NEI-30 | VEI-30 Dinion Infrared Imager
NEI | VEI Series
en
Quick Install Guide

Advertisement

Table of Contents
loading

Related Manuals for Bosch NEI-30

Summary of Contents for Bosch NEI-30

  • Page 1 NEI-30 | VEI-30 Dinion Infrared Imager NEI | VEI Series Quick Install Guide...

  • Page 3: Table Of Contents

    NEI-30 | VEI-30 Dinion Infrared Imager Table of Contents | en Table of Contents Planning Hardware Requirements Pre-installation Checklist Installation Mount the Junction Box Route Wires and Attach Connectors Attach Pendant Arm to Junction Box Connection Power Connection Video and Control Cables...

  • Page 4: Planning

    | Planning NEI-30 | VEI-30 Dinion Infrared Imager Planning CAUTION! CLASS 1 LED PRODUCT IEC60825-1 Ed. 1.2 (2001) WARNING! IMPORTANT MOUNTING INSTRUCTIONS This apparatus must be securely attached to the wall in accordance with these installation instructions. Failure to follow installation instructions may result in injury or death.

  • Page 5: Pre-Installation Checklist

    NEI-30 | VEI-30 Dinion Infrared Imager Planning | en Pre-installation Checklist WARNING! This installation must be made by a qualified service person and must conform to all local codes. WARNING! CSA Certified / UL Listed CLASS 2 power adaptors or Certified PoE+ rated 42.5 VDC to 57 VDC, 600 mA, 34.20 W (max) power adaptor must be used in order to comply with...

  • Page 6: Installation

    | Installation NEI-30 | VEI-30 Dinion Infrared Imager Installation This chapter details how to mount the VEI-30 / NEI-30 to a wall. Any variations to the installation procedures are noted. Mount the Junction Box Before mounting the junction box, decide if you should wire the box through the holes in the bottom or back of the box.

  • Page 7: Route Wires And Attach Connectors

    NEI-30 | VEI-30 Dinion Infrared Imager Installation | en Locate a stud in the wall and mark the outside edges of the stud. Using the wall mount bracket as a template, align the mounting hole with the center of the stud.

  • Page 8: Attach Pendant Arm To Junction Box

    | Installation NEI-30 | VEI-30 Dinion Infrared Imager Attach Pendant Arm to Junction Box The bottom hinge pin of the Camera Arm is provided with a Hinge Pin Stop to hold the hinge open while attaching the arm to the junction box.

  • Page 9: Connection

    Coaxial cable terminated with BNC connectors is the most common method for transmitting composite video. Bilinx control data can also be sent over the same cable. Bilinx is a Bosch 2- way communication protocol that allows remote control, configuration, and updates over a video coax cable.

  • Page 10: Ethernet Connection (Ip Models)

    NEI-30 | VEI-30 Dinion Infrared Imager Ethernet Connection (IP models) The NEI-30 connects to a 10 Base-T/100 Base-TX network either directly or via a hub. Both video and control are transmitted over a standard TCP/IP network using the built-in web server.

  • Page 11: Configuration

    All VEI-30 camera settings (except lens focus, focal length, and LED tilt) can be adjusted remotely using the Configuration Tool for Imaging Devices (CTFID) software application. Refer to the Configuration Tool for Imaging Devices User Manual located on the Bosch Security Systems website (www.boschsecurity.com).

  • Page 12: Adjusting The Focus And Focal Length

    | Configuration NEI-30 | VEI-30 Dinion Infrared Imager Figure 4.2 Camera and LED Focal length adjustment Focus adjustment (zoom) Advanced camera setup controls - keypad LED tilt control Adjusting the Focus and Focal Length Use the top set screw (item 1, Figure 4.2) to adjust the image focus: –...

  • Page 13: Making Pan Adjustments

    NEI-30 | VEI-30 Dinion Infrared Imager Configuration | en Making Pan Adjustments Using the 4 mm hex key, loosen the bolts at the base of the “u bracket” to make the necessary pan adjustments. When loosened, adjust the camera to the desired pan angle.

  • Page 14: Adjusting The Variable Field Illumination

    | Configuration NEI-30 | VEI-30 Dinion Infrared Imager Adjusting the Variable Field Illumination 4.5.1 Adjusting the LED Tilt Angle You can orient the LED array tilted either up or down to maximize infrared coverage over the field of view. On the rear of the camera housing is graphic for the LED tilt.
  • Page 15 NEI-30 | VEI-30 Dinion Infrared Imager Configuration | en To remove the 3D diffuser: Remove the 3D diffuser and plate assembly as when installing the 3D diffuser. Remove the 3D diffuser from the diffuser plate. Install the diffuser plate into the camera housing to secure and seal the unit.

  • Page 16: Index

    | Index NEI-30 | VEI-30 Dinion Infrared Imager Index accessing controls 11 adjusting LED tilt angle 14 attaching pendant arm 8 Bilinx 9 BNC connector with pendant arm, corner or mast mount 7 cable compensation 9 CAT-5E 10 CAT-6 10...
  • Page 17 NEI-30 | VEI-30 Dinion Infrared Imager Index | en Bosch Security Systems, Inc. Quick Install Guide F.01U.166.250 | 1.0 | 2011.04...
  • Page 18 | Index NEI-30 | VEI-30 Dinion Infrared Imager F.01U.166.250 | 1.0 | 2011.04 Quick Install Guide Bosch Security Systems, Inc.
  • Page 20 Bosch Security Systems, Inc. 850 Greenfield Road Lancaster, PA 17601 U.S.A. www.boschsecurity.com © Bosch Security Systems, Inc., 2011...
