The standard North American 120 Volt AC and USB Outlets allow simultaneous operation of multiple devices. Simply plug the
equipment into the unit and operate normally. Ensure that the wattage of all equipment simultaneously plugged into the
unit's 120 Volt AC Outlets does not exceed 50 watts continuous.
N o t e s : The AC power supply shuts down automatically when the battery voltage level is too low. If only the red LED lights, a
faulty condition such as an overload, overheating or short circuiting has occurred. Turn the AC Power Supply OFF and
unplug the appliance. Wait a few minutes, then turn power back ON.
This unit's 120 Volt AC Outlet will not operate appliances and equipment that generate heat, such as hair dry e r s ,
electric blankets, microwave ovens and toasters.
I M P O RTA N T: When the Main Battery is being charged, the unit's AC power outlets are disabled. To enable the AC
power outlets, disconnect the AC Power/Charger Adapter and turn the unit's AC Power Supply ON.
I N V E RTER/AC CHARGER CONTROL PANEL DETAIL VIEW
AC ON/OFF
S W I T C H
AC ON/OFF LED
I N D I C AT O R
120 VOLT AC
O U T L E T
(WITH TETHERED
PROTECTIVE COVER)
AC STATUS LED
I N D I C AT O R
USING THE USB CHARGING PORT
Both the USB Charging Port and the USB ON/OFF Pushbutton are located on the left control panel (refer to the accompanying
i l l u s t r a t i o n ) .
1 . Press the USB Charging Port ON/OFF Pushbutton to turn the USB Port ON. The red USB Power LED will light.
2 . Plug the USB-powered device into the USB Power Ports and operate normally.
3 . Press the ON/OFF Pushbutton again to turn the USB Charging Port OFF when you are finished.
Make sure the USB Charging Port ON/OFF Pushbutton is in the OFF position when the unit is being recharged or stored.
N o t e : This unit's USB Charging Ports do NOT support data communication. They only provides 5 volts DC/0.5A maximum
power to an external USB-powered device.

TROUBLESHOOTING

General
P r o b l e m S o l u t i o n
The unit will not power ON • Check the Activation ON/OFF Switch on the bottom of the unit and make sure it is in
the ON p o s i t i o n .
• Connect the AC Power/Charger Adapter to the wall outlet securely
• Make sure that the batteries are charged (check the Battery Status Icon on the LCD
Display). If charge is low, recharge the battery.
Unit locks up Press the recessed Reset Pushbutton to restart the unit.
Unit shuts down B a t t e ry voltage has fallen below 10.8V. Recharge the battery.
Radio
P r o b l e m S o l u t i o n
Receptions is poor Reorient the antenna to improve reception.
Audio is week or has poor quality • Connect the AC Power/Charger Adapter to the wall outlet.
• Recharge built-in battery.
Inverter (120 Volt AC Power Supply and USB Charging Port)
P r o b l e m S o l u t i o n
AC or USB LED Status Light is not • B a t t e ry voltage below 10.5 volts: recharge unit.
O N • Equipment being operated draws too much power: reduce load to maximum 50 watts.
• Inverter in thermal shutdown condition: allow inverter to cool down. Shutdown AC
power and ensure that there is adequate ventilation around unit, and load is not
more than 50 watts for continuous operation.
9/26/08 12:50 PM Page 10
USB CHARGING
P O RT
(WITH TETHERED
PROTECTIVE COVER)
USB ON/OFF
P U S H B U T T O N
USB STAT U S
LED INDICAT O R
12 VOLT DC
CHARGING PORT
(FOR USE WITH AC
P O W E R / C H A R G E R
A D A P T E R )
10

CARE AND MAINTENANCE

This product has a sealed lead acid battery that should be kept fully charged. Charge before first use, immediately after each use,
and once every two months if not used regularly. When storing the unit for long periods of time, press, then slide the Activation
ON/OFF Switch to the OFF position to prevent battery drain. Failure to do this may reduce the battery life dramatically.
Reachargeable Flashlight Disposal
The Rechargeable Flashlight contains Ni-Cd rechargeable batteries and must be disposed of properly.
WA R N I N G S
These batteries are not user- r e p l a c e a b l e .
Refer to the "Important Safety Instructions" regarding safe handling of units containing batteries
in the Important Safety Instructions of this manual.
Main Battery/Dynamo Backup Battery Replacement
It is recommended that the unit be returned to manufacturer for battery replacement. Contact Customer
S e rvice, toll-free, at 1-800-544-6986.
Main Battery/Dynamo Backup Battery Disposal
Contains two maintenance-free, sealed, non-spillable, lead acid batteries, which
must be disposed of properly. Recycling is required — contact your local authority
for information. Failure to comply with local, state and federal regulations can
result in fines or imprisonment. For more information on recycling this battery, call
toll-free 1-800-822-8837.
WA R N I N G S
Do not dispose of this unit in fire as batteries inside this product may explode or leak.
Do not expose the unit containing battieres to fire or intense heat as it may explode.
ACCESSORIES
Recommended accessories for use with your tool are available from your local dealer or authorized service center. If you need
assistance regarding accessories, please call: 1-800-544-6986.
WARNING: The use of any accessory not recommended for use with this tool could be hazardous.

SERVICE INFORMATION

All Black & Decker Service Centers are staffed with trained personnel to provide customers with efficient and reliable power tool
s e rvice. Whether you need technical advice, repair, or genuine factory replacement parts, contact the Black & Decker location
nearest you. To find your local service location, refer to the yellow page directory under "Tools—Electric" or call: 1 - 8 0 0 - 5 4 4 -
6 9 8 6 or visit w w w. b l a c k a n d d e c k e r. c o m.
C A U T I O N
If the cord, wires, or cables become damaged, return the entire unit to manufacturer immediately for serv i c e / r e p a i r.
FULL TWO-YEAR HOME USE WARRANTY
Black & Decker (U.S.) Inc. warrants this product for two years against any defects in material or workmanship. The defective
product will be replaced or repaired at no charge in either of two ways.
The first, which will result in exchanges only, is to return the product to the retailer from whom it was purchased (provided that
the store is a participating retailer). Returns should be made within the time period of the retailer's policy for exchanges (usually
30 to 90 days after the sale). Proof of purchase may be required. Please check with the retailer for their specific return policy
regarding returns that are beyond the time set for exchanges.
The second option is to take or send the product (prepaid) to a Black & Decker owned or authorized Service Center for repair or
replacement at our option. Proof of purchase may be required. Black & Decker owned and authorized Service Centers are listed
under "Tools-Electric" in the yellow pages of the phone directory and on our websi t e www. b l a c k a n d d e c k e r. c o m .
This warranty does not apply to accessories. This warranty gives you specific legal rights and you may have other rights which
v a ry from state to state or province to province. Should you have any questions, contact the manager of your nearest Black &
Decker Service Center. This product is not intended for commercial use.
FREE WARNING LABEL REPLACEMENT: If your warning labels become illegible or are missing, call 1-800-544-6986 for a free
r e p l a c e m e n t .

SPECIFICATIONS

Operating Vo l t a g e : 12 volts 3Ah SEL main battery
3.6 volts 600mA dynamo backup battery
Frequency Range FM: 87.5 – 108 MHz
AM: 530 – 1710 kHz
WX: 162.400MHz, 162.425 MHz, 162.450 MHz, 162.475 MHz, 162.500
MHz, 162.525 MHz, 162.550MHz
Speaker: 8 , 3 watts
F l a s h l i g h t : 6 LEDs, 4 AA Ni-Cd batteries
USB Charging Port Output: 5 volts DC, 0.5A
AC Power Inverter Output: 120 Volts AC, 50 watts
12 Volt DC In Port: 12 volts DC, 500 mA
