CS-AW7020
CS-AW7220
CS-AW7020
CS-AW7040
SUBWOOFER
CAISSON DE GRAVE
INSTRUCTION MANUAL
MANUEL D'INSTRUCTIONS
MANUAL DE INSTRUCCIONES
CS-AW7040
CS-AW7240
CS-AW7220
CS-AW7240
For Customer Use:
Enter below the Model No, and Serial
No, which is located either on the rear
or bottom of the speaker unit. Retain
this information for future reference.
Model No.
Serial No.
LVT1743-001A
Advertisement
Table of Contents
Related Manuals for JVC Arsenal CS-AW7020
Summary of Contents for JVC Arsenal CS-AW7020
- Page 1 CAISSON DE GRAVE CS-AW7020 CS-AW7220 CS-AW7020 CS-AW7040 INSTRUCTION MANUAL MANUEL D'INSTRUCTIONS MANUAL DE INSTRUCCIONES SUBWOOFER CS-AW7040 CS-AW7240 CS-AW7220 CS-AW7240 For Customer Use: Enter below the Model No, and Serial No, which is located either on the rear or bottom of the speaker unit. Retain this information for future reference.
- Page 2 3.Do not subject the speakers to excessive input. The power handling capacity of the CS-AW7020/CS-AW7040/CS-AW7220/CS-AW7240 is 600 watts (R.M.S. MUSIC POWER). Any excessive input may damage the speakers. 4.The CS-AW7020/CS-AW7040/CS-AW7220/CS-AW7240 has an impedance of 2Ω ,4Ω,8Ω. Make sure that the output impedance of the amplifier's speaker terminal is rated at 2Ω,4Ω,8Ω.
-
Page 3: Dual 4 Ω Application Diagrams
Dual 4 Ω Application Diagrams JUMPER 1 Mono Amplifier 1 Subwoofer Jumper set to Series 8Ω(4Ω+4Ω) Load SERIES Input Mono 4Ω 8Ω *JUMPER is Removed 1 2ch Amplifier 1 Subwoofer Jumper is Removed 4Ω Load Stereo 4Ω 2-Chan JUMPER 1 Mono Amplifier 2 Subwoofers Jumper set to Series Subwoofers wired in Parallel... -
Page 4: Dual 2 Ω Application Diagrams
Dual 2 Ω Application Diagrams JUMPER 1 Mono Amplifier 1 Subwoofer Jumper set to Series 4Ω(2Ω+2Ω) Load SERIES Input Mono 2Ω 4Ω *JUMPER is Removed 1 2ch Amplifier 1 Subwoofer Jumper is Removed 2Ω Load Stereo 2Ω 2-Chan JUMPER 1 Mono Amplifier 2 Subwoofers Jumper set to Series Subwoofers wired in Parallel... -
Page 5: To Install The Sealed Enclosure
Front & Rear Baffle Boards (x 2) * Screw: Dia. 4mm x 50mm (x 8) (supplied) CS-AW7020 / CS-AW7040 CS-AW7220 / CS-AW7240 A 15-13/32 inch (391.7 mm) B 15-13/32 inch (391.7 mm) C 11-13/32 inch (290.1 mm) -
Page 6: Specifications
Fs (Hz) 34.6 Hz 10.277 Pe [max.] (W) Xmax.(mm) Freq.Responce (Hz) Magnet Mass (oz) Voice Coil(Aluminum)Dia.(inch) (mm) Hvc (mm) Hag (mm) CS-AW7020 CS-AW7040 series parallel series 2Ω + 2Ω 4Ω + 4Ω 83.54 dB 84.02 dB 84.12 dB 0.123 ft Dia. - Page 7 3.Ne pas appliquer un niveau d'entrée excessif aux haut-parleurs. La puissance d'entrée admissible pour les haut-parleurs CS-AW7020/CS-AW7040/CS-AW7220/CS-AW7240 est de 600 watts (puissance musicale R.M.S.). Tout signal d'entrée excessif risque de les endommager. 4.Les haut-parleurs CS-AW7020/CS-AW7040/CS-AW7220/CS-AW7240 ont une impédance de 2Ω,4Ω,8Ω. ll faut par conséquent s'assurer que l'impédance de sortie aux bornes de haut-parleur de l'amplificateur soit aussi de 2Ω,4Ω,8Ω.
- Page 8 Diagrammes d’application duale 4Ω JUMPER 1 amplificateur mono 1 (un) caisson de basse Cavalier branché en Série Impédance de charge de SERIES 8Ω(4Ω+4Ω) Input Mono 4Ω 8Ω *JUMPER is Removed 1 amplificateur mono 1 (un) caisson de basse Cavalier branché en Parallèle Impédance de charge de 8Ω(4Ω+4Ω) Stereo 4Ω...
- Page 9 Diagrammes d’application duale 2Ω JUMPER 1 amplificateur mono 1 (un) caisson de basse Cavalier branché en Série Impédance de charge de SERIES 4Ω(2Ω+2Ω) Input Mono 2Ω 4Ω *JUMPER is Removed 1 amplificateur mono 1 (un) caisson de basse Cavalier branché en Parallèle Impédance de charge de 4Ω(2Ω+2Ω) Stereo 2Ω...
- Page 10 MDF—20 mm (3/4 pouce) est recommandé pour le matériau de l’enceinte. Écrans acoustiques avant et arrière (x 2) * Vis: Dia. 4mm x 50mm (x 8) (fournis) CS-AW7020 / CS-AW7040 CS-AW7220 / CS-AW7240 A 15-13/32 inch (391.7 mm) B 15-13/32 inch (391.7 mm) C 11-13/32 inch (290.1 mm)
- Page 11 Pe [max.] (W) Xmax. (mm) Réponse en fréquence (Hz) Masse de l’aimant (once) Diamètre de la bobine mobile ( pouces (mm) Hvc (mm) Hag (mm) CS-AW7020 CS-AW7040 series parallel series 2Ω + 2Ω 4Ω + 4Ω 83.54 dB 84.02 dB 84.12 dB...
- Page 12 “–” a “–”. Si las polaridades se co nectan inversamente, la reproducción este reofónica se deteriorará. 3.No someta los altavoces a una entrada excesiva. La capacidad máxima de los CS-AW7020/CS-AW7040/CS-AW7220/CS-AW7240 es de 600 votios (POTENCIA MUSICAL R.M.S.). Una entra da excesiva dañará los altavoces. 4.Los CS-AW7020/CS-AW7040/CS-AW7220/CS-AW7240 tienen 2Ω,4Ω,8Ω de impedancia.
- Page 13 Diagramas de Aplicasion Dual 4Ω JUMPER 1 amplificador monofónico 1(un) bajo Puente fijado en serie Carga a 8Ω(4Ω+4Ω) SERIES Input Mono 4Ω 8Ω *JUMPER is Removed Amplificador 1,2 ch 1(un) bajo Se quita el puente Carga a 4Ω Stereo 4Ω 2-Chan JUMPER 1 amplificador monofónico 2 (Dos) bajos...
- Page 14 Diagramas de Aplicasion Dual 2Ω JUMPER 1 amplificador monofónico 1(un) bajo Puente fijado en serie Carga a 4Ω(2Ω+2Ω) SERIES Input Mono 2Ω 4Ω *JUMPER is Removed Amplificador 1,2 ch 1(un) bajo Se quita el puente Carga a 2Ω Stereo 2Ω 2-Chan JUMPER 1 amplificador monofónico 2 (Dos) bajos...
- Page 15 MDF—20 mm(3/4 pulg.) como material para la caja. Pantallas acústicas delantera y trasera (x 2) * Tcrnillo: Dia. 4mm x 50mm (x 8) (suministrado) CS-AW7020 / CS-AW7040 CS-AW7220 / CS-AW7240 A 15-13/32 inch (391.7 mm) B 15-13/32 inch (391.7 mm) C 11-13/32 inch (290.1 mm)
- Page 16 10.277 Pe [máx.] (W) Xmax. (mm) Respuesta de frec (Hz) Masa del imán (oz) Diám.de la bobina móvil (pulgada) (mm) Hvc (mm) Hag (mm) CS-AW7020 CS-AW7040 series parallel series 2Ω + 2Ω 4Ω + 4Ω 83.54 dB 84.02 dB 84.12 dB 0.123 ft...
- Page 17 Dia. 10-14/32 inch [ 265 mm ] Dia. 10-26/32 inch [ 275 mm ] Dia. 9-4/32 inch [ 231.96 mm ] CS-AW7020 CS-AW7040 Dia. 12-12/32 inch [ 314 mm ] Dia. 12-24/32 inch [ 324 mm ] Dia. 10-28/32 inch [ 275.94 mm ]...
- Page 18 Santoprene Surround Air Vented Aluminum Cast Basket Integlated Dual-Layer Cone construction Woven Tinsel Lead (Patent Pending) Rapid Fire Impedance Selector Speaker Terminal ( Patent Pending) 4 (2+2) Layer Voice Coils Heat Transfer Silicon T3 Chassis (Thermal Transfer Technology) Aero Vent Bottom Plate - 18 - Multi Mount Smart Trim Ring...
- Page 19 - 19 -...
- Page 20 THANK YOU FOR PURCHASING THIS JVC PRODUCT. WE WANT TO HELP YOU ACHIEVE A PERFECT EXPERIENCE. NEED HELP ON HOW TO HOOK UP? NEED ASSISTANCE ON HOW TO OPERATE? NEED TO LOCATE A JVC SERVICE CENTER? LIKE TO PURCHASE ACCESSORIES? TOLL FREE: 1(800)252-5722 http://www.jvc.com...
