Electrolux EN18WI30LS Use And Care Manual

Condensing tankless gas water heater
Hide thumbs Also See for EN18WI30LS:
Table of Contents

Advertisement

Quick Links

See also: Service Manual , Use and Care Manual
SBB800R
Rev. 11/12
EN CONDENSING TANKLESS GAS WATER HEATER
SP CALENTADOR A GAS TIPO CONDENSADO
5995615118 November 2012
Use and Care Manual
Manual de uso y mantenimiento
*SBB800R*

Advertisement

Table of Contents
loading

Related Manuals for Electrolux EN18WI30LS

Summary of Contents for Electrolux EN18WI30LS

  • Page 1 EN CONDENSING TANKLESS GAS WATER HEATER Use and Care Manual SP CALENTADOR A GAS TIPO CONDENSADO Manual de uso y mantenimiento SBB800R 5995615118 November 2012 Rev. 11/12 *SBB800R*...
  • Page 3 - WHAT TO DO IF YOU SMELL GAS agency or the gas supplier. Thank you for purchasing this Electrolux Tankless Gas Water Heater. Before using, please: Read this manual completely for operation instructions.

  • Page 4: Important Safety Information

    Important Safety Information-1 To prevent damage to property and injury to the user, the icons shown below will be used to warn of varying levels of danger. Every indication is critical to the safe operation of the water heater and must be understood and observed. Potential dangers from accidents during installation and use are divided into the following four categories.
  • Page 5 WHAT TO DO IF YOU SMELL GAS. heater 3. Turn off gas and water supply valve appliance. 4. Call the nearest Electrolux agent your building. Immediately call your gas If the temperature and pressure relief valve is dripping or leaking, have a Prohibited instructions.
  • Page 6 Important Safety Information (Continued) WARNING Do not place the exhaust vent terminal Carbon Monoxide Poisoning Hazard. Do in an indoor environment by means not install this water heater in a mobile of adding walls and ceiling (Do not home, recreation vehicle or on a boat. Prohibited Prohibited enclose using corrugated sheets, etc.)
  • Page 7 Electric with a wet Shock. The gas conversion kit shall be installed by a hand. Consult the nearest Electrolux agent applicable codes and requirements of the if the water heater location needs to authority having jurisdiction. The be changed. Be sure information in the instructions must be to do.
  • Page 8 4500 ft. (1350m) above sea level. For installations at higher elevations, contact unit in the morning. Electrolux Home Products, Inc. for Instructions. Do not disassemble the remote controller. frequently as required by the quality of your local water.

  • Page 9: Table Of Contents

    Contents Important Safety Information ............... 2 Contents ......................7 Overview of Condensing Tankless Gas Water Heater ......8 General Parts Main Unit ....................9 Remote Controller ..................10 Initial Operation .................... 11 How to Use Setting and Using the Water Heater ............12 Flow Meter Alarm ..................

  • Page 10: Overview Of Condensing Tankless Gas Water Heater

    Note : The condensate discharged is acidic with a comes out pH level of approximately 2-3. from here. A condensate neutralizer may be required by (Ex. EN18WI30LS) local code prior to disposal. The condensing tankless gas water heater tends to show white steam.

  • Page 11: General Parts

    (with Water Filter) (Inside Water Inlet) p.22) Pressure Relief Valve Water Supply Valve Gas Supply Valve Drain Pipe Discharges the condensate. (Ex. EN18WI30LS) * The above illustration shows an example of installation. The exact installation configuration may be slightly different.

  • Page 12: Remote Controller

    General Parts -2 Remote Controller What is actually displayed depends on how the water heater is set. Burner On Indicator Setting Buttons When burning, the For setting the hot indicator is lit. water temperature, p.13 and 15) the flow meter alarm, and other settings.

  • Page 13: Initial Operation

    Open the water supply valve. OPEN CLOSED Open a hot water fixture to confirm that water is available, and then close the fixture again. Hot water fixture Open the gas supply valve. Turn on the power. Do not touch with wet hands. (Ex. EN18WI30LS)

  • Page 14: How To Use

    How to Use Setting and Using the Water Heater (Starting with the Power Off) Press the Power On/Off Button. The temperature will be displayed on the remote control thermostat. Previous set temperature (Ex.: 110°F) DANGER To prevent scalding: High Temperature Hot Water Heater temperatures over 125°F (52°C) can cause severe burns instantly or death from scalding.
  • Page 15 Set temperature. Turn on hot Turn off the hot Always check the water. water. temperature setting before use. Cold Check the indicator lights. Water temperature When using °F mode: The maximum output temperature can be °F : The temperature settings below are examples. The temperature setting set using the remote controller.

  • Page 16: Flow Meter Alarm

    How to Use Flow Meter Alarm If the flow meter alarm is being used to indicate when a tub is full: If any hot water is being used besides what is going into the tub, the alarm will sound before the tub is full. If there was water in the tub before the fill began, or if the water is not shut off manually when the alarm...
  • Page 17 Water Temperature An alarm will sound for °F : The temperatures settings below are only examples. The ten seconds when the flow temperature setting necessary will depend on the usage, the length of piping and the time of year. reaches the set level. Warm Warmer The water will continue to run unless...

  • Page 18: Muting The Remote Controller

    How to Use Muting the Remote Controller The remote controller will emit a sound when any button is pushed. This sound can be muted if it is desired. * Initial factory setting is with sound. Hold the Power On/Off Button for five seconds. Muted Sound No sound...

  • Page 19: Adjusting The Maximum Output Temperature

    How to Use Adjusting the Maximum Output Temperature Change the Press and hold the flow Turn off the temperature using power. meter alarm set button until the setting buttons. a sound is heard (2 sec.). Tone sounds after 2 sec. Down The upper limit of the hot-water supply temperature can be changed to...

  • Page 20: Preventing Damage From Freezing

    * The freeze prevention heaters will not prevent the plumbing external to the unit from freezing. Protect this plumbing with insulation, heat tape or electric heaters, solenoids, or pipe covers. If there remains a freezing risk, contact the nearest Electrolux agent. Take the measures below for extremely cold temperatures*.
  • Page 21 Preventing Damage from Freezing-2 For EN18WI30LS, EP18WI30LS If the water heater will not be used for a long period of time, drain the water. Drain the water as follows: CAUTION To avoid burns, wait until the equipment cools down before draining the water. The appliance will remain hot after it is turned off.
  • Page 22 Preventing Damage from Freezing-3 For EN19WI30LS, EP19WI30LS If the water heater will not be used for a long period of time, drain the water. Drain the water as follows: CAUTION To avoid burns, wait until the equipment cools down before draining the water. The appliance will remain hot after it is turned off.

  • Page 23: Turning The Unit Back On

    Turning the Unit Back On 1. Check that all drain plugs are inserted. 2. Check that all hot water fixtures are closed. 4. Make sure that the area around the appliance is well ventilated; open a window or a door if necessary. Then, operate the unit and verify that condensate is coming out of the drain pipe.

  • Page 24: Regular Maintenance

    For blockage at the Check drain pipe discharge. (Ex. EN18WI30LS) Periodic Maintenance Equipment Wipe the outside surface with a wet cloth, then dry the surface. Use a neutral detergent to clean any stains. If an external condensate neutralizer is installed, periodic replacement of the neutralizing agent will be required.

  • Page 25: Periodic Maintenance

    2. Open all hot water fixtures. Packing 3. With a bucket ready, remove the inlet and outlet drain plugs (For EN18WI30LS and EP18WI30LS, about 0.4 gallon (1.4L) will drain out. For EN19WI30LS and EP19WI30LS, about 0.45 gallon (1.7L) will drain out.) 4.

  • Page 26: Troubleshooting

    Troubleshooting-1 Initial Operation Unit does not attempt to ignite when water is running. p.23) Unit attempts to ignite but fails. Temperature Hot water is not available when a fixture is opened. p.23) No water is available when a fixture is opened. The hot water is not the correct temperature.

  • Page 27: Amount Of Hot Water

    The water is cold when only a 0.5 gallons (2L) per minute. single fixture is open. Open the fixture more or open other fixtures so that a greater flow passes through the unit, and the unit should begin heating again. °F to 120°F or 48°C (118°F) to Fluctuations in hot water 50°C (122°F).
  • Page 28 Troubleshooting-2 Remote Controller The light on the power button does not come on. The water temperature changes after a power failure or when the may both need to be reset after a power outage. power is disconnected. The plastic on the surface or buttons The surface of the remote controller is affixed with a protective sheet (to prevent surface scratching, etc.) at of the remote controller has torn,...

  • Page 29: Water Quality

    Limited Warranty. To ensure full warranty coverage, treat or condition water that exceeds the target levels provided in this table. : 6.5 - 8.5 Source: EPA National Secondary Drinking Water Regulations (40 CFR Part 143.3) * Maximum limit suggested by Electrolux.

  • Page 30: Error Code Cause

    Clogging of condensate Check to see if the condensate drain pipe is clogged trap or drain pipe or frozen ( p.8) Contact the installer or Electrolux Home Products, Inc. Technical Support for assistance. [When supplying combustion Clean the air supply vent.( p.21)

  • Page 31: Follow-Up Service

    Period of Time for Stocking Repair Parts Electrolux will stock repair and maintenance parts for this unit for the time period from the date of the original installation as follows: twelve (12) years for the heat exchanger and ten (10) years for remaining parts.

  • Page 32: Gas Conversion

    This work must be performed by either Electrolux or a qualified service agency and will be charged for even during the warranty period. The qualified installer will also be responsible for purchasing the gas conversion kit directly from the manufacturer.
  • Page 33 Specifications-1 water supply, piping conditions, and water temperature. Specifications Item Specification Model Name EN18WI30LS EP18WI30LS Type Installation Indoor Wall Mounted Power Vented Ignition Direct Ignition Operating Pressure 15-150 psi Minimum Flow Rate Dimensions (Height) x (Width) x (Depth) Weight 58 lbs.
  • Page 34 Specifications-2 water supply, piping conditions, and water temperature. Specifications Item Specification Model Name EN19WI30LS EP19WI30LS Type Installation Indoor Wall Mounted Power Vented Ignition Direct Ignition Operating Pressure 15-150 psi Minimum Flow Rate Dimensions (Height) x (Width) x (Depth) Weight 68 lbs. Water Holding Capacity 0.5 Gallon (1.8L) Connection Sizes...

  • Page 35: Limited Warranty

    Electrolux Home Products, Inc Limited Warranty Tankless Hot Water Heaters Required Conditions Limited Warranty Period Exclusions...

This manual is also suitable for:

En19wi30lsEp18wi30lsEp19wi30ls
