- Page 1 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector User’s Guide...
- Page 3 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector User’s Guide...
- Page 4 Note: Before using this information and the product it supports, read the information “Appendix F. Product warranties and notices” on page 49. First Edition (October 2000) © Copyright International Business Machines Corporation 2000. All rights reserved. US Government Users Restricted Rights – Use, duplication or disclosure restricted by GSA ADP Schedule Contract with IBM Corp.
-
Page 5: Table Of Contents
Contents Safety information . Appendix C. Using video mirroring . 43 About this book . . vii Appendix D. Projected image size . . 45 Installation and user’s guide . Appendix E. Help and service information Appendix A. Specifications and Appendix F. - Page 6 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
-
Page 7: Safety Information
Safety information Before installing this product, read the Safety Information. Antes de instalar este produto, leia as Informações de Segurança. Pred instalací tohoto produktu si prectete prírucku bezpecnostních instrukcí. Læs sikkerhedsforskrifterne, før du installerer dette produkt. Ennen kuin asennat tämän tuotteen, lue turvaohjeet kohdasta Safety Information. - Page 8 Antes de instalar este produto, leia as Informações sobre Segurança. Pred inštaláciou tohto zariadenia si pečítaje Bezpečnostné predpisy. Antes de instalar este producto lea la información de seguridad. Läs säkerhetsinformationen innan du installerar den här produkten. iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
-
Page 9: About This Book
About this book This manual contains instructions for setting up, using, maintenance and ® troubleshooting of the iL2120 IBM Value Data/Video Projector and the iL2220 IBM Conference Room Data/Video Projector. The manual is divided into two parts: Part 1: Setup guide This guide contains the product description and expanded installation instructions. - Page 10 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
-
Page 11: Installation And User's Guide
(DLP) technology, and feature an M1-DA connector for easy, built-in digital/analog and USB connectivity. They are easy to connect, easy to use, easy to transport, and easy to maintain. The iL2120 has native SVGA 800 x 600 resolution, the iL2220 has XGA 1024 x 768 resolution. The user-interfaces of the two products are identical;... - Page 12 Attention: This product contains a Metal Arc Lamp which contains Mercury. Dispose of it as required by local ordinances and regulations. Note: The contents of your shipping box may vary depending on the projector configuration you’ve ordered. iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
- Page 13 1 Projector and lens cap 4 Composite video cable 7 MI-DA analog computer cable 2 Soft carrying case 5 Audio cable 8 Power cord 3 User’s Guide, Quick Start card 6 Audio cable adapter 9 Remote control and multi-language online User’s Guide CD (available after 12/31/00) 1 Zoom ring...
- Page 14 For more information about image size, see Appendix D. 3. Make sure that the projector is unplugged and your computer is turned off. iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
- Page 15 Note: If you are connecting the projector to a computer, make sure that the distance between the computer and the projector is six feet or less. Connect the cables to the corresponding control panel by matching the icons. Reference the following two illustrations. 1 composite video 3 Audio in 5 Cable Wizard data interface...
- Page 16 1. Plug the end of the M1-DA analog computer cable marked A into the connector marked AD on the projector. 2. Plug the blue monitor end of the M1-DA analog computer cable into the video connector on your computer. iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
- Page 17 1 Audio cable 2 MI-DA analog computer cable 3 USB mouse Note: Many mobile computers do not automatically turn on their external video port when a secondary display device such as a projector is connected. See your computer manual for the command that activates the external video port.
- Page 18 (not a composite or S-video cable). See the previous pages for details on connecting this cable. 1 Composite video cable 2 Audio cable 3 Audio adapter iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
- Page 19 1 S-video cable 2 Audio cable 3 Audio adapter 3. Plug the white connector of the audio adapter’s into the left “audio out” connector on your video player. Plug the red connector of the adapter into the right “audio out” connector on the video player. 4.
- Page 20 (the computer considers the projector a Plug and Play monitor). 3. Turn on the lamp by pressing the lamp on/off button on the keypad. iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
- Page 21 v The fans start to run, and the Lamp LED on the top of the projector lights green, and the startup screen appears. It takes about one minute for the image to achieve full brightness. 4. If you connected a video player, turn it on. v The video image displays on the projection screen.
- Page 22 If you point the remote control at the projection screen, the distance to the screen and back to the projector must be less than or equal to 25 feet. For best results, point the remote control directly at the projector. iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
- Page 23 Note: If the remote control is inactive for several minutes, it “sleeps” to conserve battery life. Press any button except the disk mouse to reactivate the remote control. 1 Disk mouse 2 Right mouse button 3 Left mouse button Press anywhere on the edge of the disk mouse to move the cursor on the screen.
- Page 24 2 into position. If necessary, turn the leveling knob 1 (second illustration) at the rear of the projector to adjust the angle of the projected image. iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
- Page 25 Using the keypad and remote control buttons While the menus are displayed, the volume, source, and standby buttons on the keypad act as menu navigation buttons. See “Using the on-screen menus” on page 16 for details. menu source volume - volume + standby Installation and user’s guide...
- Page 26 Manual Tracking is not available until Auto Image is turned off). To open the on-screen menus, press the menu button on the keypad or remote control. This changes the volume, source, and standby buttons on the keypad iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
- Page 27 to menu navigation buttons. Press the buttons to move the cursor up, down, left, or right, or use the disk mouse on the remote control. To select a menu, move the cursor left or right to highlight the menu that you want. The drop-down menu is displayed.
- Page 28 Press the left mouse button to decrease the amount of color in the image. v Press the right mouse button to increase the amount of color in the image. Sharpness This setting adjusts the sharpness of a video image. iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
- Page 29 v Press the left mouse button to decrease the sharpness. v Press the right mouse button to increase the sharpness. Blank screen The Blank screen setting determines what color is displayed when there is no active source and when the projector is in standby. Click the left or right mouse button to change between blue and black.
- Page 30 To adjust the keystone, highlight Keystone, and then click the left or right mouse button. This option is available for computer sources displaying their native resolutions only, SVGA 800 x 600 for the iL2120 and XGA 1024 x 768 for the iL2220.
- Page 31 Resize This option works differently for computer and video sources. For computer sources, the Resize option automatically resizes the image by scaling it up or down. It affects computer images that are not in the projector native resolution. When Resize option is on, the projector makes the best fit of the image to the computer screen.
- Page 32 When Video standard is set to Auto, the projector attempts to select the video standard (NTSC, NTSC 4.43, PAL, PAL-M, PAL-N, PAL-60, or SECAM) automatically based on the input signal that it receives. (The video standard iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
- Page 33 options might vary depending on your region of the world.) If the projector is unable to detect the correct standard, the colors might not be displayed correctly or the image might appear broken. If this happens, manually select a standard by clicking the left or right mouse button and cycling through the standards.
- Page 34 You can display the on-screen menus in English, French, German, Spanish, Chinese or Japanese. v Move the cursor to the language you want, then click the left or right navigation button. The menus redraw immediately. iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
- Page 35 Status menu This is a read-only window for informational purposes. To display the status window, click Show status from the menu, and then click the left or right navigation button. To close the window, click the left or right navigation button. Display Audio Image...
- Page 36 2. Lightly wipe the cleaning cloth over the lens in a circular motion. 3. If you don not intend to use the projector immediately, replace the lens cap. iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
- Page 37 CAUTION: The following label indicates a hot surface nearby. Replacing the projection lamp WARNING: To avoid burns, allow the projector to cool for at least 30 minutes before you open the lamp module door. Never remove the lamp module while the lamp is operating.
- Page 38 Attention: This product contains a Metal Arc Lamp which contains Mercury. Dispose of it as required by local ordinances and regulations. iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
- Page 39 5. Loosen the two nonremovable screws on the outside of the module. CAUTION: Never operate with the lamp door open or removed. This disrupts the air flow and causes the projector to overheat. Installation and user’s guide...
- Page 40 Symptoms of low battery charge include erratic responses when you use the remote control and a reduced range of operation. Follow these steps to replace the batteries: iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
- Page 41 1. Turn the remote control face down in your hand. 2. Slide the battery cover off the end of the remote control. 3. Remove the old batteries and dispose of them in an environmentally proper manner. 4. Install two new AAA alkaline batteries. Make sure that you install each in the correct direction.
- Page 42 Problem: The image is too wide or narrow for the screen. v Adjust the zoom or projector placement. v Adjust the resolution of your video card if it’s greater than 1024 x 768. iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
- Page 43 Problem: The image is out of focus. v Turn the projection lens to focus the image. v Make sure that the projection screen is at least 5 feet (1.5 m) from the projector. v Check the projection lens to see if it needs cleaning. Problem: The image and menus are reversed left to right.
- Page 44 Make sure the lamp has not been in use for over 2500 hours. The lamp automatically shuts off at 2050 hours. See “Replacing the projection lamp” on page 27. iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
-
Page 45: Appendix A. Specifications And Accessories
Appendix A. Specifications and accessories This section contains the specifications and information for ordering accessories. Specifications The projector must be operated and stored within the temperature and humidity ranges specified. Temperature Operating 10 to 40° C (50 to 104° F) Non-operating -20 to 70°... - Page 46 There are many accessories available for your projector and new ones being added frequently. Please refer to http://www.infocus.com/ and select from the many accessories listed there for purchase. iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
-
Page 47: Appendix B. Portable And Mobile Computer Activation
Appendix B. Portable and mobile computer activation Many mobile computers do not automatically turn on their external video port when a projector is connected. Activation commands may be required. The following table lists activation commands. (If your computer is not listed or the given command does not work, refer to the computer documentation for the appropriate command.) On many mobile computers, the activation function key is labeled with an icon such as the following:... - Page 48 Dolch dip switch to CRT dip switch to LCD Epson dip switch to CRT dip switch to LCD Everex* setup screen option setup screen option For-A Ctrl-Alt-Shift-C Ctrl-Shift-Alt-L iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
- Page 49 Computer Key command to Key command to activate port deactivate port Fujitsu FN-F10 Gateway FN-F3 FN-F1/FN-F1 again FN-F3 FN-F1 simultaneous Grid* ** FN-F2, select auto or FN-F2 simultaneous Ctrl-Alt-Tab Ctrl-Alt-Tab Hitachi FN-F7 FN-F7 Honeywell FN-F10 FN-F10 Hyundai setup screen option setup screen option IBM 970* automatic...
- Page 50 FN-F5 FN-F5 setup screen option setup screen option Twinhead* FN-F7 FN-F7 FN-F5 FN-F5 automatic automatic WinBook Ctrl-Alt-F10 Ctrl-Alt-F10 Wyse software driven software driven Zenith** FN-F10 FN-F10 FN-F2 FN-F2 iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
- Page 51 Computer Key command to Key command to activate port deactivate port FN-F1 FN-F1 Zeos** Ctrl-Shift-D FN-F1 Ctrl-Shift-D FN-F1 * These manufacturers have models that automatically send video to the external video port when some type of display device is attached. ** These manufacturers offer more than one key command depending on the computer model.
- Page 52 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
-
Page 53: Copyright Ibm Corp
Appendix C. Using video mirroring Using video mirroring with a PowerBook computer When you turn on video mirroring (called SimulScan in newer PowerBook computers), the projector displays the same information that appears on a PowerBook built-in screen. When video mirroring is off, the projector operates like a separate display. - Page 54 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
-
Page 55: Appendix D. Projected Image Size
Appendix D. Projected image size Use the following graph and tables to help you determine projected image sizes. Table 1. Image size, width and height-maximum image size Distance to screen (feet) Diagonal (feet) Width (feet) Height (feet) 12.4 18.6 14.9 11.2 ©... - Page 56 Table 2. Image size, width and height-maximum image size Distance to screen (feet) Diagonal (feet) Width (feet) Height (feet) 10.0 15.0 12.0 iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
-
Page 57: Appendix E. Help And Service Information
Appendix E. Help and service information This section contains information on how to obtain online and telephone technical support. Online technical support Online technical support is available during the life of your product. Online assistance can be obtained through the Personal Computing Support Web site and the IBM Automated Fax System. - Page 58 Response time may vary depending on the number and nature of the calls received. Support 24 hours a day, 7 days a week Canada (Toronto only) 416-383-3344 Canada (all other) 1-800-565-3344 U.S.A. and Puerto Rico 1-800-772-2227 iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
-
Page 59: Appendix F. Product Warranties And Notices
Warranty affects any statutory rights of consumers that cannot be waived or limited by contract. If you have any questions, contact IBM or your reseller. Machine - IBM Data/Video Projectors iL2120, iL2220 Warranty period* - Three years * Contact your place of purchase for warranty service information. Some IBM Machines are eligible for on-site warranty service depending on the country where service is performed. - Page 60 Items Not Covered by Warranty IBM does not warrant uninterrupted or error-free operation of a Machine. Unless specified otherwise, IBM provides non-IBM machines WITHOUT WARRANTIES OF ANY KIND. iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
- Page 61 Any technical or other support provided for a Machine under warranty, such as assistance via telephone with “how-to” questions and those regarding Machine set-up and installation, will be provided WITHOUT WARRANTIES OF ANY KIND. Warranty Service To obtain warranty service for the Machine, contact your reseller or IBM. In the United States, call IBM at 1-800-772-2227.
- Page 62 3) SPECIAL, INCIDENTAL, OR INDIRECT DAMAGES OR FOR ANY ECONOMIC CONSEQUENTIAL DAMAGES (INCLUDING LOST PROFITS OR SAVINGS), EVEN IF IBM, ITS SUPPLIERS OR YOUR RESELLER IS INFORMED OF THEIR POSSIBILITY. SOME iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
- Page 63 Warranty affects any statutory rights of consumers that cannot be waived or limited by contract. If you have any questions, contact IBM or your reseller. Machine - IBM Data/Video Projectors iL2120, iL2220 Warranty period* - Three years * Contact your place of purchase for warranty service information. Some IBM Machines are eligible for on-site warranty service depending on the country where service is performed.
- Page 64 When warranty service involves the exchange of a Machine or part, the item IBM or your reseller replaces becomes its property and the replacement becomes yours. You represent that all removed items are genuine and iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
- Page 65 unaltered. The replacement may not be new, but will be in good working order and at least functionally equivalent to the item replaced. The replacement assumes the warranty service status of the replaced item. Any feature, conversion, or upgrade IBM or your reseller services must be installed on a Machine which is 1) for certain Machines, the designated, serial-numbered Machine and 2) at an engineering-change level compatible with the feature, conversion, or upgrade.
- Page 66 Specified Operating Environment, improper maintenance by you, or failure caused by a product for which IBM is not responsible. iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
- Page 67 Limitation of Liability: The following is added to this Section: Where IBM is in breach of a condition or warranty implied by the Trade Practices Act 1974, IBM’s liability is limited to the repair or replacement of the goods or the supply of equivalent goods. Where that condition or warranty relates to right to sell, quiet possession or clear title, or the goods are of a kind ordinarily acquired for personal, domestic or household use or consumption, then none of the limitations in this paragraph apply.
- Page 68 The warranty for an IBM Machine covers the functionality of the Machine for its normal use and the Machine’s conformity to its Specifications. The following paragraphs are added to this Section: The minimum warranty period for Machines is six months. iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
- Page 69 In case IBM or your reseller are unable to repair an IBM Machine, you can alternatively ask for a partial refund as far as justified by the reduced value of the unrepaired Machine or ask for a cancellation of the respective agreement for such Machine and get your money refunded.
- Page 70 The following is added to the end of this Section: IBM’s entire liability and your sole remedy, whether in contract or in tort, in respect of any default will be limited to damages. iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
- Page 71 NORTH AMERICA CANADA: Warranty Service: The following is added to this section: To obtain warranty service from IBM, call 1-800-565-3344. In Toronto, call 416-383-3344. UNITED STATES OF AMERICA: Warranty Service: The following is added to this section: To obtain warranty service from IBM, call 1-800-772-2227. Notices This publication was developed for products and services offered in the U.S.A.
- Page 72 Properly shielded and grounded cables and connectors must be used in order to meet FCC emission limits. IBM is not responsible for any radio or television interference caused by using other than recommended cables and connectors iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
- Page 73 or by unauthorized changes or modifications to this equipment. Unauthorized changes or modifications could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 74 IBM non accetta responsabilità alcuna per la mancata conformità alle normative di protezione dovuta a modifiche non consigliate al prodotto, compresa l’installazione di schede e componenti di marca diversa da IBM. iL2120 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
- Page 75 Le prove effettuate sul presente prodotto hanno accertato che esso rientra nei limiti stabiliti per le le apparecchiature di informatica Classe A ai sensi del CISPR 22/Norma Europea EN 55022. I limiti delle apparecchiature della Classe A sono stati stabiliti al fine di fornire ragionevole protezione da interferenze mediante dispositivi di comunicazione in concessione in ambienti commerciali ed industriali.
- Page 76 IBM Value Data/Video Projector, iL2220 Conference Room Data/Video Projector: User’s Guide...
- Page 78 Part Number: 33L3381 Printed in the United States of America on recycled paper containing 10% recovered post-consumer fiber. (1P) P/N: 33L3381...
