- Page 1 Operator´s manual Solar Mower Please read these instructions carefully and make sure English you understand them before using the machine.
- Page 2 The Solar Mower is in many ways a revolutionary product. It allows you to have a well-kept lawn throughout the season with a minimum of inspection and maintenance.
-
Page 3: Table Of Contents
WARNING! up the rear solar panel. Under no circumstances may the original SECURITY CODE design of the Solar Mower be modified without the permission of the manufacturer. Always use genuine spare parts. Non authorised modifications and/or components can result in serious disruptions and the risk of personal Symbols in the Operator’s Manual... -
Page 4: Safety Regulations
Moving from or within the mowing area: Fold up the rear section of the solar panel. • Do not stand in front of the Solar Mower when you start it. Make sure that no one else is standing in front of the Solar Wait until the cutting disc has come to a complete stop. -
Page 5: Parts Of The Solar Mower
PARTS OF THE SOLAR MOWER STOP STOP What is what? Handle and rear panel support 11. Front wheel 12. Buzzer Latch 3. Box containing computer and battery 13. LEDs 14. Keyboard 4. Rear solar panel 5. Hinge 15. Power switch 6. -
Page 6: Function
The Solar Mower will also mow in the shade if the battery has a sufficient charge. It will then run a few metres in the shade at a time and then reverse to avoid the risk of becoming stranded in the shade. -
Page 7: Installation
If you install the boundary wire yourself it is important that the instructions below are followed carefully. When the Solar Mower is set to work in the mowing area the grass should not be more than a couple of centimetres longer than the set cutting height. - Page 8 It is possible with paths that are on the same level as the lawn Delimiting areas within the mowing area to allow the Solar Mower to drive a little way onto the path and It’s possible, if required, to delimit sections within the mowing thereby not leaving an uncut area.
-
Page 9: Use
Starting the Solar Mower The cutting height can be adjusted between 3 and 9 cm. 1. If the Solar Mower is new or has been stored for a long time, the batteries must be charged before starting. Charge • Switch off the Solar Mower by folding up the rear solar panel,... -
Page 10: Start-Up Sequence
Start-up sequence These instructions assume that the boundary wire and generator have been installed correctly. It is not necessary to charge the battery for 60 minutes if the Solar Mower has been used recently. Charge 60 min in bright daylight Power switch in “STOP”... -
Page 11: Settings
The Solar Mower works as soon as there is sufficient daylight. If 0000 # 1234 # 1234 # the Solar Mower is used on a small area it may mean that it The green LED will come on after entering the sequence if the works more than is necessary to keep the lawn mown. -
Page 12: Error And Information Messages
Error and information messages This table will help you to easily interpret the Solar Mower’s signals. When the panel is opened and the alarm has been switched off the LEDs on the keyboard will come on for 12 seconds. A green LED indicates an information message and a red LED an error message. -
Page 13: Replacing The Blades
If the Solar Mower has difficulty in sensing the boundary wire despite its length not exceeding 500 m it may be necessary to • During the winter the Solar Mower should be stored in a dry replace the battery in the generator. -
Page 14: Trouble Shooting
Manual to make sure that the fault cannot be easily rectified via the keyboard or the main power switch. Observation Possible cause Action 3 beeps/second If the Solar Mower is inside the mowing Swap the boundary wire connections to LED 6 on area the boundary wire is incorrectly the generator. -
Page 15: Eu Declaration Of Conformity
We, Husqvarna AB, S-561 82 Huskvarna, Sweden, tel. +46 36-146500, declare under sole responsibility that the automatic lawn mower Husqvarna Solar Mower from 2002’s serial numbers and onwards (the year is clearly stated in plain text on the type plate with subsequent serial number), is in conformity with the following standards or other normative documents following the provisions in the COUNCIL’S DIRECTIVES:... - Page 16 114 00 43-26 ´+H$@¶6I¨ 2002W02...
