OUTLINE AND DIFFERENCES FROM BASE MODEL
OUTLINE
This model is based on the LC-42D83X, LC-46D83X and partially modified.
For the contents not covered in this Service Manual, accordingly, please refer to the LC-42D83X, LC-46D83X (S97R1LC52D83X)
Service Manual.

DIFFERENCES FROM BASE MODEL

LIST OF CHANGED PARTS (LC-42D63X)
Ref. No. Description
PRINTED WIRING BOARD ASSEMBLIES (NOT REPLECEMENT ITEM)
MINI-AV Unit
KEY Unit
MAIN Unit
SUB Unit
LED, R/C Unit
POWER Unit
AC INLET Unit
LCD PANEL (NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT NOT INDEPENDENTLY.)
LIST OF CHANGED PARTS (LC-46D63X)
Ref. No. Description
PRINTED WIRING BOARD ASSEMBLIES (NOT REPLECEMENT ITEM)
MINI-AV Unit
KEY Unit
MAIN Unit
SUB Unit
LED, R/C Unit
POWER Unit
AC INLET Unit
LCD PANEL (NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT NOT INDEPENDENTLY.)
LC-42D83X
DUNTKE188FM05
DUNTKE266FM03
DUNTKE186FM11
DUNTKE183FM01
DUNTKE264FM03
RDENCA237WJQZ
RUNTKA341WJQZ
R1LK420D3LZ60W
LC-46D83X
DUNTKE188FM05
DUNTKE266FM03
DUNTKE186FM11
DUNTKE183FM01
DUNTKE264FM03
RDENCA237WJQZ
RUNTKA341WJQZ
R1LK460D3LZ60W
i
LC-42D63X
DUNTKE188FM05
DUNTKE266FM03
DUNTKE186FM11
DUNTKE183FM01
DUNTKE264FM03
RDENCA237WJQZ
RUNTKA341WJQZ
R1LK420D3LZ50W
LC-46D63X
DUNTKE188FM05
DUNTKE266FM03
DUNTKE186FM11
DUNTKE183FM01
DUNTKE264FM03
RDENCA237WJQZ
RUNTKA341WJQZ
R1LK460D3LZ50W
Note
No Changes
No Changes
No Changes
No Changes
No Changes
No Changes
No Changes
Changes
Note
No Changes
No Changes
No Changes
No Changes
No Changes
No Changes
No Changes
Changes
