HIGH POWER CD/MP3/WMA PLAYER WITH RDS TUNER
DEH-3730MP
DEH-3700MP
This service manual should be used together with the following manual(s):
Model No.
Order No.
CX-3158
CRT3394
For details, refer to "Important Check Points for Good Servicing".
PIONEER CORPORATION
PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
PIONEER CORPORATION 2004
Mech.Module
S10.1AAC
CD Mech. Module : Circuit Description, Mech. Description, Disassembly
4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
DEH-3730MP/XN/EW
/XN/EW
Remarks
ORDER NO.
CRT3395
/XN/EW
K-ZZA. NOV. 2004 Printed in Japan
Advertisement
Table of Contents
Related Manuals for Pioneer DEH-3730MP
Summary of Contents for Pioneer DEH-3730MP
- Page 1 PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan PIONEER ELECTRONICS (USA) INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A. PIONEER EUROPE NV Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936 PIONEER CORPORATION 2004 K-ZZA.
-
Page 2: Safety Information
ICs inside the unit. 3. To protect the pickup unit from electrostatic discharge during servicing, take an appropriate treatment (shorting-solder) by referring to "the DISASSEMBLY". 4. After replacing the pickup unit, be sure to check the grating. DEH-3730MP/XN/EW... - Page 3 To protect products from damages or failures during transit, the shipping mode should be set or the shipping screws should be installed before shipment. Please be sure to follow this method especially if it is specified in this manual. DEH-3730MP/XN/EW...
-
Page 4: Table Of Contents
7. GENERAL INFORMATION ..........................49 7.1 DIAGNOSIS ............................. 49 7.1.1 DISASSEMBLY ............................. 49 7.1.2 CONNECTOR FUNCTION DESCRIPTION ..................52 7.2 PARTS..............................53 7.2.1 IC ................................53 7.2.2 DISPLAY ............................... 61 7.3 OPERATIONAL FLOW CHART ....................... 62 7.4 CLEANING............................... 63 8. OPERATIONS ..............................64 DEH-3730MP/XN/EW... -
Page 5: Specifications
1. SPECIFICATIONS DEH-3730MP/XN/EW... -
Page 6: Exploded Views And Parts List
• Screw adjacent to mark on the product are used for disassembly. • For the applying amount of lobricants or glue, follow the instructions in this manual. (In the case of no amount instructions,apply as you think it appropriate.) 2.1 PACKING DEH-3730MP/XN/EW... - Page 7 CRY1157 Polyethylene Bag CEG-162 Case Assy CXB3520 Carton See Contrast table(2) Contain Box See Contrast table(2) (2) CONTRAST TABLE DEH-3730MP/XN/EW and DEH-3700MP/XN/EW are constructed the same except for the following: Mark Description DEH-3730MP/XN/EW DEH-3700MP/XN/EW Carton CHG5433 CHG5432 Contain Box CHL5433...
-
Page 8: Exterior
2.2 EXTERIOR DEH-3730MP/XN/EW... - Page 9 Spring CBH2367 IC(IC302) TDA7386 Bracket CNC6791 Transistor(Q911, 921, 991) 2SD2396 Holder CNC8042 (2) CONTRAST TABLE DEH-3730MP/XN/EW and DEH-3700MP/XN/EW are constructed the same except for the following: Mark Description DEH-3730MP/XN/EW DEH-3700MP/XN/EW Chassis Unit CXC4288 CXC4287 Detach Grille Assy CXC4390 CXC3551 Grille Unit...
-
Page 10: Cd Mechanism Module
2.3 CD MECHANISM MODULE 1GEM1024 2GEM1045 3GEM1035 DEH-3730MP/XN/EW... - Page 11 CND2712 Bracket CND1895 Screw JFZ20P020FTC CNC9968 Screw JGZ17P022FTC CND1909 ••••• Lever CND2032 Washer YE20FTC Pickup Unit(P10)(Service) CXX1641 Lever CNC9984 Sheet CNM8134 Screw IMS26P030FTC Collar CNV7798 Spring CBL1635 Guide CNV7799 Clamper CNV8372 CNV8403 Rack CNV8374 Holder CNV8376 Holder CNV8377 CNV8378 DEH-3730MP/XN/EW...
-
Page 12: Block Diagram And Schematic Diagram
IC 301 IC 701 BRST,BRXEN,BSRQ BRST,BRXEN,BSRQ,BDATA,BSCK PE5454A BA5835FP BDATA,BSCK Q991 B.UP Q992 12EJ VDCONT DSCSNS HOME VDSENS VDSENS VDCONT VDCONT S904 S905 S903 S901 3V REGULATOR 12EJ DSCSNS HOME 3VDD IC 703 IC 203 S-812C33AUA-C2N V3R3D NJM2885DL1-33 3.3V REGULATOR DEH-3730MP/XN/EW... - Page 13 CN1801 Q801 SWVDD SW5V SOURCE SWVDD SWVDD SOURCE SOURCE INTRQ VDSENS DSENS DSENS DSENS Q821 B.UP KEY MATRIX Q822 ILMPW KEY DATA DPDT DPDT DPDT X1801 5MHz KYDT LCD DRIVER/ KYDT KYDT KEY CONTROLLER SW5V VLCD IC 1801 PD6340A DEH-3730MP/XN/EW...
-
Page 14: Overall Connection Diagram(Guide Page)
No differentiation is made between chip capacitors and 0.022 R022 discrete capacitors. CN1801 The > mark found on some component parts indicates the importance of the safety factor of the part. Therefore, when replacing, be sure to use parts of identical designation. DEH-3730MP/XN/EW... - Page 15 TUNER AMP UNIT > > CEK1208 BACKUP B.REM RL— FL— RR— FR— BACK DEH-3730MP/XN/EW...
- Page 16 DEH-3730MP/XN/EW...
- Page 17 DEH-3730MP/XN/EW...
- Page 18 DEH-3730MP/XN/EW...
- Page 19 DEH-3730MP/XN/EW...
-
Page 20: Keyboard Unit
3.3 KEYBOARD UNIT DEH-3730MP/XN/EW... - Page 21 KEYBOARD UNIT CN831 CEL1662 DEH-3730MP/XN/EW...
-
Page 22: Cd Mechanism Module(Guide Page)
3.4 CD MECHANISM MODULE(GUIDE PAGE) PICKUP UNIT(P10)(SERVICE) M1 CXC4440 SPINDLE MOTOR M2 CXB8933 LOADING /CARRIAGE CD DRIVER MOTOR DEH-3730MP/XN/EW... - Page 23 S904:12EJ SWITCH.....ON-OFF S905:8EJ SWITCH....ON-OFF The underlined indicates the switch position. SIGNAL LINE FOCUS SERVO LINE TRACKING SERVO LINE CARRIAGE SERVO LINE SPINDLE SERVO LINE CD CORE UNIT(S10.1) 3.3V REGULATOR SRAMLEVEL2 MICRO COMPUTER 3V REGULATOR CN651 SRAMLEVEL1 SRAMLEVEL0 TYPE_A/D & DEH-3730MP/XN/EW...
- Page 24 DEH-3730MP/XN/EW...
- Page 25 DEH-3730MP/XN/EW...
- Page 26 DEH-3730MP/XN/EW...
- Page 27 DEH-3730MP/XN/EW...
- Page 28 7 SIN 500mV/div 200mV/div 1V/div @ TE 500mV/div 9 TIN 500mV/div CD-ROM play operation(Regular track Jump) Spindle waveform during play operation Spindle waveform during play operation (Wider) Ref.: Ref.: Ref.: REFO REFO REFO Mode: Mode: Mode: Normal Normal Normal DEH-3730MP/XN/EW...
- Page 29 500mV/div 4 LOEJ 3 12SNS 9 TIN 5V/div 5V/div 500mV/div 4 LOEJ 5V/div 12 cm CD Eject operation 8 cm CD Eject operation CD-DA >> CD-ROM mode change(Band key) Ref.: Ref.: Ref.: REFO Mode: Mode: Mode: Normal Normal Normal DEH-3730MP/XN/EW...
- Page 30 % RFAGC 1V/div 500ms/div 1V/div 500µs/div 8 CIN 9 TIN 500mV/div 1V/div 9 TIN @ TE 500mV/div 1V/div 0 FIN 1V/div CD-ROM >> CD-DA mode change(Band key) Black dot(800µm) during play Ref.: Ref.: REFO REFO Mode: Mode: Normal Normal DEH-3730MP/XN/EW...
- Page 31 DEH-3730MP/XN/EW...
-
Page 32: Pcb Connection Diagram
For further information for respective destinations, be sure to check with the schematic dia- gram. Cord Assy 2.Viewpoint of PCB diagrams Capacitor Connector SIDE A SIDE B P.C.Board Chip Part CN901 CN1801 DEH-3730MP/XN/EW... - Page 33 SIDE A ANTENNA CN1801 FRONT DEH-3730MP/XN/EW...
- Page 34 TUNER AMP UNIT DEH-3730MP/XN/EW...
- Page 35 SIDE B DEH-3730MP/XN/EW...
-
Page 36: Keyboard Unit
4.2 KEYBOARD UNIT KEYBOARD UNIT SIDE A DEH-3730MP/XN/EW... - Page 37 KEYBOARD UNIT SIDE B CN831 DEH-3730MP/XN/EW...
-
Page 38: Cd Core Unit(S10.1)
4.3 CD CORE UNIT(S10.1) CD CORE UNIT(S10.1) SIDE A LOADING /CARRIAGE MOTOR SPINDLE MOTOR CN651 HOME REFO1 DEH-3730MP/XN/EW... - Page 39 CD CORE UNIT(S10.1) SIDE B 12EJ DSCSNS DEH-3730MP/XN/EW...
-
Page 40: Electrical Parts List
D 921 (A,21,84) Diode HZS9L(B3) R 633 (B,50,70) RS1/16S104J R 651 (B,54,35) RS1/16S0R0J D 931 (A,66,112) Diode HZS7L(C3) R 652 (B,55,33) RS1/16S0R0J D 932 (A,49,109) Diode HZS7L(A1) R 653 (B,44,37) RS1/16S104J D 991 (A,17,62) Diode HZS7L(C3) R 654 (B,72,52) RS1/16S102J DEH-3730MP/XN/EW... - Page 41 CFTNA224J50 D 1808 (A,37,72) LED SML-310VT C 303 (A,130,121) CFTNA224J50 D 1809 (A,37,120) LED SML-310VT C 304 (A,120,107) CFTNA224J50 D 1810 (A,23,119) LED CL-490S-WF-SD C 309 (B,133,129) CKSQYB225K10 X 1801 CSS1547 (B,33,83) Ceramic Resonator 5.00MHz C 310 (B,134,133) CKSQYB225K10 DEH-3730MP/XN/EW...
- Page 42 R 711 (B,44,53) RS1/16SS221J R 714 (B,51,53) RS1/16SS473J Unit Number:CWX3096 R 716 (A,63,56) RS1/16SS472J Unit Name:CD Core Unit(S10.1) R 719 (B,49,45) RS1/16SS221J R 720 (B,46,52) RS1/16SS471J R 724 (A,62,42) RS1/16S473J MISCELLANEOUS R 725 (B,57,43) RS1/16SS222J IC 201 (A,39,24) IC UPD63763GJ DEH-3730MP/XN/EW...
- Page 43 C 228 (A,49,9) CKSSYB103K16 C 234 (B,36,81) CEVW221M4 C 237 (B,38,29) CKSSYB104K10 C 239 (B,34,10) CCSSCH220J50 C 242 (B,58,32) CKSSYB104K10 C 243 (B,39,76) CKSSYB104K10 C 244 (B,49,70) CKSSYB104K10 C 246 (A,23,19) CKSSYB104K10 C 251 (B,28,31) CKSRYB102K50 C 260 (A,54,25) CKSSYB104K10 DEH-3730MP/XN/EW...
-
Page 44: Adjustment
1k ohms in series. • The load and eject operation is not guarantied with the mechanism upside down. If the mechanism is blocked due to mistaken eject operation, reset the product or turn off and on the ACC to restore it. DEH-3730MP/XN/EW... - Page 45 → → TYP(1X) TYP(2X) TRK 22 MIN 22 SEC 22 TRK 11 MIN 11 SEC 11 TRK 11 MIN 11 SEC 11 TRK 22 MIN 22 SEC 22 As for the double speed (2x), audio output cannot be supported DEH-3730MP/XN/EW...
-
Page 46: Checking The Grating After Changing The Pickup Unit
Because of eccentricity in the disc and a slight misalignment of the clamping center the grating waveform may be seen to "wobble" ( the phase difference changes as the disc rotates). The angle specified above indicates the average angle. • Hint Reloading the disc changes the clamp position and may decrease the "wobble". DEH-3730MP/XN/EW... - Page 47 Ech → Xch 20mV/div, AC Grating waveform Fch → Ych 20mV/div, AC 0° 30° 45° 60° 75° 90° DEH-3730MP/XN/EW...
-
Page 48: Error Mode
If TOC can’t be read, error wouldn’t occur, but mechanism still continues its operation. The upper digits of error code is mainly classified by 3 kinds as follows: 1x: Setup related error, 3x: Search related error, Ax: Other errors. DEH-3730MP/XN/EW... -
Page 49: General Information
Grille Assy. Fig.1 Grille Assy Removing the Tuner Amp Unit (Fig.2) Remove the screw. Remove the three screws. Straighten the tabs at three locations indicated. Remove the screw and then remove the Tuner Amp Unit. Tuner Amp Unit Fig.2 DEH-3730MP/XN/EW... - Page 50 Caution: Before installing the carriage mechanism in the frames, be sure to apply some alcohol to the dampers and set the mechanism to the clamp mode. Carriage Mechanism Damper Lower Frame Damper Damper DEH-3730MP/XN/EW...
- Page 51 Caution: In assembling, move the planet gear to the load/eject position before setting the feed screw in the inner holder. Washer Pickup Lock Arm Change Arm Styling Holder Feed Screw Inner Holder Planet Gear DEH-3730MP/XN/EW...
-
Page 52: Connector Function Description
7.1.2 CONNECTOR FUNCTION DESCRIPTION Pin No. Pin No. B.UP B.REM DEH-3730MP/XN/EW... -
Page 53: Parts
E.VOL strobe output E.VOL data output E.VOL clock output Not used TUNPCE2 PLL chip enable output 2 TUNPCE PLL chip enable output RDS LK input RDSLK RDS clock input RDS57K RDS 57K input RESET Reset LDET PLL lock detection input DEH-3730MP/XN/EW... - Page 54 P-BUS serial pole request input Wired remote control input(Not used) STRKEY1 * PE5446A IC's marked by * are MOS type. Be careful in handling them because they are very liable to be damaged by electrostatic induction. BA33BC0FP Vref Vref DEH-3730MP/XN/EW...
- Page 55 Key data output MODA Crystal oscillator connection pin Crystal oscillator connection pin 25,26 KDT2,3 Key data input Not used KST4 Key strobe output 29-32 Not used 33-55 SEG35-13 LCD segment output Power supply 57-64 SEG12-5 LCD segment output * PD6340A DEH-3730MP/XN/EW...
- Page 56 Output of DRAM ras cas)(LDQM) Output of DRAM lower cas(LDQM) cas!(UDQM) Output of DRAM upper cas(UDQM) Output of DRAM we oe(cas) Output of DRAM oe(cas) D.GND Ground for digital circuits 73-88 RDB0-15 Input/output of DRAM data0-15 89-99 RA0-10 Output of DRAM address0-10 DEH-3730MP/XN/EW...
- Page 57 Connected to the capacitor for output of REFOUT Reversal input of FE Output of FE ADIN Input of FE, TE A/D converter Reversal input of TE Output of TE Output of LD Input of PD D.GND Ground for digital circuits * UPD63763GJ DEH-3730MP/XN/EW...
- Page 58 CD mute control output 56-58 Not used CD LSI chip selection output Not used xwait CD LSI write control signal output CLKOUT Internal system clock output(Open) LOCK Spindle lock input Not used xwrite CD LSI write control signal output Not used DEH-3730MP/XN/EW...
- Page 59 CD-DA analog/digital output change setup testin Chip check test program starting input HOME Home SW sense input TEMP Temperature information sense input VDSENS VD power supply short sense input Not used * PE5454A Format Meaning CMOS NJM2885DL1-33 Thermal Protection Bandgap Reference DEH-3730MP/XN/EW...
- Page 60 22 AUDIOGND audio ground Ground of audio block 23 L ch O L channel output FM stereo “L-ch” signal output or AM audio output 24 R ch O R channel output FM stereo “R-ch” signal output or AM audio output DEH-3730MP/XN/EW...
-
Page 61: Display
7.2.2 DISPLAY - LCD(CAW1846) DEH-3730MP/XN/EW... -
Page 62: Operational Flow Chart
In case of the above signal, the communication Source keys with Grille microcomputer may fail. operative If the time interval is not 300msec, the oscillator may be defective. Source ON SYSPW←H Pin 43 Completes power-on operation.(After that, proceed to each source operation.) DEH-3730MP/XN/EW... -
Page 63: Cleaning
7.4 CLEANING Before shipping out the product, be sure to clean the following portions by using the prescribed cleaning tools: Portions to be cleaned Cleaning tools CD pickup lenses Cleaning liquid : GEM1004 Cleaning paper : GED-008 DEH-3730MP/XN/EW... -
Page 64: Operations
8. OPERATIONS DEH-3730MP/XN/EW... - Page 65 DEH-3730MP/XN/EW...
- Page 66 About the fixing screws for the front panel If you do not operate the Detaching and Replacing the Front Panel Function, use the supplied fixing screws and fix the front panel to this unit. Fixing screw (CBA1488) Fixing screw (CBA1488) DEH-3730MP/XN/EW...
- Page 67 DEH-3730MP/XN/EW...
- Page 68 - Jigs List Name Jig No. Remarks Test Disc TCD-782 Checking the grating L.P.F. Checking the grating g (Two pieces) DEH-3730MP/XN/EW...
