Yamaha Aventage RX-A1020 Specifications

Benefit from enriched audio performance via the symmetrical amp layout and center-mounted
transformer design. Enjoy an improved listening experience throughout the home by utilizing
advanced zone settings. Take full control of any zone with the Yamaha AV Controller App optimized
for Apple and Android phones and tablets, including Kindle Fire. Features such as simplified Apple
connectivity with AirPlay, streamlined user operation with SCENE Plus, automatic room
calibration (YPAO multi-point) and a GUI enhance the overall user experience.
Audio Features
• 7-channel powerful surround sound
110W per Channel
(8 ohms, 20 Hz-20 kHz, 0.06 % THD, 2 ch driven)
120W per Channel
(8 ohms, 1 kHz, 0.9 % THD, 2 ch driven)
• HD Audio format decoding: Dolby TrueHD and DTS-HD Master Audio;
Dolby Digital Plus and DTS-HD High Resolution Audio
• Selected high quality parts to achieve optimum audio performance
• Symmetrical power amplifier layout
• Heat sink with anti-vibration and anti-thermal properties
• Rigid chassis with additional bottom frames
• DAC on Pure Ground circuitry
• High speed thermal feedback power amplifier
• Low jitter PLL circuitry helps optimise sound imaging
• Extra 5th foot with Anti-Resonance Technology (A.R.T. Wedge) to reduce vibration
• Detachable Power Cable for easier installation (also allows cable upgrade)
• Assignable amplifiers for bi-amp connection
• Intelligent assignable amplifiers for Surround Back <-> Front Presence or Zone 2
• Phono input for vinyl playback
Video Features
• 4K Pass-Through for next-generation super high resolution images
• 4K upscaling boosts lower resolution images to super high-definition resolution
• 4K / full HD 1080p video upscaling from analog and HDMI input
• HDMI: 8 inputs (1 on front) and 2 outputs (simultaneous) with 3D and Audio Return Channel
• Supports Deep Color (30/36 bit), x.v.Color, 24Hz Refresh Rate and
Auto Lip-Sync compensation
• High quality video processing with precise deinterlacing
- Motion adaptive and edge adaptive deinterlacing
- Multi-cadence (incl. 3-2 pull-down) detection
Advanced Features
• SCENE PLUS - simple and versatile functionality
- HDMI CEC powers up compatible TVs and Blu-ray Disc™ players
- 12 SCENE choices (4 on front panel and others on GUI)
- Zone SCENE - 4 SCENE buttons for Zone 2
- Versatile parameters can be stored into each SCENE
• Network functions
- AirPlay allows music streaming from iPad, iPhone, iPod touch, Mac, PC
- AV Controller app for operating various functions from an iPod, iPhone, iPad or
Android phones/tablets
- Access to: Internet Radio (vTuner): MP3, WMA
Music files on PC/NAS: WAV, MP3, WMA, AAC, FLAC
- Web Browser Control via PC or Tablet
- Receiver Manager through network connection
- DLNA 1.5 certified
AV Receiver
RX-A1020
4K Pass-Through / 4K Upscaling
• HD Radio™*
• Front panel USB Digital Connection for iPod, iPhone, iPad and USB device
• Charging of iPod, iPhone and iPad via USB when AV Receiver is off
• iPod/iPhone/iPad song titles displayed in English and Western European languages on the front
panel and on-screen display
• HDMI front panel input for devices such as camcorders and digital cameras
• HDMI CEC with versatile control from AV Receiver remote control
• Ability to change HDMI input while in Standby Through mode
• YPAO R.S.C. (Reflected Sound Control) sound optimization with multi-point measurement
• Ability to store and choose between two speaker setting patterns
• Advanced multi-language GUI on-screen display with album art (English, German, French,
Spanish, Russian, Chinese and Japanese)
• Flexibly assignable component video and optical/coaxial (except Video Aux) inputs allow a wide
range of source components
• Audio Delay for adjusting Lip-Sync (0-500 ms)
• Newly designed preset remote unit
• Background Video feature (for tuner and Net)
*For USA only
Surround Realism
• HD Audio decoding with CINEMA DSP 3D (17 DSP programs)
• Compressed Music Enhancer with CINEMA DSP
• Dialogue Lift ensures that dialogue comes from the center of the screen
• Virtual dialogue lift even without use of presence speakers
• Dialogue Level Adjustment for proper sound balance with dialogue and vocals
• Virtual Presence Speaker function for CINEMA DSP 3D surround without Front Presence Speakers
• Channel expandability with external amplifier (7-channel expandability, bi-amping)
• Adaptive DRC (Dynamic Range Control) and Adaptive DSP Level
Versatile Zone Control
• HDMI Zone B for audio/video streaming to another room (same content as main room)
• Zone 2 on/off and control on front panel
• Zone 2 video assign (Component, S-Video, Composite)
• System Backup / Recovery function
• Multi-channel output in main Zone plus 2-channel HDMI output in Zone B
• Zone mono, Zone volume, tone controls and balance
• Party mode
Eco-Friendly Design
• ECO mode operation for about 20%* less power consumption
* Compared to power consumption when ECO mode is off (Yamaha measurement).
• Auto power down function with variable time setting
• Low standby power consumption of 0.3W
NEW PRODUCT BULLETIN
Hidden Control Panel
Includes HDMI Input Terminal, USB Port,
Video Aux Input Terminals, Zone 2 Switch,
YPAO Microphone Jack, And More.
