- Page 1 DRAYTEK VIGOR 2500 SERIES...
- Page 2 ISDN Backup Wireless AP The Vigor2500 series is an Internet access solution for your LAN which not only provides shared web surfing but countless other value-added features such as security, VPN and multimedia support, all in a reliable one-box solution.
-
Page 3: Led Indicators
Vigor2500 LED Indicators Descriptions ACT(Activity) Blink when power is supplied to the router and the router is running normally. LINE ON when the ADSL network is correctly setup ADSL Blinking indicates the DSL protocols start handshaking.The light will DATA remain still when data transmission is available. Local Area Network port status. - Page 4 Vigor2500We LED Indicators Descriptions ACT(Activity) Blink when power is supplied to the router and the router is running normally. LINE ON when the ADSL network is correctly setup ADSL Blinking indicates the DSL protocols start handshaking.The light will DATA remain still when data transmission is available. Local Area Network port status.
- Page 5 Vigor2500Wt LED Indicators Descriptions ACT(Activity) Blink when power is supplied to the router and the router is running normally. LINE ON when the ADSL network is correctly setup ADSL Blinking indicates the DSL protocols start handshaking.The light will DATA remain still when data transmission is available. Local Area Network port status.
-
Page 6: Copyright Declarations
Copyright 2003 All rights reserved. This publication contains information that is © Copyright protected by copyright. No part may be reproduced, transmitted, transcribed, stored Declarations in a retrieval system, or translated into any language without written permission from the copyright holders. The following trademarks are used in this document: Trademarks . -
Page 7: Be A Registered Owner
R&TTE Directive 99/5/EC. Web registration is preferred. You can register your Vigor router via http:// Be A Registered www.draytek.com.tw . Alternatively, fill in the registration card and mail it to the Owner address found on the reverse side of the card. -
Page 8: Aim Of This Chapter
Customer Service Department immediately. The Vigor2500 series all contain Annex A/Annex B models, please check if the package is suitble for your using. You can get the information from bottom of Vigor2500 series router. -
Page 9: Dsl Parameters
DSL line What you Depending on the variant Vigor2500 series you purchased, the following DSL need from ISP service must be available at your local premisses: ADSL/POTS : ADSL service must be enabled on your POTS telephone line. ADSL/ISDN : ADSL service must be enabled on your ISDN telephone line. -
Page 10: Local Networking
Example: VPI/VCI = 0/33 Protocol = PPPoA Encapsulation Method = VCMUX Modulation Method = G.DMT Username/Password Only for PPPoE/PPPoA mode users Fixed IP Address/ Subnet Mask/ Gateway IP Address Only for MPoA mode users. Some ISP will use DHCP method to provide IP address for MPoA mode users, then users do not need to know the fixed IP address. - Page 11 Ethernet port (between router and PC), DSL port and Power port as below: You must wire Vigor2500 Vigor2500We/Wt...
-
Page 12: Install ' Router Tools '
Install ‘ Router This tool which provides ‘Quick StartWizard’, ‘Firmware Upgrade Program ’ Tools ‘ and ‘Syslog Monitor’ client is in the attached CD. It supportsWindows, Mac OS 8/9 and Mac OS X. Once all previous steps are completed, turn on your router. After Power is on, Turn on your router the ‘ACT’... -
Page 13: Enter Router Menu
Once past the password prompt, you will now see the router’s main menu: Enter Router Menu (Example: Vigor2500) Click on ‘Internet Access Setup’ on the right-hand menu. Set DSL Parameters You will find two items : PPPoE/PPPoA and MPoA (RFC 1483/2684). Then You can continuely enter setting menu according to the protocol which ISP assigns. - Page 14 Enter your allocated username, password and DSL parameters according to the For PPPoE/PPPoA information provided by your ISP. Users If you want to connect to Internet all the time, you can check ‘Always On’. For MPoA (RFC Enter your allocated WAN IP address(or enabling DHCP client to get IP from 1483/2684) Users ISP) and DSL parameters according to the information provided by your ISP.
-
Page 15: Surfing Internet
You can also use this function to detect ATM/ DSL setting. Please follow the Auto detect ATM/ instructions to operate. If your country is not in the list, it may take longer time to DSL Setting detect. Surfing Internet Once all previous steps are completed, you can surf Internet now. You can also monitor the connection condition via router management function. -
Page 16: Wireless Lan Interface
The Vigor2500We and Vigor2500Wt are equipped with a wireless LAN interface Wireless LAN compliant with the 11 Mbps IEEE 802.11b protocol. The speed of Vigor2500Wt can up Interface to 22 Mbps. The features of wireless LAN capability enable high mobility of several simultaneous users accessing all LAN facilities just like on a wired LAN as well as Internet and WAN access. - Page 17 SSID(Service Set Identification): You should set the SSID same as your note book wireless card to allow the client PCs to access the network via the wireless LAN interface. The default SSID is "default". Channel: To select a wireless channel for Vigor2500We / Vigor2500Wt. The default channel is 6.
-
Page 18: Access Control Of Wireless Lan Interface
For additional security of wireless access, the Access Control allows your to restrict the Access Control of network access rights by the wireless LAN MAC address of client. Only the valid MAC Wireless LAN address which has been configured can allow to access the wireless LAN interface. Interface Enable Acces Control: To check the Enable Access Control to enable the MAC Address access control feature. -
Page 19: Trouble Shooting For Can Not Get On To The Internet
Trouble Shooting for Can not get on to the Internet Check if the power and LAN line are connected correctly. After power is on, Check if the the ‘ ACT ‘ LED will blink once a second, and the correspondent LAN port hardware is OK? will light. -
Page 20: For Windows
The default gateway IP of router is 192.168.1.1. Please check if you can ping router correctly. For Windows For Mac(Terminal) If not, please check the IP address of your PC. We suggest you set ‘ get IP automatically ‘... - Page 21 For Win98/ Me user 1. Enter “Control Panel” and double 2. Choose “TCP/IP of LAN device” and press “ click “Network”. Properties”. 3. Choose “Obtain an IP address automatically”...
- Page 22 For Win2000 user 1. Enter “Control Panel” and double click “Network and Dial-up Connections”. 4. Select ‘Obtain an IP address automatically’ 2. Right click “Local Area Connection” and choose “Properties”. 3. Choose “TCP/IP” and press “Properties”.
- Page 23 For XP user 1. Enter “Control Panel” and double click “Network Connections”. 4. Select “Obtain an IP address automatically” 2. Right click LAN icon and choose “Properties”. 3. Choose “TCP/IP” and press “Properties”.
- Page 24 For Mac OS9.x user Control Panel —> TCP/IP System Preferences —> Network For Mac OSX user...
- Page 25 Are DSL/ ISP Connect to router Web Configurator. settings Ok? (Example: Vigor2500) Check if the setting of DSL is ok. (For MPoA users, please refer to the MPoA explanation on page 24 ) —> VPI/VCI/Modulation mode: T1.413, G.Lite, G.DMT, Mu ti-mode...
- Page 26 —>Encapsulation mode: VCMUX or LLC/SNAP For PPPoE/PPPoA user, please check if user name/ password provided by ISP are correct or not.
- Page 27 ADSL Internet connection. Please contact local still can not work ISP representatives to help you for configuration. If the router does not work correctly, please contact your dealer for help. For any further questions, please write email to support@draytek.com.tw. www.simet.com.tr...
