PORTABLE DVD PLAYER

PDV-LC10
THIS MANUAL IS APPLICABLE TO THE FOLLOWING MODEL(S) AND TYPE(S).
Model
Type
PDV-LC10
‡
ZY
‡
ZU/CA
‡
ZL
CONTENTS
1. SAFETY INFORMATION ...................................... 2
4. PCB CONNECTION DIAGRAM .......................... 31
5. PCB PARTS LIST ............................................... 38
6. ADJUSTMENT .................................................... 42
PIONEER CORPORATION
PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A.
PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936
c
PIONEER CORPORATION 1999
Power Requirement
AC230V Adapter or Battery pack
AC120V Adapter or Battery pack
AC230V Adapter or Battery pack
4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan
COLOR
BRIGHT
MONITOR
PHONES
ON/OFF
HOLD
DIGITAL OUT (OPTICAL)
7. GENERAL INFORMATION ................................ 44
7.1 DIAGNOSIS ................................................. 44
7.1.1 DISASSEMBLY ...................................... 44
7.1.2 TROUBLE SHOOTING .......................... 47
7.2 PARTS ......................................................... 48
7.2.1 IC ............................................................ 48
7.2.2 DISPLAY ..................................................... 61
T - ZZR SEPT. 1999 Printed in Japan
ORDER NO.
RRV2212
Remarks

Advertisement

Table of Contents
loading

Related Manuals for Pioneer PDV-LC10

Summary of Contents for Pioneer PDV-LC10

  • Page 1: Table Of Contents

    PIONEER CORPORATION 4-1, Meguro 1-chome, Meguro-ku, Tokyo 153-8654, Japan PIONEER ELECTRONICS SERVICE, INC. P.O. Box 1760, Long Beach, CA 90801-1760, U.S.A. PIONEER ELECTRONIC (EUROPE) N.V. Haven 1087, Keetberglaan 1, 9120 Melsele, Belgium PIONEER ELECTRONICS ASIACENTRE PTE. LTD. 253 Alexandra Road, #04-01, Singapore 159936 PIONEER CORPORATION 1999 T –...

  • Page 2: Safety Information

    For the latest information, always consult the current Also test with plug reversed PIONEER Service Manual. A subscription to, or ad- (Using AC adapter ditional copies of, PIONEER Service Manual may be plug as required) obtained at a nominal charge from PIONEER.
  • Page 3 PDV-LC10 LASER DIODE CHARACTERISTICS CAUTION : FOR DVD : MAXIMUM OUTPUT POWER : 3.2 mw LASER RADIATION WHEN OPEN, AVOID LONG-TERM WAVELENGTH : 650 nm VIEWING OF DIRECT LASER RADIATION. FOR CD : MAXIMUM OUTPUT POWER : 3.3 mw WAVELENGTH : 780 nm...

  • Page 4: Exploded Views And Parts List

    PDV-LC10 2. EXPLODED VIEWS AND PARTS LIST • NOTES: Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. • mark found on some component parts indicates the importance of the safety factor of the part.
  • Page 5 S-Video Cable VDE1059 Optical fiber Cable See Contrast table (2) Battery Pack (NI-MH) VEM1026 (2) CONTRAST TABLE PDV-LC10/ZY, ZU/CA and ZL are constructed the same except for the following: Part No. Symbol and Description Mark Remarks ZY type ZU/CA type...
  • Page 6 PDV-LC10 2.2 EXTERIOR (1/2) SECTION ZY:Only Refer to " 2.3 EXTERIOR (2/2) SECTION".
  • Page 7 VNK4492 Locker Spring VBH1316 Cushion C VEB1307 Mode Button VNK4486 (2) CONTRAST TABLE PDV-LC10/ZY, ZU/CA and ZL are constructed the same except for the following: Part No. Symbol and Description Mark Remarks ZY type ZU/CA type ZL type LCD Monitor PCB Assy...
  • Page 8 PDV-LC10 2.3 EXTERIOR (2/2) SECTION TRAVERSE MECHA ASSY KIT EXCHANGE ZU/CA:Only ZY,ZL:Only ZU/CA:Only ZY:Only ZY,ZU/CA:Only ZL:Only...
  • Page 9 VEB1303 Traverse Mecha Assy VXX2657 Display LCD VAW1051 Spacer VEC2064 (2) CONTRAST TABLE PDV-LC10/ZY, ZU/CA and ZL are constructed the same except for the following: Part No. Symbol and Description Mark Remarks ZY type ZU/CA type ZL type Body Assy...
  • Page 10 PDV-LC10 2.4 EXTERIOR (UP-SIDE ) SECTION Body Assy Bottom View...
  • Page 11 Free Stopper VXB1001 Label Assy See Contrast table (2) Open Label VRW1782 (2) CONTRAST TABLE PDV-LC10/ZY, ZU/CA and ZL are constructed the same except for the following: Part No. Symbol and Description Mark Remarks ZY type ZU/CA type ZL type...

  • Page 12: Block Diagram And Schematic Diagram

    TC74VHC541AFT SHI-ASIC SERVO DSP LC78652W 52-59 146-163 3V-5V IC602 PD3410A SHIFT To CN401 SH1 ASIC PDV-LC10 Only – 98 97 78 CN602 – 24 25 27 28 30 19 36 37 39 40 CN2001 – 39 16 17 19 20...
  • Page 13 PDV-LC10 IC2001 11 QR406 IC2001 21 QR405 SW601 DSP_OPEN VR401 IC4417 TP402 SP-L IC802 Q404 IC407(2/2) MB811171622A-100FN 16M bit SDRAM IC415 TP405 CODE Buffer (Video, Audio, Sub-picture,GUI) SP-R IC407(1/2) Q412 H-Phone 159-194 IC801 IC404(DAC IC) Memory Controller MB86373 PE8001A VOUTL...

  • Page 14: Overall Wiring Diagram

    PDV-LC10 3.2 OVERALL WIRING DIAGRAM Note : When ordering service parts, be sure to refer to "EXPLODED VIEWS and PARTS LIST" or "PCB PARTS LIST". AC POWER CORD ZY,ZL : ADG1127 ZU/CA: RDG1034 ZY, ZL : AC220-230V 50/60Hz AC ADAPTER...
  • Page 15 PDV-LC10 Back Light Panel LCD Panel LCD Driver VKN1555 DKN1152 PDVDS ASSY (VWG2143:ZY) (VWG2144:ZU/CA) (VWG2145:ZL) – PDVDM ASSY (VWS1406 : ZY) (VWS1381 : ZU/CA) (VWS1407 : ZL) VAW1051...
  • Page 16 PDV-LC10 3.3 PDVDM ASSY (1/6) (FTS SECTION) (DVD) (DVD) (DVD) VREF (DVD) (CD) (CD) CHIP SIZE Resistor size size Capactor size size...
  • Page 17 PDV-LC10 R334 ZY:220 Ω ZU/CA, ZL:47 Ω PDVDM ASSY(1/6) (VWS1406:ZY) from IC261 (VWS1381:ZU/CA) (VWS1407:ZL) (DVD) (DVD) (CD) (CD) (CD) (CD) : RF SIGNAL ROUTE : ROM DATA SIGNAL ROUTE : FOCUS SERVO LOOP LINE IC302 : TRACKING SERVO LOOP LINE : SLIDER SERVO LOOP LINE : The power supply is shown with the marked box.
  • Page 18 PDV-LC10 3.4 PDVDM ASSY (2/6) (SH1 SECTION) to IC602 R598 ZY:15kΩ ZU/CA,ZL :Not used R597 ZY:20kΩ ZU/CA, ZL R1000:0 Ω ZU/CA,ZL :Not used ZU/CA, ZL to IC602-64...
  • Page 19 PDV-LC10 PDVDM ASSY(2/6) (VWS1406:ZY) (VWS1381:ZU/CA) (VWS1407:ZL) 20MHz CHIP SIZE ZY,ZL ONLY Resistor size size Capactor size size N/P Selector : The power supply is shown with the marked box.
  • Page 20 PDV-LC10 3.5 PDVDM ASSY (3/6) (MY-CHIP SECTION) PDVDM ASSY(3/6) (VWS1406:ZY) (VWS1381:ZU/CA) (VWS1407:ZL) (DVD) (DVD) CHIP SIZE Resistor size size Capactor size size...
  • Page 21 PDV-LC10 : RF SIGNAL ROUTE : AUDIO SIGNAL ROUTE : ROM DATA SIGNAL ROUTE (DVD) (DVD)
  • Page 22 PDV-LC10 3.6 PDVDM ASSY (4/6) (AV1 SECTION) PDVDM ASSY(4/6) (VWS1406:ZY) (VWS1381:ZU/CA) (VWS1407:ZL) (DVD) from IC901 from IC901 (V/CB) (V/CB)
  • Page 23 PDV-LC10 CLOCK GENERATOR SECTION to IC801-197 to IC801-205 16MNz Master Clock Adjustment R908, R910, R920, R924 R912, R914 330Ω 220Ω 100Ω 100Ω ZU/CA, ZL (V/CB) (V/CB) : AUDIO SIGNAL ROUTE : ROM DATA SIGNAL ROUTE (V/CB) : V/CB SIGNAL ROUTE...
  • Page 24 PDV-LC10 3.7 PDVDM ASSY (5/6) (ANALOG AV SECTION) PDVDM ASSY(5/6) (VWS1406:ZY) (VWS1381:ZU/CA) (VWS1407:ZL) V+5DAC VREFA from Q410 HEAD PHONE VR from Q858 to Q407 to CN401-8 to CN401 (V/CB) to IC405...
  • Page 25 PDV-LC10 to Q413 from Q854 from IC851 VREFA V2R5 V5AA : The power supply is shown with the marked box. : AUDIO SIGNAL ROUTE : ROM DATA SIGNAL ROUTE (V/CB) : V/CB SIGNAL ROUTE : Y SIGNAL ROUTE : C SIGNAL ROUTE...
  • Page 26 PDV-LC10 3.8 PDVDM ASSY (6/6) (POWER SUPPLY SECTION) PDVDM ASSY(6/6) (VWS1406:ZY) (VWS1381:ZU/CA) (VWS1407:ZL) VLCD VLC2 VDCI...
  • Page 27 PDV-LC10 : The power supply is shown V5SP with the marked box. V+9D V5DR V+5S V5AV V+5A V+5D V+3D V2R5...
  • Page 28 PDV-LC10 3.9 PDVDS ASSY PDVDS ASSY VCCB ( VWG2143:ZY ) from CN2001-10 ( VWG2144:ZU/CA ) from Q2003 ( VWG2145:ZL ) from S2002 R2007 ZY:20kΩ ZU/CA:36kΩ ZL:30kΩ from S2003 from S2001 to CN2001 from CN2001 R2018 ZY:27kΩ ZU/CA:6.2kΩ R2024 ZL:12kΩ ZY:Not used ZU/CA:47kΩ...
  • Page 29 PDV-LC10 : The power supply is shown with the marked box. V+3S PDVDS ASSY S2001 : RETURN S2002 : ¡ ¢ (FWD) S2003 : 4 1 (REV) S2004 : TOP MENU S2005 : 7 (STOP) S2006 : UP S2007 : 6 (PLAY/PAUSE)
  • Page 30 PDV-LC10 WAVEFORMS (PDVM ASSY) Note : The encircled numbers denote measuring point in the schematic diagram. Measurement condition : No. 1 to 4 and 6 to 11 : Disc MA1, Title 1-chp 1 No. 5 : CD, ABEX-784 Track 1 No.

  • Page 31: Pcb Connection Diagram

    PDV-LC10 4. PCB CONNECTION DIAGRAM NOTE FOR PCB DIAGRAMS : 1. Part numbers in PCB diagrams match those in the schematic diagrams. 2. A comparison between the main parts of PCB and schematic diagrams is shown below. Symbol In PCB...
  • Page 32 PDV-LC10 4.1 PDVDM ASSY PDVDM ASSY CN2001 IC607 Q2007 IC302 IC604 Q112 IC412 IC606 Q610 IC304 IC605 IC603 Q858 Q606 IC610 Q409 IC403 Q403 IC608 IC405...
  • Page 33 PDV-LC10 • This PCB is a six-layered board. To TRAVERSE MECHANISM ASSY To TFT COLOR MONITOR LCD Driver Assy (VNP1701-C) Q102 Q101 Q100 IC202 IC802 IC903 IC201 Q858 Q901 IC901 Q611 IC261 IC853 IC902...
  • Page 34 PDV-LC10 PDVDM ASSY IC101 Q2007 Q105 Q106 Q110 Q108 IC606 IC351 Q850 Q612 Q857 Q853 IC851 Q854 IC852...
  • Page 35 PDV-LC10 • This PCB is a six-layered board. (VNP1701-C) Q405 IC609 Q113 Q114 IC101 Q103 IC602 Q107 Q110 Q411 Q406 Q609 Q413 Q402 Q104 Q858 IC261 Q407 Q408 Q608 IC801 IC402 Q614 Q613 Q404 Q861 Q851 IC404 IC407 Q412 IC406...
  • Page 36 PDV-LC10 4.2 LPP UNIT • This PCB is a four-layered board. PDVDS ASSY (VNP1702-A)
  • Page 37 PDV-LC10 • This PCB is a four-layered board. PDVDS ASSY Q2004 Q2006 IC2001 IC2002 IC2003 Q2002 Q2001 Q2003 Q2005 (VNP1702-A) CN602...

  • Page 38: Pcb Parts List

    PDV-LC10 Mark No. Description Part No. Mark No. Description Part No. 5. PCB PARTS LIST • NOTES: Parts marked by "NSP" are generally unavailable because they are not in our Master Spare Parts List. • mark found on some component parts indicates the importance of the safety factor of the part.
  • Page 39 PDV-LC10 Mark No. Description Part No. Mark No. Description Part No. 7 PCB PARTS LIST FOR PDV-LC10/ZY UDZ12B D3, D4, D403, D404 UDZS5.1B PDVDM ASSY D409– D413, D5, D601 UDZS5.1B D605– D611 UDZS5.1B SEMICONDUCTORS D1000 UDZS8.2B IC351 BA5929FP BA9707KV COILS AND FILTERS...
  • Page 40 PDV-LC10 Mark No. Description Part No. Mark No. Description Part No. C299 CKSRYF474Z16 RESISTORS C152, C216, C313, C325, C359 CKSSYB102K50 R612, R646, R652, R765, R766 RA4C103J C424, C435 CKSSYB102K50 R783 RA4C103J C133, C136, C203, C220, C225 CKSSYB103K16 R121, R602, R605– R610, R614...
  • Page 41 PDV-LC10 Mark No. Description Part No. PDVDS ASSY SEMICONDUCTORS IC2001 PE5060A IC2002 PST9330U IC2003 TK71533SCL Q2004 2SA1576A Q2001 2SB970 Q2002, Q2006 DTC114YUA Q2005 DTC124EUA Q2003 UMH1N SWITCHES S2001- S2013 VSG1013 CAPACITORS C2002 CKSRYB102K50 C2004 CKSRYB103K50 C2001, C2003, C2006, C2007 CKSRYF104Z16 C2005 (10µF/6.3V)

  • Page 42: Adjustment

    PDV-LC10 6. ADJUSTMENT 6.1 ADJUSTMENT ITEMS AND LOCATION Adjustment Items Adjustment Points (PCB Part) [Electrical Part] 16MHz Master Clock Adjustment SIDE A PDVDM ASSY CN401 SIDE B CN601 BATTERY/ CN201 DOWNLOAD TV TUNER 6.2 JIGS AND MEASURING INSTRUMENTS IC901 CN201...
  • Page 43 PDV-LC10 6.4 ELECTRICAL ADJUSTMENT 16MHz Master Clock Adjustment • Normal mode • Power ON PDVDM ASSY 16.934400MHz ± 80Hz VC901 COLOR BRIGHT MONITOR PHONES ON/OFF HOLD DIGITAL OUT (OPTICAL) START Player PDVDM ASSY IC901 1 Frequency counter...

  • Page 44: General Information

    PDV-LC10 7. GENERAL INFORMATION 7.1 DIAGNOSIS FPC 22P (VNP1693) Note for assembly: 7.1.1 DISASSEMBLY/ASSEMBLY If the FPC 22P comes off from the Body Assy, make it the figure 7.1.1.1 TRAVERSE MECHANISM ASSY and install it. Disassembly : Flexible 2-1/2 Sheet...
  • Page 45 PDV-LC10 7.1.1.2 LCD DISPLAY SECTION Disassembly : Assembly Traverse Mechanism Assy Perform steps of TRAVERSE MECHANISM ASSY and remove the LCD Display Section. Note: Be careful not to lost a LCD Rocker and a Rock Spring. Rock Spring Rocker Insulating...
  • Page 46 PDV-LC10 7.1.1.3 Confirmation After Replacing the LCD Display (Reference) • The adjustment is unnecessary if there is no problem even if the test disc or general disc is played back after the LCD display panel is replaced. Perform the following adjustment and confirm if the screen seems to be dirty.

  • Page 47: Trouble Shooting

    PDV-LC10 7.1.2 TROUBLE SHOOTING • No Power ON • TFT is not turned ON • LCD indication is unusual START Power ON • Check the DC voltage : DC 9V input (TP9) • Check the D1 and F2 on the PDVDM Assy.

  • Page 48: Parts

    PDV-LC10 7.2 PARTS 7.2.1 IC • The information shown in the list is basic information and may not correspond exactly to that shown in the schematic diagrams. • List of IC PE5060A, PD3410A, MB86373, LC78652W PE5060A (PDVDS ASSY : IC2001) •...
  • Page 49 PDV-LC10 c t i c t i c t i c t i c t i c t i c t i c t i − l l i − − − ← ) t i n i l ←...
  • Page 50 PDV-LC10 PD3410A (PDVDM ASSY : IC602) • System Control IC • Pin Function − − − − − − − − − r i c ) t i i t p a t i o i t −...
  • Page 51 PDV-LC10 − − − − − − c t i − c t i c t i c t i c t i − c t i − − l l o − −...
  • Page 52 PDV-LC10 − t i s d i l t i s − − − l l o l a i e l l l a i e l l − e l l − − −...
  • Page 53 PDV-LC10 − − − − − − −...
  • Page 54 PDV-LC10 MB86373 (PDVDM ASSY : IC801) • MPEG2 Decoder IC • Block Diagram Exclusive 16Mbit Parallel port SDRAM Input Signal System Memory Controller Block Interface Decoder Block Internal Video Sub- Sync. Decoder picture Control Block Block Starting Signal Control Reset...
  • Page 55 PDV-LC10 • Pin Function − " ( : " L " : " i g i − i g i i g i i g i ) t i − − − i g i - t l − ) t i −...
  • Page 56 PDV-LC10 − − − − t l i f t l i f t l i f − , y l o " . " − , y l o " . " − , y l o " . "...
  • Page 57 PDV-LC10 − − − − − − − − − − − " " L y l l − − − − − − − −...
  • Page 58 PDV-LC10 LC78652W (PDVDM ASSY : IC201) • DSP IC • Block Diagram SLDO Servo TILTE 8bit 8bit SPDO Processor RF_PH (16×16+32→32) TBAL RF_BH TILTDO AUXO JITT HFLIO Track Counter FAST Event Counter PP2/EVENT DVDSYEQ FG Counter SLCIST1,2 34,35 EFMIN V_PB...
  • Page 59 PDV-LC10 • Pin Function t f i − − l l i t t i y t i t l i − − − − a i l t l i −...
  • Page 60 PDV-LC10 r r i t i r − − − − l a i t f i − − l l i l i f − t l i f t l i f t l i f − −...

  • Page 61: Display

    PDV-LC10 7.2.2 DISPLAY VAW1051 (V2001 : PDVDS ASSY ) • LCD ÷ Pin Connection COM1 COM2 COM3 COM4 — — — COM4 — — — COM3 — — — COM2 — — — COM1...

  • Page 62: Panel Facilities And Specifications

    PDV-LC10 8. PANEL FACILITIES AND SPECIFICATIONS 8.1 PANEL FACILITIES Main unit control section Liquid crystal display The PDV-LC10 portable DVD player is equipped with a liquid crystal display. Hold scan function Scanning is held when the ◊ÛN¿ÇΩ,? PORTABLE DVD PLAYER previous or next button (4 or ¢) is held in for over 5...

  • Page 63: Side Panel

    Main unit rear panel To connect the player to a TV selector switch (AV-IN/AV- equipped with an S-Video input OUT) (PDV-LC10 only) jack, connect the included S- Select input or output accord- Video cable here. This jack is ing to how you are using the S2-compatible.
  • Page 64 PDV-LC10 Main unit display window TITLE 1AB PROGRAM RANDOM RESUME 8 RESUME 96 kHz ANGLE The title or chapter This lights when the resume number (for DVDs) or the function is on. track number (for video 9 ANGLE CDs and CDs) is displayed This lights when the angle here.

  • Page 65: Specifications

    370 g (PDV-10) Battery pack Power cord External dimensions 190 (W) x 142 (D) x 28 (H) mm (PDV-LC10) Note (not including protruding parts) The specifications and design of this 190 (W) x 142 (D) x 18 (H) mm (PDV-10)
