Kenwood KVT-915DVD Service Manual

MONITOR WITH DVD RECEIVER
KVT-915DVD,925DVD
KVT-935DVD,945DVD
KVT-965DVD

SERVICE MANUAL

TM
ATT DISP
Cord with connector(BK)
E30-6171-05
Screw set *Screw set
N99-1558-05 N99-1723-05
Cord with connector
E30-4953-05
*Depends on the model. Refer to the parts list.
SCREEN MODE V SEL FNC
V.OFF AV OUT SEL
SRC
AUTO
Auto
KVT-915DVD (K TYPE)
Cord with connector(WH) Plastic cabinet assy
E30-6172-05 A02-2723-03
Mounting hardware
*Antena adaptor
J21-3801-04 x2
T90-0512-05
*DC cord *DC cord
E30-6195-05 E30-6196-15
© 2004-3 PRINTED IN JAPAN
TENTATIVE
B53-0165-00 ( N ) 2703
The DVD mechanism information is not in this service manual.
Please refer to service manual for X92-4750-00 (B53-0052-00).
Metallic cabinet
A01-2813-01
AV INPUT 1
L
VIDEO
FM /AM ANTENNA AV INPUT 2
VIDEO L
Remote controller
A70-2046-05 (RC-DV101)
*Escutcheon
B07-3022-02
B07-3058-02
B07-3083-02
*Mounting hardware
J21-9784-04 x2
*Antenna assy
T90-0545-05
*Cord with connector
E30-6197-25
PREOUT
SUB
(MONO) REAR FRONT
AV OUTPUT
R L VIDEO L L L
POWER
R R CENTER R R R
Not supplied
Lever
D10-4589-04 x2
Cleaning cloth
W01-1620-05
Mounting hardware assy
J21-9934-03
*Accessory
W01-1552-05
*Antenna assy
T90-0551-15 x2
*Cord with connector
E30-6241-25
