Page 6
EnglisH introduction The induction cooker works on the basis of an electromagnet that creates a powerful, high-frequency electromagnetic field. When cookware consisting of magnetic material (e.g. iron) is placed on the induction cooker, the electromagnetic field transfers energy to the bottom of the cookware, which causes the cookware and the food inside it to become hot.
Page 7
Do not use the appliance if the plug, the mains cord or the appliance itself is damaged. If the mains cord is damaged, you must have it replaced by Philips, a service centre authorised by Philips or similarly qualified persons in order to avoid a hazard.
Page 8
Philips will not accept liability for any damage caused. Place the induction cooker on a stable, horizontal and level surface and make sure there is at least 10cm free space around it to prevent overheating.
Page 9
EnglisH Before first use Remove all packaging material from the induction cooker. Preparing for use Place the appliance on a dry, stable and level surface. Make sure there is at least 10cm free space around the appliance to prevent overheating. Always place the cookware on the cooking zone during cooking.
Page 10
EnglisH Note: Always place and use the appliance on a dry, stable and level surface. The tables below shows the default settings in the different cooking modes and to what extent these default settings can be adjusted. Default and adjustable settings Mode Default Power (watt)/...
Page 11
EnglisH suggested boiling time for 1 litre is 3-5 minutes, for 2 litres 6-10 minutes and for 3 litres 9-14 minutes. Power/temperature settings High Wattage 1000 1200 1400 1600 1800 2000 Temperature (°C) Quick start cooking (manual mode) Put the mains plug in the wall socket. The appliance produces a -second beep.
Page 12
EnglisH Press the Hr:Min button. Adjust the time with the + and - buttons. Note: When you press the + and - buttons briefly, the time increases or decreases by 1 minute. When you press the buttons longer, the time increases or decreases by 5 minutes.
Page 13
EnglisH Put the mains plug in the wall socket and press the Power on/off button to switch on the appliance. The power-on light goes on and the display shows the power bar and the default power level (100W). Press the button of the preset mode you want to use. Note: Before you press the Start button to confirm the selected mode, you can still switch to any other preset mode.
EnglisH Press the Hr:Min button. Adjust the time with the + and - buttons. Note: When you press the + and - buttons briefly, the time increases or decreases by 1 minute. When you press the buttons longer, the time increases or decreases by 5 minutes.
Page 15
EnglisH Press the Timer button. Press the + and - buttons to set the number of minutes or hours after which you want the appliance to start cooking. Note: Press the + or - button briefly to increase or decrease the time in steps of 5 minutes.
Page 16
By doing this, you help to preserve the environment. guarantee and service If you need information or if you have a problem, please visit the Philips website at www.philips.com or contact the Philips Customer Care Centre in your country (you find its phone number in the worldwide guarantee leaflet).
The light is defective. Take the appliance to your Philips dealer or a service centre authorised by Philips. When I press the cooking The light is defective.
Page 18
10 minutes and then switch on the appliance again. The appliance Take the appliance to a Philips dealer or a service malfunctions centre authorised by Philips. The appliance has Check if the air outlet is covered. If so, remove the...
Page 19
EnglisH Recipes Chinese-style soup Preparation time: 3 hours Ingredients: 300g chicken 1 carrot 2 potatoes 1 onion 2ltr water Put all ingredients in the cookware in the same order as described above. Put the lid on the cookware. Place the cookware on the cooker and boil the soup in the Soup mode (see chapter ‘Using the appliance’, section ‘Using the preset cooking modes’.
Page 20
繁體中文 簡介 電磁爐的運作原理是利用電磁鐵產生強力的高頻電磁場。將具磁性 材料 (如鐵製) 的鍋具放在電磁爐上時,電磁場會將能源轉往鍋具底 部,使鍋具及其中食物加熱。要調整鍋具溫度時,只要改變電磁場 強度,鍋具溫度便會立即改變。 電磁爐的優點: 安全:電磁爐不使用火焰,還有多重安全裝置,讓您隨時都可以 與家人一同烹調享受美食。 快速:使用電磁爐烹煮時,鍋具便是熱源。因此導熱更快也更 好,跟傳統烹調方法比起來,最多能夠省下三分之一的時間。 多功能:電磁爐有 8 種預設烹調模式,每一種都設有最佳加熱 模式。善用這些模式即可調理各式各樣營養滿點的餐點。 簡易操作:互動式的控制面板簡潔有力,並有顯示螢幕助您操作 按鈕輕易調整設定。 舒適:電磁爐烹調無煙不油膩,而且電磁爐本身和四週空間不悶 熱,讓您舒舒服服調理餐點。 輕便:電磁爐設計輕巧,加熱面板也不留熱度,隨時都能安全操 作,在家裡每個地方都可以調理餐點。 一般說明 (圖 1) A 陶瓷加熱面板 B 機身 C 烹調區 D 控制面板 E 顯示 F 出風口 g 進風口 H 電線 控制面板...
