to change the password. Getting Started...

  • Page 24: Creating New Group And Gateway

    4.2 Creating New Group and Gateway Creating New Group and Gateway When first setting up a VoIP network, Unit Groups must first be created. Once a new Unit Group has been created, New Gateways can be added to the group. Refer to the following steps and examples given in 1.2 Network Devices and Numbering Plan to create new Unit Groups and Gateways.
  • Page 25 4.2 Creating New Group and Gateway 2. Setup Wizard (1/6): Enter Name of the Gateway. Select "BV1250G" for "Unit", "V1.40" for "Version", and "BRIT" for "Interface". Note: Do not select any other value than above. Enter Comment for the Gateway (if necessary), then click [Next >].
  • Page 26 4.2 Creating New Group and Gateway 6. Setup Wizard (5/6): • Check "Use Default Password" to accept the default User Level Password ("user"), then click [Next >]. • Enter and confirm the User Level Password to change the default password, then click [Next >]. 7.

  • Page 27: Configuring Domain Name System (Dns) Data

    4.3 Configuring Domain Name System (DNS) Data Configuring Domain Name System (DNS) Data The function of a DNS in a VoIP network is to provide telephone number-to-IP Address translations . The IP Gateway Card has internal DNS database capabilities that can contain a maximum of 511 units in the network.
  • Page 28 4.3 Configuring Domain Name System (DNS) Data Los Angels telephone extension is now configured. 4. Repeat steps 1 to 3 and configure all DNS data, then click [Save] to end configuration. The IP Gateway Card creates the database for entire network as a simple text file named "DNS.DAT"...

  • Page 29: Configuring Office Data

    4.4 Configuring Office Data Configuring Office Data Once a gateway unit is created, the MCS produces a configuration file (OFDD.VHO) containing the Office Data for the unit. Office Data is a generic term for configuration data set and stored in an IP Gateway Card. Edit the Office Data using the MCS so that each unit will operate properly in the network in which it is installed.
  • Page 30 4.4 Configuring Office Data Numbering Office Code Click the "Numbering" tab. Enter Office Code, then click [OK]. Setting Hunt Pattern Click the "Hunt pattern" tab. Click [OK]. Setting Trunk Data Click the "Trunk Data" tab. Click [OK]. Getting Started...
  • Page 31 4.4 Configuring Office Data Presetting Fax Protocol Click the "FAX related" tab. Select "TCP" (default) or "UDP", then click [OK]. Setting Other Data Click the "Other" tab. Select "A-law" or "m-law" (default) for "A- law/m-law flag"depending on the area in which the IP Gateway Card is used, then click [OK].

  • Page 32: Transferring The Data To The Ip Gateway Card

    4.5 Transferring the Data to the IP Gateway Card Transferring the Data to the IP Gateway Card Upon finishing all DNS and Office Data configuration using the MCS, please follow the procedure below to transfer the data to each Hybrid IP-PBX with IP Gateway Card in the network.

  • Page 33: Synchronising Time And Date Of The Ip Gateway Card

    4.6 Synchronising Time and Date of the IP Gateway Card Synchronising Time and Date of the IP Gateway Card Loss of clock synchronisation of the IP Gateway Card will produce alarm indications under 2 conditions: (1) when the IP Gateway Card is newly installed to the Hybrid IP-PBX, or (2) when it has been disconnected from a power source for more than two months causing the battery discharge.
  • Page 34 4.6 Synchronising Time and Date of the IP Gateway Card Getting Started...

  • Page 35: Optimising Performance

    Section 5 Optimising Performance Getting Started...

  • Page 36: Preventing Problems

    Voice level too low: Increase gain by decreasing PAD level. Voice loud/distorted: Decrease gain by increasing PAD level. Excessive background noise: Decrease gain by increasing PAD level. To configure, please refer to Section 4.9.1 Configure Gateway Units (KX-TDA0480) of IP Gateway Card Installation Manual. 5.1.2 Transmission Delays Transmission delays can cause delays and loss in voice communications and fax transmissions.

  • Page 37: Priority Control

    The priority control feature should be used when available. To configure, please refer to Section 4.9.1 Configure Gateway Units (KX-TDA0480) of IP Gateway Card Installation Manual. 5.1.4 Recovery Delay and Jitter Buffer When voice signals are packetised and transmitted, individual packet can take different paths through the network and arrive at the destination at varied timings (Jitter).
