RM24906
Universal Remote
Instruction Manual

Advertisement

Table of Contents
loading

Related Manuals for GE RM24906

Summary of Contents for GE RM24906

  • Page 1 RM24906 Universal Remote Instruction Manual...

  • Page 2: Table Of Contents

    With the RM24906, juggling multiple remote controls is a thing of the past! Your RM24906 controls up to four devices, including the most popular brands of TV, VCR, DVD, CBL, and SAT.

  • Page 3: Introduction

    Setup Battery Installation 1. On the back of the remote, push down on the tab and lift the cover off. 2. Match the batteries to the + and - marks inside the battery case, then insert 2 AAA Alkaline batteries. 3.

  • Page 4: Button Functions

    Button Functions Some buttons on the remote might have functions that are referred to by different names on the device you are controlling. E.G. PREV.CH may be called RECALL, or ENTER may be called DISPLAY. These differences depend on the brand and model of your product. Also, this remote can only operate features that exist on your product.
  • Page 5 Button Functions, cont. ON•OFF Turns product On or Off. Note: The REC button must be pressed TWICE to record from your VCR. For some brands of VCRs, you might need to press the REC button once, then press it again for three seconds. CODE SEARCH Used to setup the remote, and for code search function.

  • Page 6: Menu Operation

    Menu Operation The Menu button puts the remote in and out of Menu Mode. Pressing Menu brings up your device Menu. While in Menu mode the remote’s red indicator light blinks continuously. The remote will exit Menu Mode after 20 seconds if no keys are pressed.

  • Page 7: Direct Code Entry

    Direct Code Entry 1. Press and hold the button until the red indicator stays on, then release the 2. Press and release the desired device button ( blinks, then stays lit. 3. Enter the 4 digit code from the code tables (on separate sheet). Note: after a valid code entry, the red indicator turns off.

  • Page 8: Code Search

    Code Search If your device does not respond after you have tried all the codes for your brand, or if your brand is not listed, try searching for your code by following these steps. 1. Manually turn on the device ( be controlled.

  • Page 9: Using Your Remote

    Using Your Remote Code Identification The Code Identification Feature allows you to identify the 4 digit library code stored under your device button. For example, if you want to find out what 4 digit code is stored under your TV device button, follow the six steps below: 1. Press and hold the button until the red indicator stays on. Release the 2.

  • Page 10: Sleep Function

    Using Your Remote, cont. Sleep Function The Sleep button enables the remote to turn off your TV after a period of 1 to 99 minutes as shown below. The remote must be in TV mode to set a Sleep Timer. This feature works even if your TV does not have a sleep feature.

  • Page 11: Controlling Devices With Power On And Off

    Using Your Remote, cont. Controlling Devices with Separate Power On and Off Buttons Some GE, RCA and ProScan models require you to press the device button for more than one second to turn the device on and the ON•OFF button to turn the device off. Controlling Combo Devices Some Combo devices (e.g.

  • Page 12: Volume/Mute Control And Punch-Through

    Using Your Remote, cont. Volume/Mute Control and Punch- Through This remote lets you select which device Mode controls your Volume/Mute buttons. The remote is initially set for all device Modes to use their own Volume/Mute control if present. If the programmed code has no Volume/Mute operation of its own then those buttons will punch-through control to the TV Mode device without needing to change to TV Mode.

  • Page 13: Setting Any Mode For Its Own Volume/Mute

    Using Your Remote, cont. Setting any Mode to use its own Volume/Mute Control This routine can set any Mode to use only its own Volume/Mute control. Note - If your chosen Mode has no Volume/Mute functions of its own then the Volume/Mute buttons will do nothing. 1.

  • Page 14: Troubleshooting

    Troubleshooting Remote does not operate your product. • Press the device button of the product you want to control. • Program the remote with a new code. • Install new batteries. (You might have to reprogram your remote after installing new batteries.) •...
  • Page 15 90 Day Limited Warranty Jasco Products Company warrants this product to be free from manufacturing defects for a period of ninety days from the original date of consumer purchase. This warranty is limited to the repair or replacement of this product only and does not extend to consequential or incidental damage to other products that may be used with this unit.
  • Page 16 Jasco Products Company 311 N.W. 122nd Oklahoma City, OK 73114 Made in China Universal Remote Instruction Manual RM24906 RM24906...
