table travel
the table travels in two directions and is con-
trolled by handwheels, as illustrated in figure 23:
•
X-axis (longitudinal)
•
y-axis (cross)
X-Axis or Longitudinal Travel
(Left & Right)
figure 23. possible directions of table travel.
Graduated Dials
the handwheels have graduated dials that are
used to determine table movement in 0.001" incre-
ments, with one full revolution equalling 0.100".
rotate graduated dial to a relative starting point
(see figure 24).
graduated dial
figure 24. graduated dial location.
-24-
X-axis handwheel
tool Needed
hex Wrench 5mm .............................................. 1
to use X-axis handwheel:
1.
Y-Axis or
Cross Travel
(In & Out)
2.
3.
y-axis handwheel
the saddle does not have limit stops. to move
the table along the y-axis, loosen the y-axis
table locks shown in figure 25, then use the
handwheel in front of the table in the same man-
ner as the X-axis handwheel.
loosen both X-axis table locks shown in
figure 25.
Note: To readjust positioning of table locks,
pull out and rotate.
table stops
X-axis
table locks
figure 25. X- and y-axis table travel locks.
position table stops along front of table to
restrict table travel.
adjust X-axis graduated dial to zero, then use
handwheel to move table.
Model G0758 (Mfd. Since 2/14)
Qty
y-axis
table locks
