- Page 1 WS-855A User Manual Version 2.2 <Product Overview> 15” TFT Display 10-slot Workstation January 20, 2004...
-
Page 2: Copyright Notice
Copyright Notice © Copyright 2004 by ICP Electronics Inc. All rights reserved. No part of this manual may be reproduced, copied, or translated without prior notice to ICP Electronics Inc. The information provided in this document is for reference only. We do not assume any responsibility arising out of the application of the products. -
Page 3: Table Of Contents
Table of Contents Chapter 1. Product Information ........3 1.1. General Information..........3 1.2. Product Specifications ..........4 1.3. Dimensions............6 1.4. Front Accessible CD-ROM, 3.5" FDD ......7 1.5. The Membrane Keypad ..........8 Chapter 2. System Setup ..........9 Adding Cards ............ -
Page 4: Chapter 1. Product Information
PC/AT compatible computer specially designed to meet the applications for industrial working environments. LCD Display WS-855A is equipped with a color 1024x768 resolution 15" TFT LCD. Versatile Passive Backplane WS-855A can be equipped with PCI-10S (standard), PCI-10S2, BP-10S, IP-10S or PX-10S 10-slot backplane. -
Page 5: Product Specifications
Lockable drive door design & anti-vibration card clamp included. Backplane: PCI-10S (standard), PCI-10S2, BP-10S, IP-10S, PX-10S 10-slot backplane. 12cm ball bearing cooling fan with removable fan filter. Display Module SPEC IFICATIONS WS-855A LCD Type AU-15.0” XGA Color TFT-LCD Single Supply Voltage +12 VDC Panel Size 15”... - Page 6 Industrial Power Supply Power Supply: ACE-832A, 300W industrial power supply Shock: 10 G peak acceleration (11 msec. duration) Safety: meet UL/CSA/TUV EMI: meet FCC/VDE class A Environmental Specifications Operating Temperature : 0 ~ 50℃ Relative Humidity: 10-95% @40 ℃ , non-condensing Vibration: 5 to 17 Hz, 0.1"double-amplitude displacement, 17 to 500 Hz, 1.5 G Peak to peak...
-
Page 7: Dimensions
1.2. Dimensions The following diagram indicates the dimensions of WS-855A. 413.4... -
Page 8: Front Accessible Cd-Rom, 3.5" Fdd
1.3. Front Accessible CD-ROM, 3.5" FDD WS-855A workstation is equipped with one 5.25˝CD-ROM and 3.5˝ FDD that can be accessible by opening the front lockable drive door as shown in the following diagram. Power ON/OFF switch, Ext.-keyboard and USB port are also accessible through this same front lockable drive door. -
Page 9: The Membrane Keypad
The sealed-membrane keypad has 59 keys including 10 function keys to allow users enter data directly. Users can also attach the external keyboard through a connector on the front panel of WS-855A. A built-in controller will merge the signals from the membrane keypad and general keyboard into one signal, which... -
Page 10: Chapter 2. System Setup
Chapter 2. System Setup The WS-855A 15" TFT LCD 10-slot workstation is very easy to set up for operation. All you have to do is to open the back cover, install your CPU card, display control card, hard disk drive and other I/O cards required by your application, and you are ready to mount into a 19"... - Page 11 Please install the drivers in the order shown in the diagrams below. STEP 2 STEP 3 STEP 2 STEP 2 STEP 3 STEP 3...
-
Page 12: Power Supply Installation
2.3 Power Supply Installation Power supply is equipped at the rear of workstation and some screws are available to fasten it as shown below. STEP 2 STEP 3 STEP 1 STEP 3 BACKPLANE ACE-925A POWER SUPPLY Brown Blue Black White Brown WHITE Blue... -
Page 13: Cooling Fan Installation
2.4 Cooling Fan Installation WS-855A is equipped with a 12 cm ball bearing cooling fan with removable fan filter by the side of workstation. The following diagram shows the details of fan and its accessories. PCB GUIDE RAIL 12cm FAN... -
Page 14: Panel Mounting
2.5 Panel Mounting WS-855A can be mounted within a panel as shown in the following figure. Please make sure that the dimensions of the case is within panel aperture so that your screw holes line up with the mounting bolts on the flange of WS-855A. -
Page 15: Rack Mounting
2.6 Rack Mounting WS-855A can not only be mounted within a panel but also can be mounted in a 19" Rack. The following diagram shows how to mount WS-855A into the 19" Rack. -
Page 16: Chapter 3. Maintenance
3.2 Cooling Fan WS-855A is equipped with 12 cm cooling fan with removable fan filter by the side of the workstation. Please refer to the diagram of section 2.4. You have to open the chassis and unfasten the four bolt kits to take the fan out for maintenance. - Page 17 Appendix A Exploded Diagram ITEM DESCRIPTION PART NO. REMARK Front Panel 42001-0025XX 59key pad membrane 42002-0011XX Lockable front door 52100-000007 Touch pad units 19700-000003 OSD membrane 52100-000007 15” TFT LCD CPT-CLAA150XA03 23000-000037 Lock 45007-000104 Strengthened glass 15” 48113-333257 Optional Front panel bracket 41002-0035XX Display Bracket 41017-010702...
-
Page 18: Appendix B Keypad
Appendix B Keypad A. Block Diagram CON1 Membrane 2 Membrane 1 A203 CON2 Keyboard 1 Keyboard 2 B. Jumper Setting CON1 Pin1 Pin2 Pin3 Pin4 Pin5 +5V in DATA CLOCK CON2 Pin1 Pin2 Pin3 Pin4 Pin5 +5V in DATA CLOCK CON3 Pin1 Pin2... - Page 19 Pin1 Pin2 Pin3 Pin4 Pin5 BTN0 BTN1 BTN2 BTN3 BTN4 Pin6 Pin7 Pin8 BTN5 BTN6 BTN7 Pin1 Pin2 Pin3 Pin4 Pin5 LINE0 LINE1 LINE2 LINE3 LINE4 Pin6 Pin7 Pin8 Pin9 Pin10 LINE5 LINE6 LINE7 POWER GOOD +5V in LED- out Pin11 Pin12 Pin13...
-
Page 20: Appendix C User Mode Osd Item Description
Appendix C User Mode OSD Item Description Auto-Adjustment This item will automatically adjust the H/V position, frequency, phase, and black level. Auto Phase This item will automatically adjust the sampling. Brightness This item is used to adjust the brightness of screen. This function will also adjust the offset value of ADC. - Page 21 DOS/GFX It is used to select VGA input signal to either text mode or graphic mode. (This item is only selectable on resolution of 720/640x400 or 720/640x350.) 400 and 350 standard IBM modes have the same Hsync. and Vsync. Values so AV-9261 MPU cannot differentiate them automatically.
- Page 22 Revert It is used to reload original parameters from the factory’s OSD data area of the system EEPROM 24c16 device to re-initialize AV-9261 system device. When user adjust OSD data too much and did not gain better quality, user can select this item and MPU will reload default BIOS setting and re-initialize the system.
-
Page 23: Appendix D Touch Panel Controller
Appendix D Touch Panel Controller Please refer to the following diagram for graphic illustration of how connection of touch panel controller is done. Touch screen... -
Page 24: Appendix E Touch Pad
Appendix E Touch Pad TP-101 Touch Pad is PS/2 Mouse compatible. Users must connect the external PS/2 Mouse cable as the in the figure below. Touch Pad is a pointing device for computers and it detects the position of a finger over a touch-sensitive area. To move the cursor, users have to lightly slide a finger over the smooth sensor area. -
Page 25: Appendix Fcheck List
Appendix F CHECK LIST ITEM DESCRIPTION PART NO. Q’TY REMARK 32000-000002 ROUND CABLE.POWER CORD 175CM. By POWER SUPPLY ROUND CABLE.VGA CABLE M TO M. 15PIN 32000-023200 By VGA CABLE TO 15PIN.25CM. By Touch pad to CPU 32000-000072 ROUND CABLE.MINI DIN M TO M (27.5CM) CARD x1 By KEYBOARD x1 For: Touch screen...
