HCCWD484
ULTRA WIDE DYNAMIC COLOR CAMERA
Honeywell's HCCWD484 is the ideal camera for environments with high contrast
and changing light conditions. Using Next Generation Image Capture Technology,
images are converted from analog to a digital format within each pixel immediately
after the image is captured. Even in high contrast lighting conditions, the
HCCWD484 delivers higher quality images; significantly better dynamic range
(120 dB max), and higher frame rates than conventional CCD cameras.
While conventional cameras record every pixel in a frame with the same exposure
time, the HCCWD484 records each of its 388,800 pixels at its optimum exposure
time. This results in correct color rendering and capturing of details in all
applications including high contrast scenes with shadows and glare. Typical CCD
cameras would render the same scene washed out or under exposed. Next
Generation Image Capture Technology eliminates multiple processing steps prior
to being digitized and stored, significantly reducing noise. This delivers crisp, high
resolution images without the presence of blooming or smearing, in both moving
and still pictures.
Market Opportunities
The HCCWD484 is a surveillance solution designed in locations where high contrast
and variable light conditions exist. Setup is quick and easy and can be customized
with on-screen displays and preset modes. This provides optimum performance for
both indoor and outdoor applications including: lobbies, atriums, vestibules, gated
entrances, foyers, loading docks, and driveways.
Features
• 1/3" Wide Dynamic Digital Imager
• 14-bit digital processing
• 480 TV lines of resolution
(NTSC, PAL)
• Independent per-pixel exposure
• Dynamic range: 95 dB typical/120 dB
max – 100 to 200 times greater than
conventional CCD cameras
• Transient protection on inputs and
outputs
• Temperature range: -4ºF to 95ºF
• Higher frame rates – 50/60 fps
progressive video capture for sharp
image definition in all lighting
conditions
• 0.4 lux @ F1.2 for true color
representation in low light conditions
• 12 VDC/24 VAC with line lock
• C/CS lens mount
• DC, Video and Manual Iris lens
support
www.honeywellvideo.com
Advertisement
Related Manuals for Honeywell HCCWD484
Summary of Contents for Honeywell HCCWD484
- Page 1 (120 dB max), and higher frame rates than conventional CCD cameras. While conventional cameras record every pixel in a frame with the same exposure time, the HCCWD484 records each of its 388,800 pixels at its optimum exposure time. This results in correct color rendering and capturing of details in all applications including high contrast scenes with shadows and glare.
- Page 2 Low Light Performance The HCCWD484 offers 0.4 lux of low light sensitivity – the best of any of the ultra wide dynamic range cameras on the market today. Honeywell offers three Vari-focal Auto Iris lenses which have the widest maximum apertures of comparable lenses having the same focal length range.
- Page 3 HCCWD484 www.honeywellvideo.com ULTRA WIDE DYNAMIC COLOR CAMERA On Screen Display Menu The HCCWD484 can be quickly set up and configured using the built-in OSD menu. This includes choosing preset scene settings, modifying the camera setup, and adding a camera ID.
-
Page 4: Specifications
1/3" High Resolution Ultra Wide Dynamic Camera, 480 TVL, 0.4 lux, 12 VDC/24 VAC, NTSC HCCWD484X 1/3" High Resolution Ultra Wide Dynamic Camera, 480 TVL, 0.4 lux, 12 VDC/24 VAC, PAL NOTE: Honeywell reserves the right, without notification, to make changes in product design or specifications. Honeywell Security Honeywell Video Systems...
