Use

The control panel

CONDENSER DRYER
E L E C T R O N I C
A B C D
1 Door opening button
Press this button to open the door: any programme
which is running stops.
2 ON/OFF button
This button is used to switch the dryer on. At the end
of the programme, release this button by pressing it
again to switch the dryer off.
3 Mains-ON light
Comes on when the appliance is switched on
(ON/OFF button pressed down) and goes out when
this button is released.
4 Low temperature button
Pressing this button allows drying to be performed at
a lower temperature, for delicate items.
Corresponding pilot light 5 comes on and an
acoustic sound rings.
This option can also be used for time controlled
drying.
The dryer heats at 1400 W instead of 2400 W.
If the button is not pressed, drying is performed at
full power (2400 W).
5 Low temperature light
Comes on when the low temperature drying button is
pressed.
6 Buzzer OFF button
A buzzer sounds when buttons 4-6 and 8 are
pressed and during the anti-creasing phase.
Press this button when selecting the programme if
you wish to switch the buzzer off.
S E N S O R
E F G H
5 7
A U T O R E V E R S E
1 2 3 4 6
7 Buzzer OFF light
Comes on when you press the corresponding button.
8 Start button
Press this button for about 2 seconds to start the
dryer after having selected the programme. An
acoustic sound rings.
If the door is opened while the programme is
running, this button must be pressed again after
closing the door in order to restart the programme
from the point at which it was interrupted.
This button must also be pressed after a power cut
and after having re-inserted the water reservoir if it
has been emptied in the middle of a programme.
In both cases light
phase in progress) flashes to remind you that the
start button needs to be pressed again.
9 Programme phase indicator lights
These lights indicate the various phases of the
programme as they are being performed.
"Drying" light
This light indicates that the appliance is in the drying
phase.
"Cooling" light
This light indicates that the appliance is in the
cooling phase. At the end of drying, there is a 10
minute cooling phase to cool the laundry.
If light or
Start button needs to be pressed again for the
programme to resume.
8
8 9 10
or (depending on the
is flashing, this means that the
