Page 2: Copyright
Copyright Copyright c 2004 All rights reserved This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without the express written consent of the manufacturer. -
Page 3: Table Of Contents
Table of Contents Copyright • •• • • • • •• • • • • • •• • • • • • • •••••••••• •• •• •• •• •• •• •• •• •• •• •• •• •• •• •• •• • Table of Contents •... -
Page 4: Introduction
Cotains Unpack the HAICOM 3 in 1 car holder and check that besides this Installation Manual the following components are included: Suction-arm support Cradle/dummy connector Audio Cable If anything is missing or appears damaged contact the reseller. -
Page 5: Choosing A Mounting Option
Suction-support installation overview The HAICOM 3 in 1 car holder comes with two mounting supports that allow the HAICOM 3 in 1 car holder to be installed in most car makes. Use this installation option if the cigarette lighter can not be... - Page 6 1. Align the cradle with the support plate as shown below. 2. Insert the cradle plate into the groove on the support plate at an angle (A), and push down (B). 3. Push the cradle down until it "clicks" into place.
-
Page 7: Detaching The Cradle
Detaching the cradle Follow these steps to detach the cradle from the arm fixture. 1. Pull back the tab on the 2. Slide cradle up and cradle plate to release remove it. the support plate. -
Page 8: Installing The Base Connector
Installing the base connector Each brand of PDA requires a different base connector. Consult your local dealer for details on purchasing the correct base connector for your model if needed. Refer to the following to install the base connector: 1. Release the dummy base from the cradle by lifting at tab. -
Page 9: Installing The Suction-Arm Support
Installing the suction-arm support Caution: Turn off the car's ignition before proceeding. The suction cup must be mounted on a clean, smooth surface, such as the windscreen, or the dashboard. Refer to the following: 1. Remove dirt or grease from the surface if necessary. 2. - Page 10 3. Push the locking lever towards the base to lock the support in place. 4. Insert the power adapter into the socket.
-
Page 11: Inserting Your Pda
Do you need to turn off car ignition to insert PDA? Caution: Turn off the car's ignition before proceeding. When installed in HAICOM 3 in 1 car holder, the battery in your PDA is recharged. Refer to the following to insert your PDA into the cradle: 1. -
Page 12: Removing Your Pda
Removing your PDA Refer to the following to remove your PDA from the cradle: 1. Push the release button (A) on the side of the cradle to release the padded arms. 2. Lift the PDA straight up to remove it. Caution: Do not twist the PDA as this can cause permanent damage to the connector... -
Page 13: Connecting To The Pda
Connecting to the PDA You can connect the supplied audio cable from your PDA to the FreeCruiser to avail of the HAICOM 3 in 1 car holder's built-in speaker. You can connect a GPS antenna to the HAICOM 3 in 1 car holder if you have a GPS-enabled PDA. -
Page 14: Gps Connector Pin Assignment
GPS Connector Pin Assignment Ensure the PS2 connector for your GPS receiver conforms to the pin assignments shown below. Color Function Green White Black The connector is a 6-pin Mini-DIN (male) with 3.6 ± 0.1 mm wire. IrDA Connection Installation: Setting fi...
