D-Link DCS-7513 Quick Installation Manual
Full hd wdr day & night outdoor network camera
Hide thumbs
Also See for DCS-7513:
- User manual (99 pages) ,
- Quick installation manual (61 pages) ,
- Technical specifications (4 pages)
Table of Contents
Advertisement
Quick Links
Advertisement
Table of Contents
Related Manuals for D-Link DCS-7513
Summary of Contents for D-Link DCS-7513
-
Page 1: Quick Installation Guide
Quick Installation Guide Full HD WDR Day & Night Outdoor Network Camera This document will guide you through the basic installation process for your new D-Link Network Camera. DCS-7513 Documentation also available on CD and via the D-Link Website... -
Page 2: Quick Install Guide
This installation guide provides basic instructions for installing the Network Camera on your network. For additional information about how to use the camera, please see the User’s Manual which is available on the CD included in this package or from the D-Link support website. -
Page 3: Hardware Overview
2 screws. Install the SD Card Push the SD card into the camera with the gold contacts oriented towards the base of the camera. To eject the SD card, push the SD card into the slot. D-Link DCS-7513 Quick Install Guide... -
Page 4: Mounting Instructions
4. Mounting Instructions Mounting Installation Please see the User Manual for detailed instructions regarding installation and mounting of the camera using a mounting bracket. Figure 2.1 Figure 2.2 Figure 2.3 Figure 2.4 D-Link DCS-7513 Quick Install Guide... - Page 5 Connection with a PoE Hub If you are using a PoE hub, connect the IP camera to the hub via an Ethernet cable, which will provide transmission of both power and data over a single cable. D-Link DCS-7513 Quick Install Guide...
-
Page 6: Configuration With Wizard
Insert the DCS-7513 CD into your computer's CD-ROM drive to begin the installation. If the Autorun function on your computer is disabled, or if the D-Link Launcher fails to start automatically, click Start > Run. Type D:\autorun.exe, where D: represents the drive letter of your CD-ROM drive. - Page 7 Click on the D-Link Setup Wizard SE icon that was created in your Windows Start menu. Start > D-Link > Setup Wizard SE The Setup Wizard will appear and display the MAC address and IP address of your camera(s). If you have a DHCP server on your network, a valid IP Address will be displayed.
-
Page 8: Viewing Camera Via Web Browser
Viewing Camera via Web Browser Click on the D-Link Setup Wizard SE icon that was created in your Windows Start menu. Start > D-Link > Setup Wizard SE Select the camera and click the button labeled "Link" to access the web configuration.
