D-Link DCS-7110 Specifications

Hd outdoor day/night network camera
Hide thumbs Also See for DCS-7110:
1
2
3
4

Advertisement

Quick Links

Download this manual See also: User Manual
Product Highlights
• One Megapixel sensor for High Definition recording
• Mechanical IR Cut Filter for Day/ Night
• 15 meter Illumination Distance with 12 LEDs and
Light Sensor to Support Dark Environments with 0
Lux Illumination
• Supports H.264/MPEG4/MJPEG Video Compression
• Up to 30 Frames Per Second
• Support for Multiple Simultaneous Streams
DCS-7110
HD Outdoor Day/Night Network Camera
Features
• 1/4" megapixel CMOS sensor
• Real-time H.264/ MPEG-4/ MJPEG
• Max. resolution 1280x800 at 30 fps
• Four (4) simultaneous streams
• Built-in 4 mm, F1.5 fixed lens
• 15M IR illumination distance
• Mechanical IR filter for day/night use
• Tamper detection
• Motion detection
• Privacy mask
• Advanced event management
• Advanced web user interface
• HTML code example of streaming
• IPv6, 802.1x, QoS, CoS
• HTTPS secured streaming
• 3GPP mobile surveillance
• Samba client for NAS
• Power over Ethernet (PoE)
• IP66 weatherproof
• Unified SDK
• ONVIF compliant
Overview
The D-Link DCS-7110 is an all-in-one, outdoor network camera equipped with industry-
leading high definition (HD) megapixel resolution and H.264 compression. The DCS-7110
connects to a network to provide high-quality live video on a LAN or over the Internet. This
camera is capable of capturing video in both dark and light environments thanks to its built-
in IR LEDs and IR-cut removable (ICR) filter. The ICR filter can be manually applied via the web,
or set to automatically adjust based on lightning conditions. This feature allows the camera
to capture crisp color images during the daytime and detailed gray scale images at night or
in or low-light conditions.
Multiple Video Streams
The DCS-7110 supports simultaneous streaming of H.264, MPEG-4, and MJPEG video to
provide both high-quality and bandwidth-efficient compression formats. H.264 produces
a small file size, making it useful for extended recording with high detail or for use in low-
bandwidth networks. MJPEG delivers excellent file integrity, ideal for situations which require
extensive image detail.
Flexible Connectivity
The DCS-7110 includes input and output ports for connectivity to external devices such
as IR sensors, switches, and alarm relays. It also comes with an RS-485 interface, providing
connectivity to an optional pan/tilt scanner. The DCS-7110 also incorporates Power over
Ethernet (PoE), allowing it to be easily installed in a variety of locations without the need for
supplemental power cabling.

Advertisement

loading

Related Manuals for D-Link DCS-7110

Summary of Contents for D-Link DCS-7110

  • Page 1 • HTML code example of streaming bandwidth networks. MJPEG delivers excellent file integrity, ideal for situations which require • IPv6, 802.1x, QoS, CoS extensive image detail. • HTTPS secured streaming Flexible Connectivity • 3GPP mobile surveillance The DCS-7110 includes input and output ports for connectivity to external devices such • Samba client for NAS as IR sensors, switches, and alarm relays. It also comes with an RS-485 interface, providing • Power over Ethernet (PoE) connectivity to an optional pan/tilt scanner. The DCS-7110 also incorporates Power over • IP66 weatherproof Ethernet (PoE), allowing it to be easily installed in a variety of locations without the need for • Unified SDK supplemental power cabling.
  • Page 2 DCS-7110 HD Outdoor Day/Night Network Camera Weather-proof and Tamper-proof 3GPP Mobile Surveillance Designed to be mounted outdoors, the DCS-7110 includes an IP66 certified Support for 3GPP Mobile Surveillance allows users to view a live video feed enclosure which protects against the elements. Anti-tamper features make from a 3GPP compatible Internet-ready mobile device. This extends monitoring this camera suitable for tamper-prone locations such as transportation hubs, capability, allowing users to check the camera’s video feed while on the go without schools, or correctional facilities. The electronic tamper detection system can a computer. sense whenever the camera has been redirected, de-focused, blocked, or spray- painted, and respond promptly with a visible or audible alarm. D-ViewCam for Management The included D-Link D-ViewCam™ is sophisticated software which allows users to manage up to 32 network cameras, set e-mail alert notifications, create recording schedules, and use motion detection to record directly to a hard drive. D-ViewCam™ also allows users to upload a floor plan to create a realistic layout of the premises where cameras are located, further simplifying the management process. Technical Specifications Camera Hardware Profile • 1/4” Megapixel progressive CMOS sensor • 4 mm fixed lens , F1.5 with 65.4 degree • 15 meter IR illumination distance horizontal viewing angle • Built-in Infrared-Cut Removable (ICR) Filter module • 256 Mbytes SDRAM...
  • Page 3 DCS-7110 HD Outdoor Day/Night Network Camera System Integration System Requirements Operating System: • Browser: - Windows® 7, Windows Vista®, Windows® XP - Internet Explorer, Mozilla Firefox D-ViewCam™ System Requirements • Operating System: • Web Browser: Internet Explorer 6 or higher - Windows® 7, Windows Vista®, Windows® XP Event Management • Motion detection • Supports multiple HTTP, SMTP and FTP servers • Event notification and upload snapshots/video clips • Multiple event notification via HTTP, SMTP or FTP • Multiple recording methods for easy backup Remote Management • Configuration accessible via web browser • Take snapshots/video clips and save to local hard drive or NAS via web browser Surveillance Software Function • Remote management/control of up to 32 cameras • Supports all management functions provided in web • Viewing of up to 32 cameras on one screen interface • Scheduled motion triggered, or manual recording options Supported PDA, Mobie Phones, and Software • Handsets with 3GPP player, Packet Video Player 3.0, QuickTime 6.5, Real Player 10.5, Windows 2000, XP External Device Interface • DI and DO for external sensor and alarm • RS485 for pan/tilt scanner General Specification Power Input • 12V DC 1.25A...

  • Page 4: For More Information

    DCS-7110 HD Outdoor Day/Night Network Camera Open Network Video Interface Forum (ONVIF) Compliant The open Network Video Interface Forum (ONVIF) is standards relating to open IP video networking. The DCS-7110 is ONVIF compliant and therefore interoperable with other manufacturers’s products on the same network such as cameras, storage systems video analytics products and video management systems. Warranty and Service Information Warranty • 5 Year Warranty Ordering Information Part Number Description DCS-7110 HD Outdoor Day/Night Network Camera Sunscreen Included. 5-Year Warranty available only in the USA Product specifications, size, and shape are subject to change without notice, and actual product appearance may differ from that depicted on the package. See inside package for warranty details. Updated 05/03/12 For more information U.S.A. | 17595 Mt. Herrmann Street | Fountain Valley, CA 92708 | 800.326.1688 | dlink.com Canada | 2525 Meadowvale Blvd | Mississauga, ON L5N 5S2 | 800.361.5265 | dlink.ca ©2012 D-Link Corporation/D-Link Systems, Inc. All rights reserved. D-Link and the D-Link logo are registered trademarks of D-Link Corporation or its subsidiaries in the United States and/or other countries. Other trademarks or registered trademarks are the property of their respective owners. Visit www.dlink.com for more details.
