Tagan PipeRock TG600-BZ Features & Specifications

TG600-BZ 600 W
Features:
•
Compliant with Intel EPS12V Ver. 2.91 and ATX Ver. 2.2 and downward versions with four independent +12V rails
•
Four independent +12 V rails provide individual power to different devices, thus making the system more stable
•
Universal motherboard compatibility due to 20+4-pin main power as well as 4-pin & 8-pin +12 V power connectors
•
Less heat and less noise due to 80% efficiency; this saves electricity, making it an economical and ecological solution
•
One 6-pin and one 6+2-pin PCI-Express connector supports NVIDIA SLI technology and ATI Crossfire graphic cards
•
PCI-Express 6-pin & 6+2-pin cables with REMI technology (ferrite core + cable shielding + anti-noise capacitor) reduce
EMI ripples and noises.
•
Total 14 IDE and SATA hard disks are available for numerous configurations, particularly suitable for graphic-, gaming- and
server-usage
•
Patented manual +12V rails „TURBO" mode switch can integrate the four rails into one single rail with more DC output
•
By means of TSCT (Tagan Silence Control Technology) the fan of the Tagan power supply operates very silent at any DC output
•
Perfect cooling and silent solution due to the blue illuminated 13.5 cm fan together with the super-big heat sink inside
•
Black mesh and copper-shielded cables help to optimize airflow and makes the cables short-circuit proof
•
Patented PipeRock modular cable management with colourfully illuminated housing to avoid wrong connection
•
Internal OVP (Over Voltage Protection) and OCP (Over Current Protection) functions avoid sudden power surge to
protect components in the system
•
Universal AC input range for all countries: 100 V
and flexibility
•
With cable clips for advanced cable management
•
Anti-vibration rubber frame between power supply and case avoids vibration and reduces noise
•
Embedded AC input socket avoids interference with PC case
•
Big I/O switch with dust proof rubber cover avoids dust and bears more current of AC input
•
Unique ground wire with golden pin diverts static electricity from connected components to avoid disturbances
Voltage Table
Model
AC Input
DC Output
Max Amps
Max Combined
Max Combined
Total Power
MaxPoint Handelsges. mbH ● Kurt-Fischer-Str. 50 ● 22926 Ahrensburg ● Germany ● Tel.: 04102 / 468 - 800 ● Fax.: 04102 / 468 – 801
– 240 V
AC
TG600-BZ 600 W „PipeRock Series" (BZ600)
100 V
AC
+3.3 V +5 V +12 V
24 A 24 A
140 W
info@MaxPoint.de ● www.MaxPoint.de ● WEEE-Reg.-Nr. DE88670488
(±10% tolerance) with active PFC for better electricity performance
AC
– 240 V (±10% Tolerance); 12/6 A; 50/60 Hz
AC
+12 V +12 V
1 2
20 A 20 A 20 A
576 W
580 W
600 W
Series 600W
+12 V -12 V
3 4
20 A 0.8 A
9.6 W
20 W
+5 VSB
3 A
15 W
