Bosch Divar 700 Series Installation And Operation Manual

Divar 700 series digital hybrid hd recorder / digital network hd recorder
Hide thumbs Also See for Divar 700 Series:
Table of Contents

Advertisement

Quick Links

See also: Operating Manual
Divar 700 Series
Digital Hybrid HD Recorder / Digital Network HD Recorder
en
Installation and Operation manual

Advertisement

Table of Contents
loading

Related Manuals for Bosch Divar 700 Series

Summary of Contents for Bosch Divar 700 Series

  • Page 1 Divar 700 Series Digital Hybrid HD Recorder / Digital Network HD Recorder Installation and Operation manual...

  • Page 3: Table Of Contents

    Divar 700 Series Table of Contents | en Table of Contents Safety Safety precautions Important safety instructions Important Notices FCC and UL Bosch notices Introduction Digital video recorder for surveillance applications 2.1.1 Versions 2.1.2 Software 2.1.3 Firmware upgrades 2.1.4 Manuals 2.1.5...
  • Page 4 | Table of Contents Divar 700 Series Keyboard connections 4.10 Ethernet connection(s) 4.11 RS485 port 4.12 Biphase port 4.13 USB connectors 4.14 External alarm I/O connection 4.15 Malfunction relay 4.16 Power supply 4.17 Maintenance Operating instructions Front panel controls 5.1.1...
  • Page 5 Divar 700 Series Table of Contents | en 6.1.3 Time Server Video & Audio 6.2.1 Analog Channels 6.2.2 IP Channels 6.2.3 Bitrates tab Schedule 6.3.1 Setting the dynamic characteristics 6.3.2 Schedule 6.3.3 Exceptions Recording 6.4.1 Normal 6.4.2 Contact 6.4.3 Text 6.4.4...
  • Page 6 | Table of Contents Divar 700 Series 6.12.2 6.12.3 Serial ports 6.12.4 Licenses 6.12.5 Logging Menu default values Quick install menu defaults Monitor view settings defaults Configuration menu defaults Technical specifications Electrical 8.1.1 Mechanical 8.1.2 Environmental 8.1.3 Electromagnetic and Safety 8.1.4...

  • Page 7: Safety

    Divar 700 Series Safety | en Safety Safety precautions DANGER! High risk: This symbol indicates an imminently hazardous situation such as "Dangerous Voltage" inside the product. If not avoided, this will result in an electrical shock, serious bodily injury, or death.
  • Page 8 17. Attachments, changes or modifications - Only use attachments/accessories specified by the manufacturer. Any change or modification of the equipment, not expressly approved by Bosch, could void the warranty or, in the case of an authorization agreement, authority to operate the equipment.

  • Page 9: Important Notices

    This device is intended for the use in public areas only. U.S. federal law strictly prohibits surreptitious recording of oral communications. Disposal - Your Bosch product was developed and manufactured with high-quality material and components that can be recycled and reused. This symbol means that electronic and electrical appliances, which have reached the end of their working life, must be collected and disposed of separately from household waste material.
  • Page 10 SELV - All the input/output ports are Safety Extra Low Voltage (SELV) circuits. SELV circuits should only be connected to other SELV circuits. Video loss - Video loss is inherent to digital video recording; therefore, Bosch Security Systems cannot be held liable for any damage that results from missing video information. To minimize the risk of lost digital information, Bosch Security Systems recommends multiple, redundant recording systems, and a procedure to back up all analog and digital information.

  • Page 11: Fcc And Ul

    Divar 700 Series Safety | en FCC and UL FCC & ICES Information (U.S.A. and Canadian Models Only) This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 12: Bosch Notices

    REGARDING THE PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING- RELATED FUNCTIONS OF THIS PRODUCT. Bosch notices Copyright This manual is the intellectual property of Bosch Security Systems and is protected by copyright. All rights reserved. Trademarks All hardware and software product names used in this document are likely to be registered trademarks and must be treated accordingly.

  • Page 13: Introduction

    Introduction Digital video recorder for surveillance applications The Divar 700 Series is a video recording system that records multiple camera signals while simultaneously providing live multiscreen viewing and playback. The unit has comprehensive search and playback facilities for viewing stored video. Once configured, all recording takes place in the background without requiring operator intervention.

  • Page 14: Software

    An SDK (software development kit) is available to integrate the unit into third party management software. 2.1.3 Firmware upgrades Firmware upgrades are released periodically. Check the Bosch Security website for the latest version. Note: Whenever the Divar 700 is upgraded to a newer software version, any saved configuration backup file exported from the older version of the software will no longer be useable with the new software.

  • Page 15: On-Screen Help

    If any items are missing, notify your customer service representative or Bosch Security Systems sales representative. The shipping carton is the safest container in which to transport the unit. Save it and all packing materials for future use.

  • Page 16: Installation Environment

    Divar 700 Series Installation environment 2.3.1 Mounting The Divar 700 Series is supplied as a desktop unit. If desired, the unit can be rack mounted using the rack mounting kit supplied with the unit. 2.3.2 Ventilation Ensure that the location planned for the installation of the unit is well ventilated. Take note of the locations of the cooling vents in the unit's enclosure and ensure that they are not obstructed.

  • Page 17: Quick Install

    10. Connect an Intuikey keyboard to the KBD in socket and connect the terminator (supplied with the keyboard) to the KBD out socket. 11. Connect a Bosch pan/tilt/zoom control unit to the Biphase port (via the 15-pole D-type connector board).

  • Page 18: First-Time Use

    | Quick install Divar 700 Series First-time use The unit first determines if camera inputs are PAL or NTSC and selects the output mode for the monitor. If only IP cameras are connected, the system defaults to PAL. The unit starts with a multiscreen display.

  • Page 19: Quick Install Menu

    Divar 700 Series Quick install | en Quick install menu The Quick install menu contains four tabs: International, Network, Schedule, and Recording. Navigate through these tabs using Back and Next. Click Undo to cancel changes made in the active tab. Click Close to exit the Quick install menu. Changing Quick install settings overwrites customized settings.

  • Page 20: Schedule

    | Quick install Divar 700 Series 3.3.2 Schedule Figure 3.3 Quick install menu - Schedule The currently active weekly schedule is shown. Each color represents an available profile: – Yellow - Profile 1 – Dark blue - Profile 2 –...

  • Page 21: Recording

    Divar 700 Series Quick install | en 3.3.3 Recording Figure 3.4 Quick install menu - Recording Set the Normal recording Resolution, Quality, and Frame rate for each profile in the table. Set the Alarm and Motion recording Resolution, Quality, and Frame rate. These settings are set for all profiles.

  • Page 22: Network

    | Quick install Divar 700 Series 3.3.4 Network Figure 3.5 Quick install menu - Network Fill in the settings that control the behavior of the unit with respect to a network. DVR name — Enter a unique DVR name to be used in the network.

  • Page 23: Hardware Setup

    Divar 700 Series Hardware setup | en Hardware setup This chapter contains detailed information about the hardware installation and connection of external equipment to the unit. The connector types and their pin signals are described. Most of the connectors are located at the rear panel of the unit. For convenience, a USB port is located on the front of the unit to connect a mouse or memory device.

  • Page 24: Hard Disk Installation

    DVR. Note: Only genuine Bosch hard disks will work in the Divar 700 Series. See the Bosch website or contact your local Bosch representative for available hard disks.
  • Page 25 Divar 700 Series Hardware setup | en Placing a hard disk Figure 4.4 Placing a hard disk Locate the first empty hard disk bay. It is recommended to install the disks in order from one to four, as labeled. (Note that disks 3 and 4 are mounted in a double bay.) Unscrew the two torx T10 screws securing the selected bay.

  • Page 26: Camera Connections

    | Hardware setup Divar 700 Series Camera connections On hybrid units, connect cameras to the Video in connectors on the back of the unit using 75 ohm video coaxial cables with BNC connectors. Optionally, this signal can be looped through to other equipment via the corresponding Video out connector.

  • Page 27: Audio Connections (Hybrid Version Only)

    A single monitor can be connected on the network version. Note: HD models provide HD recording but not HD local display. Use the Bosch Video Client to display live HD cameras and SD cameras with Main Profile streams, and recorded video from these cameras.

  • Page 28: Cvbs

    | Hardware setup Divar 700 Series 4.6.2 CVBS Connect the unit to CCTV monitors using 75 ohm video coaxial cables with BNC connectors. The unit provides a 1 Vpp CVBS signal. If the monitor has a loop-through connection without using the loop-through output, then select the 75 ohm impedance setting on the monitor.

  • Page 29: Rs232 Com Port Connections

    Divar 700 Series Hardware setup | en RS232 COM port connections The RS232 COM ports are used to connect a PC to the unit for service purposes. Use a null- modem cable to connect the serial port of the PC to the unit. The Baud rate can be selected in the menu system.

  • Page 30: Keyboard Connections

    Divar 700 Series Keyboard connections The keyboard input and output connectors are used to connect a Bosch Intuikey keyboard to one or more units. For one unit, connect the keyboard to the KBD in connector. For more units, connect a cable between the KBD out connector of the first unit and the KBD in connector of the following unit.

  • Page 31: Ethernet Connection(S)

    Divar 700 Series Hardware setup | en Pin number Signal No connection System ground Keyboard minus line Keyboard plus line System ground No connection Table 4.3 Keyboard out - RJ11 socket (KBD out) 4.10 Ethernet connection(s) The standard RJ-45 Ethernet socket is used to connect the unit directly to a PC, IP camera, or to a network.

  • Page 32: Biphase Port

    | Hardware setup Divar 700 Series - | + | G N0 | C | NC N0 | C | NC Figure 4.15 RS485 connector Signal name Pin number Description TX - Data transmission TX + Data transmission Shield Table 4.5 RS485 pin definition...
  • Page 33 Divar 700 Series Hardware setup | en BIPHASE SHIELD CTRL 1 SHIELD CTRL 2 SHIELD CTRL 3 SHIELD CTRL 4 SHIELD CTRL 5 SHIELD Figure 4.16 Biphase port connector and connection board Signal name Pin number Description Code 1 - Biphase control ch.

  • Page 34: Usb Connectors

    | Hardware setup Divar 700 Series 4.13 USB connectors Four USB connectors are located at the rear panel of the unit. For convenience, one USB port is located on the front of the unit to connect a mouse or memory device.
  • Page 35 Divar 700 Series Hardware setup | en ALARM I/O Figure 4.18 External alarm input and output connector and connection board Bosch Security Systems Installation and Operation manual F.01U.246.471 | v3.4 | 2011.06...

  • Page 36: Malfunction Relay

    | Hardware setup Divar 700 Series Signal name Pin number Description Alarm_in_1 Alarm input 1 Alarm_in_2 Alarm input 2 Alarm_in_3 Alarm input 3 Alarm_in_4 Alarm input 4 Alarm_in_5 Alarm input 5 Alarm_in_6 Alarm input 6 Alarm_in_7 Alarm input 7...

  • Page 37: Power Supply

    Divar 700 Series Hardware setup | en 4.16 Power supply Power is supplied to the unit via the IEC-style socket. For security reasons, the unit has no on/ off switch. This means that the unit is always powered as long as the power cable from the unit is connected to a live power socket.

  • Page 38: Operating Instructions

    | Operating instructions Divar 700 Series Operating instructions These instructions explain the purpose of the front panel keys. The functions available can be limited by setting passwords. Some functions may also require a software license. An administrator has access to many more functions in the menu.
  • Page 39 Divar 700 Series Operating instructions | en OSD key – press to view date/time and camera information, date/time only, or none Search key – press to open the date/time search menu to look for recorded images PTZ key – enables either pan/tilt or pan/zoom modes Freeze key –...

  • Page 40: Indicators

    | Operating instructions Divar 700 Series Stop key – while in playback mode, press to return to live mode Note: IP camera numbering starts at 9 on an 8-channel hybrid model and at 17 on a 16-channel hybrid model. So on a 16-channel hybrid unit with IP cameras, camera key 1 selects analog camera 1 and, when pressed again, IP camera 17.

  • Page 41: Viewing Pictures

    Divar 700 Series Operating instructions | en Viewing pictures The hybrid version has two monitor outputs, A and B. The way in which these monitors display pictures depends on how the system is configured. When an alarm or motion input is detected, the camera picture with the Alarm/Motion indicator can be displayed on monitor A, B, or both.
  • Page 42 | Operating instructions Divar 700 Series Multiscreen To view different multiscreen displays on monitor A or B: Press the multiscreen key. – A multiscreen display of camera pictures appears on the active monitor. – The camera keys of the selected cameras light (green).

  • Page 43: Live And Playback

    Divar 700 Series Operating instructions | en Zoom To zoom in on a video image: Press the zoom key. – The picture is enlarged by a factor of 2. Use the arrow keys to select the area of the picture to be displayed.

  • Page 44: Overview Of The Menu System

    | Operating instructions Divar 700 Series Overview of the menu system The menu gives access to several functions to help use the unit. Access to some menu items is password protected. There are three ways of accessing the menu system: –...

  • Page 45: Access Using The Front Panel Keys

    Divar 700 Series Operating instructions | en System information The System information menu contains two submenus: – Status - opens a menu to view status information. – Log Book - opens a menu to view the system log. Help The Help function displays a help text.

  • Page 46: Search

    | Operating instructions Divar 700 Series Search Figure 5.5 Top menu - Search To search, enter the top menu and click Search. Choose Date/time search or event or text search from the pull-down menu. Alternatively, press the search key to switch to Date/time search directly.

  • Page 47: Search

    Divar 700 Series Operating instructions | en 5.6.2 Search Events search criteria Figure 5.7 Search menu - Events – Under Start time and End time, fill in date and time values to determine the time span of the search. –...
  • Page 48 | Operating instructions Divar 700 Series Smart motion search criteria Figure 5.8 Search menu - Smart motion Set the smart motion search parameters as follows: – Under Start time and End time, fill in date and time values to determine the time span of the search.
  • Page 49 Divar 700 Series Operating instructions | en Text search criteria Figure 5.9 Search menu - Text data – Under Start time and End time, fill in date and time values to determine the time span of the search. – To set the Search direction, select Forward to search from start time to end time or Backward to search from end time to start time.
  • Page 50 | Operating instructions Divar 700 Series Search results Figure 5.10 Search menu - Search results – The recording fitting the filter and closest to the selected date and time is shown first. – Use the up/down arrow keys to move through the list. The selected recording is shown in the preview window.

  • Page 51: Export And Local Playback

    Divar 700 Series Operating instructions | en Export and local playback Figure 5.11 Top menu - Export video The export menu is accessed from the top menu. It allows writing segments of recorded video and audio to a USB storage device or recordable DVD. The playback menu allows playback of segments of recorded video and audio from the local disk set, a USB storage device or recordable DVD.

  • Page 52: Playback

    | Operating instructions Divar 700 Series – To add another video segment to the list, click Add. – To change a video segment in the list, select it and click Change. – To remove a video segment from the list, select it and click Remove.

  • Page 53: Configuration

    Divar 700 Series Operating instructions | en Configuration Figure 5.14 Top menu - Configuration The Configuration menu is accessed from the top menu. The Configuration menu contains three submenus: – Quick Installation - opens a wizard to configure basic settings. For more information refer to Section 3 Quick install.
  • Page 54 | Operating instructions Divar 700 Series Sequence Figure 5.15 Configure monitors menu - Sequence Select the length of time a camera remains visible on screen (1 to 60 seconds) in the Sequence dwell time field. Use the the Add button to move camera inputs or multiscreen views to the sequence list. Use the Move up or Move down buttons to put them in the desired order.
  • Page 55 Divar 700 Series Operating instructions | en Event display Figure 5.16 Configure monitors menu - Event display Select the way events are displayed on both monitor A and B. Check the Contact inputs events, Motion detection events, Text events or Video loss alarms boxes to display these events on the screen.
  • Page 56 | Operating instructions Divar 700 Series Text display Figure 5.17 Configure monitors menu - Text display Select the way text events are displayed on both monitor A and B. – Enable Show text data to see a text data overlay on the monitor.

  • Page 57: System Information

    Divar 700 Series Operating instructions | en System information Figure 5.18 Top menu - System information The System information menu is accessed from the top menu. The System information menu contains two submenus: – Status - opens a menu to view status information.
  • Page 58 | Operating instructions Divar 700 Series – Earliest recording - displays date and time of the earliest (oldest) recording on disk. – Latest recording - displays date and time of the latest (newest) recording on disk. – Total Disk Size - displays the total installed disk space.
  • Page 59 Divar 700 Series Operating instructions | en Voltage level Lower limit Upper limit 12 Volt 10.8 V 13.2 V 5 Volt 4.7 V 5.3 V 3.3 Volt 3.1 V 3.5 V Table 5.2 Power supply levels Bosch Security Systems Installation and Operation manual...

  • Page 60: Logbook

    | Operating instructions Divar 700 Series 5.9.2 Logbook The logbook menu is used to display a filtered history of system events. Logbook filter Set various filter criteria to search in a specified time period for various system events. Figure 5.20 Logbook menu - Logbook filter –...

  • Page 61: Event Handling

    Divar 700 Series Operating instructions | en 5.10 Event handling Various types of events change the way the unit works. These events are: – a contact input signal applied to the unit; – motion detection in a camera signal; –...

  • Page 62: Contact Inputs

    | Operating instructions Divar 700 Series 5.10.2 Contact inputs If a contact input causes an alarm – Monitors A and B (hybrid version only) can display an array of pre-selected cameras. – Monitor A: The border around the displayed cameos is red. The alarm icon is displayed in the corresponding cameo.

  • Page 63: Advanced Configuration

    Divar 700 Series Advanced configuration | en Advanced configuration Access all the parameters that are used to configure the unit via the configuration menu item of the top menu. The large number of parameters available gives the opportunity to program extensive functionality.

  • Page 64: International

    | Advanced configuration Divar 700 Series Left tabs Top tabs Users General Administrator Users 1 to 7 System Service Serial ports Licenses Logging International 6.1.1 Language Figure 6.1 Configuration menu - International - Language – Select your Language from the drop-down list.

  • Page 65: Time/Date

    Divar 700 Series Advanced configuration | en 6.1.2 Time/date Figure 6.2 Configuration menu - International - Time/date – Select a Time zone from the list (daylight saving time is adjusted accordingly). – Select either a 12-hour or a 24-hour clock Time format.

  • Page 66: Time Server

    | Advanced configuration Divar 700 Series recordings, the clock resumes advancing at the normal pace and normal recording behaviour is resumed. If you want the recorder to set back the clock more than 10 minutes, but also want the unit to resume recording immediately, you should either delete all recordings manualy, or set the recorder time ahead of the latest recording time.

  • Page 67: Video & Audio

    Divar 700 Series Advanced configuration | en Video & Audio Use this menu to configure the video and audio inputs. On DHR 730 models tabs 1-8 are for the analog cameras. Higher tabs are for IP cameras. On DHR 750 models tabs 1-16 are for the analog cameras. Higher tabs are for IP cameras.

  • Page 68: Ip Channels

    | Advanced configuration Divar 700 Series Control tab – Enable PTZ when a controllable camera is connected. By default, PTZ is disabled. – Select protocol and device address on PTZ bus. (PTZ commands are transmitted across the RS485 and Biphase bus simultaneously. Each camera should have a unique address greater than 0.)
  • Page 69 Divar 700 Series Advanced configuration | en Manual setup Figure 6.6 Configuration menu - Video & Audio - IP camera manual setup Click Manual setup ... to configure or change an IP camera connection. – IP address - enter the IP address of the IP camera.
  • Page 70 | Advanced configuration Divar 700 Series Auto detect Figure 6.7 Configuration menu - Video & Audio - IP camera - Auto detect Click Auto detect ... to assign a detected IP camera to the selected channel. Select Configure ... to change the IP parameters of the selected camera.

  • Page 71: Bitrates Tab

    Divar 700 Series Advanced configuration | en 6.2.3 Bitrates tab Units with IP channels have a Bitrates tab for allocating the total available IP bandwidth to the individual cameras. DHR models with 8 or 16 IP channels have 36 Mbit/s total bandwidth available for video streams from IP cameras.
  • Page 72 | Advanced configuration Divar 700 Series panel. This causes the bitrate for the camera to be lower than the value set in the recording profiles. – No Bitstream when the camera can not stream video data due to bitrate limitations.

  • Page 73: Schedule

    Divar 700 Series Advanced configuration | en Schedule 6.3.1 Setting the dynamic characteristics The settings in the Schedule menu provide the opportunity to tap the powerful functionality of the unit. By planning and setting up the profiles available, efficient use of resources is achieved that covers most types of working situations.

  • Page 74: Exceptions

    | Advanced configuration Divar 700 Series 6.3.3 Exceptions – Up to 32 exceptions can be set that override the schedule. – To add an exception, select Add. Enter the Date, Time, Duration, and the Profile. – To edit an exception, select it and click Change..

  • Page 75: Recording

    Divar 700 Series Advanced configuration | en Recording Use the Recording menu to configure the recording set-up for each of the six profiles. Note: The audio/video settings in a profile also apply to the stream used for remote live viewing.

  • Page 76: Contact

    | Advanced configuration Divar 700 Series – Resolution: – for analog cameras, set the video resolution to 4CIF (704 x 576/480 PAL/NTSC), 2CIF (704 x 288/240 PAL/NTSC), or CIF (352 x 288/240 PAL/NTSC). – for IP cameras, set the video resolutions from which to choose in the Camera resolutions field in the Video &...

  • Page 77: Copy

    Divar 700 Series Advanced configuration | en Note: If Event only recording has been selected under the Normal tab, then the pre-event time also applies for contact, motion and text recordings. 6.4.5 Copy The copy recording settings function makes it easy to set up recording for all profiles and all cameras.

  • Page 78: Contacts

    | Advanced configuration Divar 700 Series Contacts Use the Contacts menu to set up alarm inputs and relay outputs. Figure 6.11 Configuration menu - Contacts 6.5.1 Contact inputs By default, all contact Inputs are Normally Open (NO). When needed, highlight contact inputs to function as Normally Closed (NC) contacts (highlight the un-numbered box to select all).
  • Page 79 Divar 700 Series Advanced configuration | en – No override (default) – Follows: the profile override lasts for as long as the input is active (no override duration can be set). – Fixed duration: the profile override starts when the input becomes active and continues for the time set in the override duration field.

  • Page 80: Motion

    | Advanced configuration Divar 700 Series Motion 6.6.1 Motion detection on analog cameras The motion detection feature is configured by selecting the tabs for each individual analog video input. Figure 6.12 Configuration menu - Motion on analog cameras Select the Draw cells mode next to the preview window: –...

  • Page 81: Motion Detection On Ip Cameras

    Divar 700 Series Advanced configuration | en – Noise in the camera image can create false motion events, especially when detecting small objects. Make sure the camera has been set up correctly and enough lighting is available for the camera to obtain a noise-free image.
  • Page 82 | Advanced configuration Divar 700 Series Note: The settings on this page only become effective after clicking the Save button. F.01U.246.471 | v3.4 | 2011.06 Installation and Operation manual Bosch Security Systems...

  • Page 83: Text Data

    Divar 700 Series Advanced configuration | en Text data 6.7.1 Bridge Bridges or terminals for supplying text data are configured here. Figure 6.14 Configuration menu - Bridge text data – Port: enter the port for the bridge device. – Add bridge: click to enter the IP address of a bridge.
  • Page 84 | Advanced configuration Divar 700 Series Figure 6.15 Configuration menu - DirectIP text data DirectIP allows external systems to send text data to the Divar unit for recording with one or more cameras. Click Add to define a new source system sending text data Enter the source IP address of the external system that sends the text data or 0.0.0.0 to...

  • Page 85: Event

    Divar 700 Series Advanced configuration | en Event Use the Event menu to specify the desired behavior for an active contact input, detected motion, or video loss. The general behavior of events is also set here. Each of the six profiles has a General, Contact, Motion, Text and Video loss tab.

  • Page 86: Contact

    | Advanced configuration Divar 700 Series 6.8.2 Contact The event behavior can be configured for each of the 16 input contacts in turn. – Check the Enabled box if the input contact should activate an event. – Check the Alarm box if the input contact should activate an alarm.

  • Page 87: Video Loss

    Divar 700 Series Advanced configuration | en 6.8.5 Video loss The event behavior for video loss signals can be configured for each video channel in turn. – Check the Enabled box for each video channel if video loss should activate an event.

  • Page 88: Network

    | Advanced configuration Divar 700 Series Network 6.9.1 Setup - General Figure 6.17 Configuration menu - Network - Setup - General – Enter a unique DVR name to be used on the network. – If Discovery is enabled, the unit can be automatically discovered and its IP address can be read.

  • Page 89: Setup - Connection 1

    Divar 700 Series Advanced configuration | en 6.9.2 Setup - Connection 1 Figure 6.18 Configuration menu - Network - Setup - Connection 1 Set up the network parameters for the primary Ethernet port. – Enable DHCP to have IP address, subnet mask, and default gateway assigned automatically by the network DHCP server.

  • Page 90: Setup - Connection 2

    | Advanced configuration Divar 700 Series 6.9.3 Setup - Connection 2 Figure 6.19 Configuration menu - Network - Setup - Connections Set up the network parameters for the secondary Ethernet port. – Enable DHCP to have IP address, subnet mask, and default gateway assigned automatically by the network DHCP server.

  • Page 91: Ip Range

    Enter the same begin and end address to specify a single IP address. Enter different begin and end addresses to specify an IP address range. Only workstations (with the Bosch Video Client or Configuration Tool) that have an IP address in one of the specified ranges can gain access to the unit.
  • Page 92 | Advanced configuration Divar 700 Series Figure 6.21 Configuration menu - Network - Monitor streaming F.01U.246.471 | v3.4 | 2011.06 Installation and Operation manual Bosch Security Systems...

  • Page 93: Snmp

    Divar 700 Series Advanced configuration | en 6.9.6 SNMP Figure 6.22 Configuration menu - Network - SNMP SNMP – Enable SNMP to activate SNMP. – Community - fill in the SNMP authentication string. – System contact - fill in the contact data of the administrator.
  • Page 94 | Advanced configuration Divar 700 Series Traps Figure 6.23 Configuration menu - Network - SNMP - Traps – Enable Traps to allow traps to be sent. – Select the traps to send: Coldboot, Temperature alarms, Power supply alarms, Video loss events, HDD alarms, Text bridge connection loss alarms.

  • Page 95: Storage

    Divar 700 Series Advanced configuration | en 6.10 Storage The Storage menu gives access to information on the hard disk(s) and iSCSI storage LUNs. Figure 6.24 Configuration menu - Storage - Disk set 6.10.1 Disk set A disk set consists of 1 or more disk drives and/or iSCSI LUNs. It normally is associated with a particular recorder unit.

  • Page 96: Disks

    | Advanced configuration Divar 700 Series RAID 4 is active, the storage available for video recording is equal to three times the size of the smallest disk in the set. The fourth disk is used for parity information. If a single disk fails, no data is lost. Recording continues on three disks without RAID 4 protection.

  • Page 97: Service

    6.10.4 Raid 4 protection Divar 700 series recorders have a licensed RAID 4 protection feature. When this feature is active, the recordings are safe, even if one of the hard drives should fail. The RAID feature requires 4 drives to operate. The net capacity of hard disk space available in RAID mode is 3 times the size of the smallest hard disk in the recorder.
  • Page 98 | Advanced configuration Divar 700 Series Activating RAID mode. Make sure you have installed the RAID 4 license. If the active disk set has 4 drives installed, the internal RAID option can be enabled in the Disk set tab by selecting Change. The recorder warns that all recordings will be lost.

  • Page 99: Users

    Divar 700 Series Advanced configuration | en 6.11 Users 6.11.1 General – Set a default user. This user is logged on to the unit by default on power up. 6.11.2 Administrator Figure 6.27 Configuration menu - Users - Administrator –...

  • Page 100: Users

    100 en | Advanced configuration Divar 700 Series 6.11.3 Users 1 - 7 Figure 6.28 Configuration menu - Users - User 1 access rights The access rights for up to seven users can be defined with the seven tabs. –...
  • Page 101 Divar 700 Series Advanced configuration | en 101 Figure 6.29 Configuration menu - Users - User 1 control rights In the Control rights tab, set the rights for camera viewing, camera control, camera pre- positioning, and relay control. Bosch Security Systems Installation and Operation manual F.01U.246.471 | v3.4 | 2011.06...

  • Page 102: System

    102 en | Advanced configuration Divar 700 Series 6.12 System 6.12.1 Service – Select Restore factory defaults to reset the settings in the menu system to their default value. (Refer to Section 7 Menu default values for a list of default values.) –...

  • Page 103: Serial Ports

    Divar 700 Series Advanced configuration | en 103 6.12.3 Serial ports Figure 6.31 Configuration menu - System - Serial ports COM port The COM port is used for service or integration purposes. Set up the communication parameters required. RS485 port The COM port is used for service or integration purposes.

  • Page 104: Licenses

    104 en | Advanced configuration Divar 700 Series 6.12.4 Licenses Figure 6.32 Configuration menu - System - Licenses Some optional features require a software license to be obtained before they are activated. – MAC address displays the MAC address of the unit. The MAC address, together with a valid license number, is required to obtain an activation key via: https://activation.boschsecurity.com...

  • Page 105: Menu Default Values

    Divar 700 Series Menu default values | en 105 Menu default values The following tables list the items of the menu system of the unit. The Default value column shows the values that are restored when the factory defaults item of the System settings menu is selected.

  • Page 106: Monitor View Settings Defaults

    106 en | Menu default values Divar 700 Series Monitor view settings defaults Table 7.2 Monitor view settings default values Navigation Setting Default value Reset Display Monitor A Transparent Enabled options background Cameo borders Black Click to open menus Disabled...

  • Page 107: Configuration Menu Defaults

    Divar 700 Series Menu default values | en 107 Configuration menu defaults Table 7.3 Configuration menu default values Navigation Setting Default value Reset International Language Language English Temperature unit Celsius Time/date Time zone GMT+1 West Europe Time format 24-hour Time...
  • Page 108 108 en | Menu default values Divar 700 Series Table 7.3 Configuration menu default values Navigation Setting Default value Reset Recording Profile 1-6 1...32 Normal Recording mode Continuous Pre-event time 30 seconds Resolution 4CIF Video quality Medium Frame rate 6.25 IPS...
  • Page 109 Divar 700 Series Menu default values | en 109 Table 7.3 Configuration menu default values Navigation Setting Default value Reset Text data Bridge Recorder TCP port 4200 List of bridges and Empty terminals DirectIP List of direct IP Empty connections...
  • Page 110 110 en | Menu default values Divar 700 Series Table 7.3 Configuration menu default values Navigation Setting Default value Reset Network Setup General DVR Name Divar 700 Series Discovery Enabled Remote streaming 100 Mbps limit HTTP port Connection 1 DHCP...
  • Page 111 Divar 700 Series Menu default values | en 111 Table 7.3 Configuration menu default values Navigation Setting Default value Reset Users General Default user Administrator Administrator User name Administrator Password Allow local log on Enabled Allow remote log on Enabled...
  • Page 112 112 en | Menu default values Divar 700 Series F.01U.246.471 | v3.4 | 2011.06 Installation and Operation manual Bosch Security Systems...

  • Page 113: Technical Specifications

    Divar 700 Series Technical specifications | en 113 Technical specifications The following pages give the technical specifications of the unit. Electrical Voltage and Power Input voltage 100-240 VAC; 0.7-0.3 A, 50/60 Hz Power consumption 250 W835 BTU/h Video Inputs (hybrid version only) Composite video 0.5-2 Vpp, 75 ohm, automatic termination...
  • Page 114 114 en | Technical specifications Divar 700 Series Control RS232 Output signals according to EIA/TIA-232-F, max input voltage ±25 V Keyboard input Conform RS485 max signal voltage ±12 V, supply 11 V-12.6 V at max 400 mA Biphase Impedance 128 ohm, max overvoltage protection ±40 V, max cable length...

  • Page 115: Mechanical

    Divar 700 Series Technical specifications | en 115 Storage Hard Disks 4 front-replaceable SATA hard drives Record Rate (IPS) PAL: 400 total, configurable per camera: 25, 12.5, 6.25, 3.125, 1 NTSC: 480 total, configurable per camera: 30, 15, 7.5, 3.75, 1 720p60/50: 60/50, 30/25, 15/12.5, 7.5/6.25, 3.75/3.125, 1/...

  • Page 116: Electromagnetic And Safety

    116 en | Technical specifications Divar 700 Series 8.1.3 Electromagnetic and Safety EMC requirements FCC Part 15, Class B EMC directive 89/336/EEC Immunity EN50130-4 Emission EN55022 Class B Harmonics EN61000-3-2 Voltage fluctuations EN61000-3-3 Safety UL, 60950-1 CE, EN60950-1 Canada CAN/CSA - C22.2 no. E60950-1 8.1.4...

  • Page 117: Accessories (Optional)

    Divar 700 Series Technical specifications | en 117 8.1.6 Accessories (Optional) Keyboard KBD-Digital / Universal - Intuikey keyboard with joystick Keyboard extension kit (LTC 8557) Keyboard port expander (LTC 2604) Storage 500GB, 1 TB or 2 TB storage expansion kits...
  • Page 118 118 en | Technical specifications Divar 700 Series F.01U.246.471 | v3.4 | 2011.06 Installation and Operation manual Bosch Security Systems...
