Tripp Lite U236-000-R Quick Manual

USB 2.0 Hi-Speed to Ethernet NIC Network Adapter,
10/100 Mbps
MODEL NUMBER: U236-000-R
Description
Tripp Lite's U236-000-R USB 2.0 Ethernet Adapter allows your computer to instantly connect to a 10/100Mbps
network through a USB port - no need to open up your computer case to add an internal Ethernet card. It's also an ideal USB-to-LAN alternative for a Wii
gaming console that needs network access in an environment lacking wireless capability. The adapter's compliance with USB 2.0 (480Mbps) ensures true
10/100 Mbps network speed without any compromise. Furthermore, the adapter is compact and is USB bus-powered; requires no external power adapter.
Features
Allows your computer to instantly connect to a 10/100Mbps network through a USB port - no need to open up your computer case to add an internal
Ethernet card
An ideal USB-to-LAN alternative for a Wii gaming console that needs network access in an environment lacking wireless capability
Compliant with USB 2.0 and USB 1.1 specifications
Compliant with IEEE 802.3 (10Base-T) and 802.3u (100Base-TX) standards
Supports both full-duplex and half-duplex operations
Supports suspend mode and remote wakeup via link-up and magic packet
Powered by USB port - no external power adapter required
Equipped with diagnostic LEDs

Specifications

OVERVIEW
Intended Application
Cable Type
Model Type
Connecting Peripherals
USB
Adapters
1 / 3
Highlights
Create a network port on a
computer via USB
PC / MAC compatible
Compliant with USB 2.0 and USB
1.1 specifications
System Requirements
IBM compatible Pentium-233MHz
or faster PC or Mac
64 MB RAM or more
One available USB port
Windows 2000, XP, Vista, 7, and
8; Mac OS X 10.4 through 10.9
Package Includes
USB 2.0 to 10/100 Ethernet
Adapter
CD ( Driver & User Manual )
Quick Install Guide
