Compliance Information For U.S.A. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
To meet your future needs, and to receive any additional product information as it becomes available, please register your product on the Internet at: www.viewsonic.com. The ViewSonic Wizard CD-ROM also provides an opportunity for you to print the registration form, which you may mail or fax to ViewSonic. For Your Records...
Congratulations! Thank you for choosing ViewPoP Digital Audio player! Please read this User Guide carefully beforehand to ensure proper using and operation. Precaution To avoid possible traffic accidents To avoid possible damages to the player please do not use the player while walking, keep the player clean and away from places with driving, riding or operate other heat source, direct sunlight, dirts, high humidty...
Note: To avoid program failure when using the player as the removable disk, please follow the proper document management and operation method to save and export documents, and never disconnect the player from PC abruptly during downloading, uploading and formatting. Recommended minimum system requirement Pentium 133MHz or above, at least 64 MB RAM Microsoft Window 98, ME, 2000, XP...
Connect the MP3 player to the USB interface of PC, and then insert the CD-ROM came with the system to the CD-ROM drive. Select “ViewSonic” installation folder, and then click “step up .exe”. The following image appears and is ready to install the program. Then, click "Next".
Page 13
After accepting the agreement and selecting the installation directory, the PC will finish the installation automatically. Click "Next" in each step until "Finished" appears. If the USB device can not display as illustrated above, please uninstall the USB driver from the system completely, and then reinstall again.
Connecting and downloading Connecting PC Before operation, please verify the player is turned off, and connect the PC and MP3 player using the provided USB cable. Use the USB interface to download MP3 music files from PC to the player. Data transmitting During data transmitting, please do not disconnect the player from PC.
Page 15
Click "OK" button. After the "Safe to Remove Hardware" window appears, the player can now be disconnected from PC safely. Never unplug the USB cable during data transmitting to avoid any failure to the Player; after data transmitting, please do not disconnect the player from PC until "Device now be safely removed"...
Basic Operation Buttons and functions 1) Microphone/ MIC 2) Menu button/ MENU / Last, Fast backward/ Next, Fast forward 3) Volume down/V- 4) Volume up/V+ 5) Play / Pause Stop 6) USB interface 7) HOLD button 8) Line In interface 9) Earphone jack Screen instruction...
Power on/ off operation From power off mode, press the / button for 2 seconds, the player will power on with the “ViewSonic” displays, and then the main menu appears with "Playing Music" displays on the screen. Press the MENU button to enter the MP3 standby mode;...
How to use the MP3 player Playing MP3 files a) From MP3 standby mode, press the / button to play MP3 music as well as pause and resume playing. Play Pause b) From play or pause mode, press the / button for 2 second to return to MP3 standby mode, and press / button again to repeat step "a)".
FM Radio receiver-Playing FM a) From the play mode or standby mode, press the MENU button for 2 seconds to enter the main menu, and then push the MENU button to select FM mode and press the MENU to select the FM radio receiver, and press the button again to enter. The player will play the default channel.
Recording FM From FM playing mode, press the MENU button to enter the FM main menu, and press MENU button to select the FM recording function, and then press the MENU button to enter the FM recording mode, the recorded FM music will be saved in WAV format. Press the MENU button to finish recording and save and then listen to the record under...
Setting Voice Mode a) From MP3 mode or voice standby mode, press the MENU button for 2 seconds to enter the main menu setting, and push the MENU button to select voice mode, and then press the MENU button to enter the voice playing mode to start recording, during which you can press / button to pause and resume, and press the MENU...
c) From voice standby or play mode, press the MENU button to select last or next voice file. d) From the STOP status, press the MENU button to effectively find and play the desired music. e) From Play mode, push and hold MENU button to fast backward or forward this music.
Function Setting Setting EQ mode From MP3 mode or voice standby mode, press the MENU button for 2 seconds to enter the main menu, and press the MENU button to select the setting menu. Press the MENU button to enter the setting menu. Press the MENU button to enter the EQ mode setting, and press the...
Setting Playing Mode From MP3 playing mode, press the MENU button for 2 seconds to enter the main menu. Press the MENU button to select the setting menu, and press again to enter. Press the MENU button to select the play mode, and then press the MENU button to enter the play mode selection.
Setting Contrast From MP3 mode or voice standby mode, press MENU button for 2 seconds to enter the main menu, and press the MENU button to select the setting menu, and press again to enter, then press the MENU button to select contrast setting mode, and press again to enter, and then press the MENU button to adjust the contrast of LCD, after which...
Setting Power From MP3 mode or voice standby mode, press MENU button for 2 seconds to enter the main menu, and press the MENU button to select the setting menu, and press again to enter, then press the MENU button to select automatic power off mode, and press again to enter, and then press the MENU button to select the automatic power off time, which...
Setting language From MP3 mode or voice standby mode, press MENU button for 2 seconds to enter the main menu, and push the MENU button to select setting menu, and then press the MENU button to enter the setting menu, then press the MENU button to select language setting, and press again to enter.
Exit From MP3 mode or voice standby mode, after selecting the exit setting, it will return to the upper menu. Note: From setting, pres / button can exit setting instantly. Variable speed playing function From MP3 mode or voice standby mode, press the MENU button for 2 seconds to enter the tool function setting mode and press button to select the variable speed playing mode, and then you can press the MENU button to enter the speed changing playing mode.
Music Preview From MP3 mode or voice standby mode, press the MENU button for 2 seconds to enter the main menu, and press the MENU button to select browsing mode, and then press button to select music browsing, then you can press the MENU button to save the select and begin browsing, after which you can press the...
The Read only music can not be deleted! Folder function From MP3 mode or voice standby mode, press the MENU button for 2 seconds to enter the main menu setting, and then press the MENU button again to enter the folder function setting.
A-B Play Mode From MP3 or voice play mode: 1) Press MENU button to select start point A; 2) Press MENU button to select end point B, MP3 will play between A-B. 3) Press MENU C button again to cancel setting and resume playing MP3 or voice. Lock function Under any mode, you can push the HOLD switch in the direction of arrow, a lock icon will appear on the LCD and all the buttons will be nonfunctional;...
Plug the Player into the USB interface of PC, relative icons appears on the LCD screen. The LCD screen may display relative icon during data transmitting. For software upgrading and formatting the removable disk, please refer to the website of ViewSonic. Troubleshooting Symptom...
Page 33
The MP3 files currently are compressed with different compress individually rate and format, while this Player compressed Download the standard MP3 files again. supports the standard compressed MP3 files can MP3 only, please do not adopts layer not be played one or two compression.
電磁相容資訊 美國符合 本設備已通過測試,並符合 FCC 規則第 15 部分 B 級數位裝置的限制。這些限制旨在提供合理的保 護,以防在一般住宅環境繁造成有害干擾。本設備會產生、使用和發射無線電頻率能量,因此若沒 有依照指示安裝及使用,可能會對無線電通訊產生有害的干擾。然而,並不保證在特定安裝方式下 不會產生干擾。如果本設備對無線電或電視收訊產生有害干擾,( 可透過開、關設備判定),建議使 用者嘗試以下方法消除干擾: 重新調整或放置接收天線。 增加設備與無線接收設備的距離。 將本設備連接到與接收器不同的電源插座上。 請向經銷商或具有經驗的無線電/ 電視技術人員請求幫助。 加拿大符合 此項B級數位設備符合加拿大干擾源設備規範的所有要求。 Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. 歐洲國家符合- CE 合格 本裝置符合依 92/31/EEC 及 93/68/EEC 第 5 條有關「電磁相容性」修訂的 EEC 指 令...
安裝說明 爲 Windows 98 安裝驅動程式。(在 Windows ME 及以上版本不需要安裝驅動程式) 將 MP3 隨身聽與電腦的 USB 連接埠連接,將附贈的光碟放入 CD-ROM。 選擇“ViewSonic”安裝檔案,點擊“step up .exe”。電腦將出現以下圖片。並準備 安裝程式。點擊“下一步”。...
Page 40
同意條約並選擇安裝路徑後,電腦將自動完成安裝程式。點擊“下一步”直到電腦 顯示“安裝完成”。 如果 USB 驅動器沒有按照上面所說的方式顯示,請移除所安裝的 USB 驅動, 重新安裝。...
FM 收音機- FM 播放 a) 在播放或待機模式下,按 MENU 鍵 2 秒進入主功能表,推動 MENU 鍵選擇 FM 收音機,按下 MENU 鍵進入該模式,此時將在預設頻道下播放。最多可預設 30 個電台 b) 在 FM 播放模式下,可按 / 鍵來切換已儲存的頻道。可再擴充儲存至 40 個電台 頻道 c) 在 FM 播放模式下,推動 MENU 鍵進行手動調節頻率,頻率將以 0.1MHZ 的調整 幅度增加或減少;調至理想的頻道後,按 MENU 鍵 2 秒進入 FM 主功能表。推動 MENU 鍵選擇儲存電臺功能,按下...
FM 錄音 FM 播放模式下,按 MENU 鍵進入 FM 主功能表,推動 MENU 鍵選擇 FM 錄音功 能。按下 MENU 鍵進入 FM 錄音模式,FM 音樂將以 WAV 格式錄製下來,按 MENU 鍵結束 FM 錄音並將其儲存,之後可以在 FM 播放錄音選項繁下聆聽。 FM 功能設置 在 FM 播放模式下,按 MENU 鍵進入 FM 主功能表功能設定模式。 推動 MENU 鍵可以選擇:返回播放音樂、播放 FM 錄音檔、FM 錄音、儲存電台、 刪除電台、自動搜索、返回...
b) 錄音播放模式的選項有:標準模式、單曲循環、全部循環、隨機播放、隨機循環。 音場模式主功能表 標準模式 單曲循環 全部循環 隨機循環 全部隨機循環 c) 錄音待機或播放模式下,按 MENU 鍵來選擇上一個或下一個語音繁件。 d) 在 STOP 狀態下,推動 MENU 鍵,即可快速有效的搜索到你所需要的曲目播放。 e) 在錄音播放模式下,長時間推動 MENU 鍵,將在本曲目繁快退或快進。 f) 在語音待機模式下,按下 鍵 2 秒鐘將進入電源待機模式。 MP3 轉錄功能 在待機或播放模式下,按 MENU 鍵 2 秒進入主功能表設定。 推動 MENU 鍵選擇 LINE IN 錄音模式,按下 MENU 鍵進入 LINE IN 錄音模式並 開始錄音。...
隨機播放 隨機循環 對比度設定 在 MP3 播放模式或錄音待機模式下,按下 MENU 鍵 2 秒進入主功能表,推動 MENU 鍵選擇設定功能表,按下 MENU 鍵進入設定功能表。推動 MENU 鍵選 擇對比度設定模式,按下 MENU 鍵進入對比度模式,推動 MENU 鍵調節 LCD 對比度。按下 MENU 鍵儲存剛選擇的設置。按 / 鍵返回當前模式。 容量查看 在 MP3 播放模式或錄音待機模式下,按下 MENU 鍵 2 秒, 推動 或 鍵進“關於”, 查看本機總容量與可用容量。按 鍵返回當前模式。...
電源設定 在 MP3 播放模式或語音待機模式下,按下 MENU 鍵 2 秒進入主功能表, 推動 MENU 鍵選擇設置功能表 , 按下 MENU 鍵進入設定功能表 。 推動 MENU 鍵 選擇自動關機模式,按下 MENU 鍵進入電源設定模式,推動 MENU 鍵選擇自動 關機時間,自動關機時間的選項有: 2 分鐘、10 分鐘、30 分鐘、關閉。按下 MENU 鍵儲存剛剛選擇的關機時間。按 / 鍵返回當前模式。 屏保時間 在 MP3 播放模式或語音待機模式下,按下 MENU 鍵 2 秒進入主功能表, 推動 MENU 鍵選擇設定功能表,按下...
語言設定 在 MP3 播放模式或錄音待機模式下 , 按下 MENU 鍵 2 秒進入主功能表, 推動 MENU 鍵選擇設置功能表,按下 MENU 鍵進入設定功能表,推動 MENU 鍵選擇語言 設置,按下 MENU 鍵進入語言設定。語言有:英繁、繁繁簡繁、繁繁繁繁、法繁、 西班牙繁、丹麥繁、德繁、義大利繁、荷蘭繁。按下 MENU 鍵儲存剛剛選擇的語言。 按 / 鍵返回當前模式。 錄音設定 在 MP3 播放模式或錄音待機模式下,按下 MENU 鍵 2 秒進入主功能表, 推動 MENU 鍵選擇設定功能表,按下 MENU 鍵進入設定功能表。推動 MENU 鍵選擇錄音頻率設置...
电磁相容信息 美国法律 依 FCC 规则的第十五章,本设备经测试,符合 B 级数码设备的限制标准。这些限制标准用于确认 电气设备不会对居室中安装的其它设备产生有害干扰。本设备会产生、使用和发射射频能量,因此 若没有依照指示安装及使用,可能会对无线电通讯产生有害的干扰。然而,这并不保证该设备在特 定安装过程中不会发生这种干扰。如果该设备对收音机或电视机产生有害的干扰( 这可以通过设备 的开、关来判定),用户可以尝试以下的方法消除干扰: 重新调整或放置接收天线。 增加设备与无线接收设备之间的间距。 将该设备连接到与无线设备不同的另一插座上。 洽询销售商或具有无线电/ 电视经验的技术人员请求帮助。 加拿大法律 此项B级数位设备符合加拿大干扰源设备规范的所有要求。 Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. 欧洲国家- CE 达标 本装置遵守依 92/31/EEC 及 93/68/EEC 条款 5 有关 「电磁兼容性」 修订的 EEC 指令 89/336/EEC,以及依...
安装说明 为 Windows 98 安装驱动程序。(在 Windows ME 及以上版本不需要安装驱动程序) 将 MP3 播放机与在 PC 机的 USB 口连接,将附赠的光盘放入 CD-ROM。 选择“ViewSonic”安装文件夹,点击“step up .exe”。电脑将出现以下图片。并准备 安装程序。点击“下一步” 。...
Page 65
同意条约并选择安装路径后,电脑将自动完成安装程序。点击“下一步”直到电脑 显示“安装完成” 。 如果 USB 驱动器没有按照上面所说的方式显示, 请卸载所安装的 USB 驱动, 重新安装。...
连接与下载 与 PC 机连接 在操作前,请确认播放机电源已关闭,将附赠的 USB 连接线接头插入计算机,另外 一头连接到 MP3 播放机。 MP3 播放器连接到计算机 USB 端口下载 MP3 歌曲到 MP3 播放器。 数据传输中 注:本机最多存储 190 个 MP3 格式文件。最多存储 120 个 VOICE 格式文件。 在拷贝文件时,请不要强制中断本产品与计算机的 USB 连接。如果在档案 传输时,USB 连接被强制中断,当前正在传输的档案可能损坏。 移出 USB 端口装置 用鼠标双击任务栏上的图标安全移除硬件: 在安全移除硬件窗口画面上,选取“USB 大容量储存装置”项,然后点击“stop” 按钮。屏幕出现“ViewPop MP3 Digital Audio Player”窗口,如图所示。...
Page 67
点击“OK”按钮。当屏幕出现“safe to Remove Hardware”窗口后,就可以从 PC 机 中安全分离。 在与 PC 机有数据传输时,请不要中途拔出 USB 连接线,这样可能会 对播放 机造成不良的后果;须数据传输完毕,PC 机出现“设备可以安全拔 出”,才可 以与 PC 机正常分离;在进行 USB 功能操作时,其它按键功能无 效。 如果某些错误操作导致程序丢失或出现 I/O 错误提示, 不能开机,请参考疑难 排解部分。...
FM 收音机- FM 播放 a) 在播放或待机模式下,按 MENU 键 2 秒进入主菜单,推动 MENU 键选择 FM 模式,按下 MENU 选择 FM 收音机模式,按下 MENU 键进入该模式,此时将 在缺省频道下播放。 b) 在 FM 播放模式下,按 / 键来切换已储存的频道。 c) 在 FM 播放模式下,推动 MENU 键进行手动调节频率,频率将以 0.1MHZ 的调整 幅度增加或减少;调至理想的频道后,按 MENU 键 2 秒进入 FM 主菜单。推动 MENU 键选择储存电台功能,按下...
FM 录音 FM 播放模式下, 按 MENU 键进入 FM 主菜单, 推动 MENU 键选择 FM 录音功能。 按下 MENU 键进入 FM 录音模式,FM 音乐将以 WAV 格式录制下来,按 MENU 键结束 FM 录音并将其储存,之后可以在 FM 播放录音选项中聆听。 FM 功能设置 在 FM 播放模式下,按 MENU 键进入 FM 主菜单功能设置模式。 推动 MENU 键可以选择:返回播放音乐、播放 FM 语音、FM 录音、储存电台、删 除电台、搜索电台、返回...
b) 语音播放模式的选项有:标准模式、单曲循环、全部循环。 语音播放模式主菜单 标准模式 单曲循环 全部循环 随机循环 全部随机循环 c) 语音待机或播放模式下,按 MENU 键来选择上一个或下一个语音文件。 d) 在 STOP 状态下,推动 MENU 键,即可快速有效的搜索到你所需要的曲目播放。 e) 在语音播放模式下,长时间推动 MENU 键,将在本曲目中快退或快进。 f) 在语音待机模式下,按下 键 2 秒钟将进入电源待机模式。 MP3 直录功能 在待机或播放模式下,按 MENU 键 2 秒进入主菜单设置。 推动 MENU 键选择 LINE IN 录音模式, 按下...
电源设置 在 MP3 播放模式或语音待机模式下, 按下 MENU 键 2 秒进入主菜单,推动 MENU 键选择设置菜单,按下 MENU 键进入设置菜单。推动 MENU 键选择自动关机模 式,按下 MENU 键进入电源设置模式,推动 MENU 键选择自动关机时间,自动 关机时间的选项有:2 分钟、10 分钟、30 分钟、关闭。按下 MENU 键储存刚刚选择 的关机时间。按 / 键返回当前模式。 屏保设置 在 MP3 播放模式或语音待机模式下, 按下 MENU 键 2 秒进入主菜单,推动 MENU 键选择设置菜单,按下 MENU 键进入设置菜单。推动 MENU 键选择背光设置模 式,按下...
语言设置 在 MP3 播放模式或语音待机模式下,按下 MENU 键 2 秒进入主菜单, 推动 MENU 键选择设置菜单,按下 MENU 键进入设置菜单,推动 MENU 键选择语言设置, 按下 MENU 键进入语言设置。语种有:英文、中文简体、中文繁体、法文、西班牙 文、 丹麦文、 德文、 意大利文、 荷兰文。 按下 MENU 键储存刚刚选择的语言。 按 键返回当前模式。 录音设置 在 MP3 播放模式或语音待机模式下, 按下 MENU 键 2 秒进入主菜单,推动 MENU 键选择设置菜单,按下 MENU 键进入设置菜单。推动 MENU 键选择录音频率设 置。...
