Cisco Tandberg 1700 MXP Installation Sheet

Installation sheet
Content of the box:
The 1700 MXP unit
•
• Designers lens cap
• Remote control
• Installation sheet
• Country specific power cable
• Accessories box:
• 1 VGA - DVI cable (w/ audio)
• 1 LAN/Ethernet cable
• Power supply
• Batteries for the remote control
Tilt the display
manually to get a
better view angle.
Tilt the camera
manually to make
it point at you.
Audio/Line in
78-19991-01 1700 MXP Installation Sheet, March 2011
The lens cap (privacy
cover) is held in
place by a magnet.
Turn the ring to focus
the camera. To see
yourself, press the
Selfview key on the
remote control.
DVI-I for PC
presentations
To let the PC and the
video system share a
single LAN connection,
connect your PC to the
LAN through the video
system.
© 2011 Cisco Systems, Inc. All rights reserved.
Headset recommendations
Standard PC headsets with 3.5 mm jacks
are compatible with the 1700 MXP. Having
a headset with microphone is optional.
See the user documentation for more
information about using a headset with
1700 MXP and for technical headset
recommendation.
Headset toggle button
Headset microphone
Headset out
Connect the video
system to your LAN
1700 MXP
Power
