Table Of Contents; Parts Guide; Sharp Corporation - Sharp AL-1642CS Service Manual

q
1
Exteriors
2
SPF exteriors
3
SPF transport unit
4
SPF pick up unit
5
Operation panel
6
Side door unit
7
Optical frame
8
LSU unit
9
Delivery paper guide unit
F
Middle frame
G
Base plate unit 1
H
Base plate unit 2
I
Fusing unit
J
Drive unit
K
Multi manual paper feeding cover unit

PARTS GUIDE

DIGITAL LASER COPIER /
DIGITAL MULTIFUNCTIONAL
SYSTEM
MODEL
CONTENTS
L
M
N
O
P
Q
R
S
T
U
V
W
I

SHARP CORPORATION

CODE:00ZAL1642CSP1
AL-1642CS
Multi manual paper feeding unit
Socket holder unit
TC case unit
250 sheets tray
Harness
2ND frame unit
2ND paper feeding unit
Packing material & accessories
Operation PWB
MCU PWB
IF PWB
DC power supply PWB
Index
This document has been published to be used
for after sales service only.
The contents are subject to change without
once.
