- Page 1 Cordless Circular Saw with Dust Collection MODEL 5026D MODEL 5036D MODEL 5046D 001322 I N S T R U C T I O N M A N U A L WARNING: For your personal safety, READ and UNDERSTAND before using.
-
Page 2: Specifications
SPECIFICATIONS MODEL 5026D 5036D 5046D Blade diameter 165 mm 160 mm 160 mm Max. Cutting depth 55 mm 53 mm 53 mm 2,400 2,400 2,400 No load speed (min Overall length 338 mm 338 mm 338 mm Net weight 3.8 kg 3.8 kg... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS ENA002-2 WARNING: When using battery operated tools basic safety precautions, including the following, should be followed to reduce the risk of fire, leaking batteries and personal injury: Read these instructions before operating this product and save these instructions. 14. - Page 4 ADDITIONAL SAFETY RULES FOR TOOL ENB077-1 Be aware that this tool is always in an operating condition, because it does not have to be plugged into an electrical outlet. Wear hearing protection. Keep Guards In Place and In Working Order. Never wedge or tie lower guard open.
- Page 5 15. Avoid Cutting Nails. Inspect for and remove all nails from lumber before cutting. 16. Operate with proper hand support and proper workpiece support. WARNING: It is important to support the workpiece properly and to hold the saw firmly to prevent loss of control which could cause personal injury.
- Page 6 IMPORTANT SAFETY INSTRUCTIONS FOR BATTERY CARTRIDGE ENC004-1 (1) Do not touch the terminals with any con- Before using battery cartridge, read all instruc- tions and cautionary markings on (1) battery ductive material. charger, (2) battery, and (3) product using bat- (2) Avoid storing battery cartridge in a con- tery.
-
Page 7: Functional Description
FUNCTIONAL CAUTION: DESCRIPTION • Always be sure that the tool is switched off and the battery cartridge is removed before adjusting or checking function on the tool. Installing or removing battery cartridge 001329 • Always switch off the tool before insertion or removal of the battery cartridge. - Page 8 Tip the rear of the tool down to empty the dust box. 1. Lever Cleaner cutting operations can be performed by connecting this tool to Makita 2. Rubber cap vacuum cleaner. Remove the rubber cap from the dust cap and connect the 3.
-
Page 9: Operation
To install the blade, follow the removal procedure in reverse. Install the cup 001447 washer, inner flange, saw blade, outer flange and hex bolt on the spindle in that order. BE SURE TO TIGHTEN THE HEX BOLT CLOCKWISE SECURELY. After installing the blade, install the dust box and tighten the clamping screws to secure the dust box. - Page 10 For 5046D only 001475 When you cut angle materials or the like, the lower guard may rest on the angle. If so, tilt other rear of the tool to prevent this. When cutting thin sheet metals such as corrugated metal, always cut them at a position more than 20 mm (25/32”) away from the edge.
-
Page 11: Maintenance
CAUTION: • These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. - Page 12 Makita Corporation 884267C993...
