Grizzly Electric Motor G2536 Instruction Sheet

Model G2536 Specifications
Power .......................................................... 2 HP
Cycle ............................................................60Hz
Voltage .................................................110/220V
Prewired ......................................................110V
Amps ....................................................18.6/9.3A
RPM ............................................................. 3450
Phase ........................................................ Single
Class ..................................................................E
Start Capacitor ........................ 400MFD 125VAC
Dimensions .............................. 1
Run Capacitor ........................... 40MFD 250VAC
Dimensions .............................. 1
Replaceable Parts
REF PART # DESCRIPTION
1 P2536001 MOTOR FAN COVER
2 P2536002 MOTOR FAN
3 P2536003 S CAPACITOR COVER
4 PC400F S CAPACITOR 400M 125V 1-3/8 X 2-3/8
5 P2536005 R CAPACITOR COVER
WARNING: NO PORTION OF THIS INSTRUCTION SHEET MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
⁄ "D x 2
3
8
⁄ "D x 3½"L
7
8
Disconnect power when
replacing motor. Failure
to do this may result in
serious personal injury.
�
�
COPYRIGHT © DECEMBER, 2007 BY GRIZZLY INDUSTRIAL, INC.
#JB10222 PRINTED IN TAIWAN
MODEL G2536
2 HP ELECTRIC MOTOR
INSTRUCTION SHEET
Electrical Safety
If you are unsure how to attach wires to terminals,
DO NOT continue. Contact a qualified electrician
for assistance. Connecting wires improperly may
cause them to come loose or contact other wires,
which can cause electrocution, fire, or a short.
⁄ "L
3
8
�
�
�
�
REF PART #
6 PC040D
7 P2536007
8 P2536008
9 P2536009
Electrocution or fire could
result if this motor is not
grounded correctly or if
your wire connections do
not comply with local and
state codes. Ensure com-
pliance by checking with a
qualified electrician!
�
�
�
DESCRIPTION
R CAPACITOR 40M 250V 1-7/8 X 3-1/2
JUNCTION BOX
CENTRIFUGAL SWITCH
CONTACT PLATE
