INSTALLER: THESE INSTRUCTIONS MUST BE CONVEYED TO AND REMAIN WITH THE HOMEOWNER.
CERTIFIED UNDER CANADIAN AND AMERICAN NATIONAL STANDARDS, CR97-003, CAN1-2.21-M85, IAS U.S. 4-96.
INSTALLATION AND OPERATION INSTRUCTIONS FOR
WARNING: If the information in these instructions is not followed exactly, a fi re or
explosion may result causing property damage, personal injury or death.
Do not store or use gasoline or other fl ammable vapours and liquids in the vicinity of
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Close propane bottle or shut-off gas
supply.
• Do not use any phone in your build
ing or near the appliance.
Installation and service must be performed by a qualifi ed installer, service agency or
the gas supplier.
THIS FIREPLACE MUST BE INSTALLED OUTSIDE.
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON L4M 4Y8 Canada • (705)721-1212 • fax(705)722-6031
$10.00
OUTDOOR GAS APPLIANCE
OUTDOOR GAS FIREPLACE
NATURAL GAS MODEL
PROPANE GAS MODEL
CERTIFIED FOR CANADA AND UNITED STATES USING ANSI / CSA METHODS
FOR YOUR SAFETY
this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
www.napoleonfi replaces.com • ask@napoleon.on.ca
GSS36N
GSS36P
• Immediately call your gas supplier from
a neighbour's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier,
call the fi re department.
1
W415-0369 / F / 12.10.07
