Sharp PN-V600A Operation Manual

Hide thumbs Also See for PN-V600A:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Setup Manual
PN-V600A
LCD MONITOR
OPERATION MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Sharp PN-V600A

Summary of Contents for Sharp PN-V600A

  • Page 1 PN-V600A LCD MONITOR OPERATION MANUAL...
  • Page 2 IMPORTANT: To aid reporting in case of loss or theft, please record the Model No.: product’s model and serial numbers in the space provided. The numbers are located in the rear of the product. Serial No.: U.S.A. ONLY FOR CUSTOMERS IN U.K. IMPORTANT The wires in this mains lead are coloured in accordance with the following code: GREEN-AND-YELLOW:...

  • Page 3: Important Information

    IMPORTANT INFORMATION WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. The lightning flash with arrowhead symbol, within a triangle, is intended to alert the user to the CAUTION presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of RISK OF ELECTRIC sufficient magnitude to constitute a risk of electric SHOCK shock to persons. DO NOT OPEN The exclamation point within a triangle is intended to alert the user to the presence of CAUTION: T O REDUCE THE RISK OF ELECTRIC important operating and maintenance (servicing)
  • Page 4 Separate collection promotes an environment-friendly treatment, recycling of materials, and minimizing final disposal of waste. IMPROPER DISPOSAL can be harmful to human health and the environment due to certain substances! Take USED EQUIPMENT to a local, usually municipal, collection facility, where available. Remove USED BATTERIES from equipment, and take them to a battery collection facility; usually a place where new batteries are sold. If in doubt about disposal, contact your local authorities or dealer and ask for the correct method of disposal. ONLY FOR USERS IN THE EUROPEAN UNION, AND SOME OTHER COUNTRIES; FOR INSTANCE NORWAY AND SWITZERLAND: Your participation in separate collection is requested by law. The symbol shown above appears on electrical and electronic equipment and batteries (or the packaging) to remind users of this. If ‘Hg’ or ‘Pb’ appears below the symbol, this means that the battery contains traces of mercury (Hg) or lead (Pb), respectively. Users from PRIVATE HOUSEHOLDS are requested to use existing return facilities for used equipment and batteries. Batteries are collected at points of sale. Return is free of charge. If the equipment has been used for BUSINESS PURPOSES, please contact your SHARP dealer who will inform you about take-back. You might be charged for the costs arising from take-back. Small equipment (and small quantities) might be taken back by your local collection facility. For Spain: Please contact the established collection system or your local authority for take-back of your used products.

  • Page 5: Dear Sharp Customer

    DEAR SHARP CUSTOMER Thank you for your purchase of a SHARP LCD product. To ensure safety and many years of trouble-free operation of your product, please read the Safety Precautions carefully before using this product. SAFETY PRECAUTIONS Electricity is used to perform many useful functions, but it can also cause personal injuries and property damage if improperly handled. This product has been engineered and manufactured with the highest priority on safety. However, improper use can result in electric shock and/or fire. In order to prevent potential danger, please observe the following instructions when installing, operating and cleaning the product. To ensure your safety and prolong the service life of your LCD product, please read the following precautions carefully before using the product. 1. Read instructions — All operating instructions must be read and understood before the product is operated. 2. K eep this manual in a safe place — These safety and operating instructions must be kept in a safe place for future reference. 3. Observe warnings — All warnings on the product and in the instructions must be observed closely. 4. Follow instructions — All operating instructions must be followed. 5. C leaning — Unplug the power cord from the AC outlet before cleaning the product. Use a dry cloth to clean the product. Do not use liquid cleaners or aerosol cleaners.
  • Page 6 SAFETY PRECAUTIONS (Continued) 1 9. Batteries — Incorrect use of batteries may cause the batteries to burst or ignite. A leaky battery may corrode the equipment, dirty your hands or spoil your clothing. In order to avoid these problems, make sure to observe the precautions below: • Use the specified batteries only. • I nstall the batteries with due attention to the plus (+) and minus (-) sides of the batteries according to the instructions in the compartment. • Do not mix old and new batteries. • Do not mix batteries of different types. Voltage specifications of batteries of the same shape may vary. • Replace an exhausted battery with a new one promptly. • If you will not use the remote control for a long time, remove the batteries. • I f leaked battery fluid gets on your skin or clothing, rinse immediately and thoroughly. If it gets into your eye, bathe your eye well rather than rubbing and seek medical treatment immediately. Leaked battery fluid that gets into your eye or your clothing may cause a skin irritation or damage your eye. 2 0. U sage of the monitor must not be accompanied by fatal risks or dangers that, could lead directly to death, personal injury, severe physical damage or other loss, including nuclear reaction control in nuclear facility, medical life support system, and missile launch control in a weapon system.

  • Page 7: Tips And Safety Instructions

    * Please contact your local Sharp servicing dealer or - I mages cannot be rotated on this monitor. service center for assistance. When using in portrait orientation, you will need to prepare appropriately orientated content in advance. - T he AC outlet shall be installed near the equipment and shall be easily accessible.

  • Page 8: Mounting Precautions

    - T o install in landscape orientation, rotate the monitor 90 installing, removing or moving the monitor. degrees to the right. - Set the MONITOR on the SETUP menu to PORTRAIT. • Mounting the monitor on the wall requires special expertise and the work must be performed by an authorized SHARP (See page 24.) dealer. You should never attempt to perform any of this - B e sure to secure the power cord (supplied) to the cable work yourself. Our company will bear no responsibility clamp attachment with the supplied cable clamp.

  • Page 9: Table Of Contents

    Turning Power On/Off ............17 Troubleshooting .............53 Turning on the main power.........17 Specifications ..............55 Turning power on/off ..........17 Mounting Precautions (For SHARP dealers and service engineers) ............60 Disabling power on/off operations ......17 Basic Operation .............18 Supplied Components If any component should be missing, please contact your dealer.

  • Page 10: Part Names

    28. External speaker terminals 29. Audio 1 input terminals 30. Audio 2 input terminals Caution 31. PC RGB input terminals • Consult your SHARP dealer for attachment/detachment of 32. AV component input terminals optional parts. 33. AV video input terminal • Do not block the fan cover. 34. AV S-video input terminal • Do not open the expansion terminal cover by yourself.
  • Page 11 Part Names n R emote control unit (Supplied with the PN-ZR01 (optional)) 1. Signal transmitter 2. POWER button 3. MUTE button 4. VOL +/Cursor control ( ) button 5. BRIGHT -/Cursor control ( ) button 6. DISPLAY button 7. MODE button 8.

  • Page 12: Connecting Peripheral Equipment

    Connecting Peripheral Equipment 1. PC/AV HDMI input terminal • Use a commercially available HDMI cable (conforming to the HDMI standard). • Set HDMI of INPUT SELECT on the OPTION menu according to the device to be connected. • Select the audio input terminal to be used in PC HDMI or AV HDMI of AUDIO SELECT on the OPTION menu. When HDMI is selected, connection to the audio input terminal is unnecessary. 2. PC D-sub input terminal • When the PN-ZB02 (optional) is attached, select the audio When the PN-ZB02 (optional) input terminal to be used in PC D-SUB of AUDIO SELECT is attached on the OPTION menu.

  • Page 13: Multiple Monitor Connection

    Connecting Peripheral Equipment Multiple monitor connection TIPS • The length of the signal cables or surrounding environment The monitors can be aligned and used as a large screen. may affect the image quality. [Example] • The screen may not display properly when using terminals other than PC DVI-D/AV DVI-D for the input mode. In this Remote control sensor box case, turn off the power to all the monitors connected in a (Supplied with the PN-ZR01 (optional)) daisy chain and then turn the power on again.
  • Page 14 Connecting Peripheral Equipment ■ Connection with RS-232 cable For the monitor in For the monitor in landscape orientation portrait orientation If you connect the monitor in a daisy chain using RS-232 cable, using the monitor buttons on the primary (main unit), settings are copied to the secondary (expansion unit) and operation from the primary can perform operation for all monitors. Setting each ID No. in the monitor is required.

  • Page 15: Preparing The Remote Control Unit

    Preparing the Remote Control Unit Installing the batteries Remote control operation range 1. Press the cover gently and slide it in the direction of the The operation range of the PN-ZR01 (optional) remote control arrow. unit is approx. 23 feet (7 m) when aimed directly at the remote control sensor box. When used at an angle of approx 10° from the center to the top/bottom/right/left of the remote control sensor, use it within a distance of approx 16.4 feet (5 m). Remote control sensor 2.

  • Page 16: Binding Cables

    Binding Cables The cables connected to the terminals on the rear of the monitor can be fastened with the cable clamps. Insert the cable clamp into the cable clamp attachment on the rear of the monitor and fasten the cables. Cable Cable clamp attachment...

  • Page 17: Turning Power On/Off

    If you already set the time but the date/time setting screen appears when the power is turned on, the internal battery may be exhausted. Please contact your local Sharp servicing dealer or service center for assistance with battery replacement. •...

  • Page 18: Basic Operation

    Basic Operation When performing operation of multiple monitors with the 1. INPUT (Input mode selection) remote control unit, first set the remote control unit to the The menu is displayed. Press to select the input appropriate remote control mode (see page 21). mode, and press to enter. Input mode Video Audio PC D-SUB PC D-sub input terminal Audio input terminal PC HDMI PC/AV HDMI input terminal AV HDMI PC/AV HDMI input terminal When the PN-ZB02 (optional) is attached Input mode Video Audio...
  • Page 19 Basic Operation 5. BRIGHT +/- (Backlight adjustment) Pressing displays the BRIGHT menu when the menu screen is not displayed. B R I G H T Press to adjust the brightness. * If you do not press any buttons for about 4 seconds, the BRIGHT menu automatically disappears. * When BRIGHTNESS SENSOR is ON or ON: DISPLAY, when the brightness is adjusted BRIGHTNESS SENSOR will become OFF. 6.

  • Page 20: Nswitching The Screen Size

    Basic Operation nSwitching the screen size Even when the screen size is changed, the display may remain the same depending on the input signal. WIDE PC input Displays image so it fills the entire screen. AV input An image with a 4:3 aspect ratio is stretched to fill the entire screen. ZOOM 1 PC input An image with a 4:3 aspect ratio is enlarged to fill the entire screen without changing the aspect ratio. The edges of the image may be cut off. AV input ZOOM 2 PC input Use this size if ZOOM 1 cuts off the subtitles. AV input NORMAL PC input Displays image so it fills the screen without changing the aspect ratio of the input signals.

  • Page 21: Remote Control Mode

    Remote Control Mode With the remote control unit it’s possible to perform operation ALL MONITORS of... Performs operation of all primary/secondary monitors. • The primary monitor will be displayed on the menu of the primary. • Monitors with a specified ID No. * W hen it receives signals from the remote control unit, • All primary/secondary monitors “Operating all monitors.” will be displayed on the secondary It’s necessary to specify which type of operation will be screen. (Excluding power and input mode selection operation) performed in advance.

  • Page 22: Menu Items

    Menu Items Displaying the menu screen TIPS • The menu will differ depending on the input mode. Video and audio adjustment and settings of various functions • The menu screen will close automatically if no operation is are enabled. This section describes how to use the menu performed for about 15 seconds. (DATE/TIME SETTING, items. See pages 23 to 27 for details of each menu items. SCHEDULE and LAN SETUP screens will close in about 4 minutes.) Caution nMenu screen display • Do not turn the main power switch off while the menu items are being displayed. Doing so may initialize the settings.

  • Page 23: Menu Item Details

    Menu Items Menu item details nPICTURE You can move the menu screen display position each time The menu will differ depending on the input mode. DISPLAY is pressed. nSCREEN AUTO (PC D-SUB/PC RGB) The ANALOG GAIN and ANALOG OFFSET are You can move the menu screen display position each time automatically adjusted.
  • Page 24 Menu Items USER SCREEN MOTION Adjusts each item when the WHITE BALANCE is set to Residual images are reduced by moving the screen. USER. PATTERN1 ..The whole screen moves vertically and R-CONTRAST ..Adjusts bright-toned red component. horizontally. G-CONTRAST ..Adjusts bright-toned green component. PATTERN2 ..A black screen spreads from the bottom of B-CONTRAST ..Adjusts bright-toned blue component. the screen and then shrinks to the bottom of R-OFFSET ..Adjusts dark-toned red component.
  • Page 25 Menu Items OFF IF NO OPERATION BRIGHTNESS SENSOR SETTING (When connected to the PN-ZR01 (optional) only) Determines whether or not to set the monitor to go into Performs adjustments to the brightness sensor. Performs standby mode when there is no operation from the remote operation with the primary monitor. control unit, RS-232C commands, or LAN for over 4 hours. Set the surrounding brightness and the current screen HOT PLUG CONTROL luminance to AMBIENT BRIGHTNESS and SCREEN Sets whether to use hot plug control for the PC/AV HDMI...
  • Page 26 Menu Items nOPTION AUDIO OUTPUT(RCA) Sets the volume of sound output from the audio output DATE/TIME SETTING terminals. When set to VARIABLE2, audio is not output from Set the date and time. Press to select the date the external speaker terminals. and time, and press to change the numerical VARIABLE ..
  • Page 27 Menu Items nMULTI nPIP/PbyP ENLARGE (See page 28.) PIP MODES Sets whether or not to use the enlarge function. Sets the display method. OFF ..Displays one screen. ADVANCED (ENLARGE) PIP ...Displays a sub screen inside a main screen. ENLARGE H / ENLARGE V PbyP ..Displays a main screen and a sub screen in a line..Sets the number of screen splits (number of PbyP2 ..Displays a main screen which measures 1024 pixels monitors) in the horizontal/vertical direction used for in the longest direction and a sub screen in a line.

  • Page 28: Ndual Screen Display

    Menu Items nDual screen display nEnlarge You can display the screens of the PC input signal and AV • You can align several monitors and integrate them into a input signal simultaneously. single large screen to display. Set this function with “PIP MODES” in the PIP/PbyP menu. • Up to five monitors can be aligned in both the horizontal and vertical directions. A sub screen is displayed • Each monitor displays enlarged views of separated images. inside a main screen. Main screen (Example) Horizontal direction: 2 monitors screen Vertical direction: 2 monitors PbyP...
  • Page 29 Menu Items nZOOM2 SPECIAL SETTING (3) DAY OF THE WEEK Specifies the day of the week to execute the SCHEDULE. If you connect a laptop computer with any of the following 0: ONLY ONCE screen resolutions and black bands appear around the Executes the SCHEDULE once on the specified day. screen, set ZOOM2 SPECIAL SETTING of INPUT SIGNAL on Specify the day of the week to execute the SCHEDULE. the OPTION menu to ON and then select ZOOM2 in the SIZE 1: EVERY WEEK setting. Executes the SCHEDULE on the specified day of the week This displays the area inside the black band. every week.

  • Page 30: Adjustments For Pc Screen Display

    Menu Items nADVANCED items (AV input) (See page 23 Adjustments for PC screen display for additional Menu item details.) nAutomatic adjustment FLESH TONE When you use the PC D-sub input terminal or PC RGB input Adjust the hue control. terminals to display a PC screen for the first time, or when 3D-NR you change the setting of the PC, use the automatic screen adjustment. Reduce the noise of playback images on video. 1. Switch the input to PC D-SUB or to PC RGB and display Setting a higher level reduces more noise. However, it may the adjustment pattern.

  • Page 31: Initialization (Reset)/Functional Restriction Setting (Function)

    Initialization (Reset)/Functional Restriction Setting (FUNCTION) You can return the settings to their factory-preset values and RS-232C restrict operations. (RS-232C/LAN when the PN-ZB02 (optional) is attached) SIZE 1. If using the remote control unit, press until “F” Specifies whether to allow control via RS-232C or LAN is displayed in the upper left area of the screen, then (see pages 32 and 45). while “F”...

  • Page 32: Controlling The Monitor With A Pc (Rs-232C)

    Controlling the Monitor with a PC (RS-232C) Communication conditions You can control this monitor from a PC via RS-232C (COM port) on the PC. You can also connect multiple monitors via a daisy chain by Set the RS-232C communication settings on the PC to match using a PC. By assigning ID numbers to each monitor (see the monitor’s communication settings as follows: page 34), you can make input mode selection/adjustment or Baud rate Stop bit 1 bit can check the status of a specific monitor. Data length 8 bits Flow control None Precautions when the PN-ZB02 (optional) is attached Parity bit...
  • Page 33 Controlling the Monitor with a PC (RS-232C) nResponse code format When RS-232C/LAN SELECT is set to LAN When a command has been executed correctly Return code Return code , 0A , 0A A response is returned after a command is executed. nCommunication interval * If an ID number has been assigned • After OK or ERR is returned, you must send the following...
  • Page 34 Controlling the Monitor with a PC (RS-232C) nCommands for ID control Advanced operation This section explains commands for daisy chain connection. The command examples shown on this page assume the The basic communication procedure is the same as in the following connection and ID number set up.
  • Page 35 Controlling the Monitor with a PC (RS-232C) nRepeater control IDLK ..The parameter of this command sets the ID number of the monitor. The monitor is subject to all This system has a function to allow setting of multiple subsequent commands. monitors connected in a daisy chain using a single command. This function is called repeater control. You can use Repeater Example: control function without assigning ID numbers.

  • Page 36: Setting Of The Gamma User Data

    Controlling the Monitor with a PC (RS-232C) nRepeater control command Setting of the GAMMA user data Repeater control is achieved by setting the FOURTH nTo transfer the GAMMA user data CHARACTER of the parameter to “+”. Use the user data transfer commands (UGRW, UGGW and Example: UGBW). For each of the R, G and B colors, divide the total 512 pieces of user data into 16 blocks, and transfer 32 pieces VOLM030 + ← Sets volume of all monitors to 30. of data with each command. In repeater control, responses are returned by all the …...

  • Page 37: Rs-232C Command Table

    Controlling the Monitor with a PC (RS-232C) RS-232C command table How to read the command table Command: Command field (See page 32.) Direction: W When the “Parameter” is set in the parameter field (see page 32), the command functions as described under “Control/Response Contents”. R The returned value indicated under “Reply” can be obtained by setting “????”, “ ?” or “???+” (repeater control) in the parameter field (see page 32). Parameter: Parameter field (See page 32.) Reply: Response (Returned value) *1:...

  • Page 38: Screen Menu

    Controlling the Monitor with a PC (RS-232C) SCREEN menu Function Command Direction Parameter Reply Control/Response contents (A) (B) AUTO ASNC When the input mode is PC D-SUB, PC RGB. CLOCK CLCK 0-1200 0-1200 When the input mode is PC D-SUB, PC RGB. Varies depending on the signal. PHASE PHSE 0-63 0-63 When the input mode is PC D-SUB, PC RGB. POSITIONING POSITION OF HPOS 0-100 0-100 0-800 on PC D-SUB, PC RGB. THE LONGEST Varies depending on the signal. DIRECTION POSITION OF VPOS...

  • Page 39: Picture Menu

    Controlling the Monitor with a PC (RS-232C) PICTURE menu Function Command Direction Parameter Reply Control/Response contents (A) (B) AUTO AGIN When the input mode is PC D-SUB, PC RGB. ANALOG GAIN ANGA 0-127 0-127 When the input mode is PC D-SUB, PC RGB. ANALOG OFFSET ANOF 0-127 0-127 When the input mode is PC D-SUB, PC RGB. CONTRAST CONT 0-60 0-60 BLACK LEVEL BLVL 0-60 0-60 TINT TINT 0-60 0-60...

  • Page 40: Audio Menu

    Controlling the Monitor with a PC (RS-232C) AUDIO menu Function Command Direction Parameter Reply Control/Response contents (A) (B) TREBLE AUTR -5-5 -5-5 ○ BASS AUBS -5-5 -5-5 ○ ○ BALANCE AUBL -10-10 -10-10 RESET ARST SETUP menu Function Command Direction Parameter Reply Control/Response contents...

  • Page 41: Option Menu

    Controlling the Monitor with a PC (RS-232C) OPTION menu Function Command Direction Parameter Reply Control/Response contents (A) (B) DATE/TIME SETTING DATE AABBCCDDEE AABBCCDDEE AA: Year, BB: Month, CC: Day, DD: Hour, EE: Minute 0: YYYY/MM/DD, 1: MM/DD/YYYY, 2: DD/MM/YYYY DATE DISPLAY FORMAT DTFT YYYY: Year, MM: Month, DD: Day TIME DISPLAY FORMAT TMFT 0-1 0: 24-HOUR TIME, 1: 12-HOUR TIME SCHEDULE SC01- ABCDEFFGGH ABCDEFFGGH Schedule of a specified number A: Schedule 0= Not effective, 1 = Effective SC08 B: Power 0 = OFF, 1 = ON C: Day of the week 1 0 = Only once, 1 = Every week, 2 = Every day D: Day of the week 2 0 = Sunday, 1 = Monday through 6 = Saturday,...
  • Page 42 Controlling the Monitor with a PC (RS-232C) MULTI menu Function Command Direction Parameter Reply Control/Response contents (A) (B) ENLARGE ENLG 0-1 0: OFF, 1: ON ENLARGE MODE EMAG 0-4 0: OFF, 1: 2 x 2, 2: 3 x 3, 3: 4 x 4, 4: 5 x 5 EMHV 11-55 11-55 1 x 1 (OFF) to 5 x 5 (“m x n” is expressed as “mn”, where m and n are the numbers of monitors specified for the longest direction and the shortest direction respectively.) IMAGE POSITION (M x N) EPHV 11-55 11-55 Specifies values in the order of IMAGE POSITION IN LONGEST/ SHORTEST DIRECTION. IMAGE POSITION (2 x 2) EPOS 0-3 See the description below.
  • Page 43 Controlling the Monitor with a PC (RS-232C) PIP/PbyP menu Function Command Direction Parameter Reply Control/Response contents (A) (B) ○ PIP MODES MWIN 0-3 0: OFF, 1: PIP, 2: PbyP, 3: PbyP2 ○ PIP SIZE MPSZ 1-64 1-64 ○ PIP POS THE LONGEST MHPS 0-100 ○ DIRECTION 0-100 ○ THE SHORTEST MVPS 0-100 ○...
  • Page 44 Controlling the Monitor with a PC (RS-232C) Others Function Command Direction Parameter Reply Control/Response contents (A) (B) ○ SCREEN SIZE (PC) WIDE 1-5 1: WIDE, 2: NORMAL, 3: Dot by Dot, 4: ZOOM1, 5: ZOOM2 ○ SCREEN SIZE (AV) WIDE 1-5 1: WIDE, 2: ZOOM1, 3: ZOOM2, 4: NORMAL, 5: Dot by Dot ○ VOLUME VOLM 0-31 0-31 MUTE MUTE 0-1 0: OFF, 1: ON INFORMATION MODEL INF1 Value ●...

  • Page 45: Controlling The Monitor With A Pc (Lan)

    Controlling the Monitor with a PC (LAN) Settings to connect to a LAN When the PN-ZB02 (optional) is attached, your monitor can be connected to a LAN allowing you to control it from a PC on the LAN. Set the monitor’s IP address and subnet mask to match the You can also configure the monitor to send e-mail notification settings of your LAN. when it has a problem. These settings can be made on either the monitor or a PC The connection requires a commercially available LAN cable connected to the monitor.
  • Page 46 Controlling the Monitor with a PC (LAN) ■ To set from a PC 7. Temporarily change the IP address and subnet mask. To access the monitor as it is shipped from the factory, set When the monitor is connected to a PC, LAN settings can be as follows. configured via PC. • IP Address: 192.168.150.1 • Subnet Mask: 255.255.255.0 Set up process • Default Gateway: (leave blank)

  • Page 47: Controlling With A Pc

    Controlling the Monitor with a PC (LAN) Controlling with a PC 7. Specify the “DHCP CLIENT”, “IP ADDRESS”,etc. ■ Basic operation You use Internet Explorer on a PC on the LAN to control the monitor. 1. Launch Internet Explorer on the PC. 2. In the “Address” box, type “http://” followed by your monitor’s IP address followed by “/”, then press the Enter key. You can confirm the IP address with the DISPLAY function. When prompted to enter a user name and password, type the user name and password that you specified in the security settings (see page 49), and click [OK]. If you did not make any security settings, leave the spaces blank and click on [OK].
  • Page 48 Controlling the Monitor with a PC (LAN) ■ INFORMATION ■ ADJUSTMENT Information about this monitor appears. You can adjust these settings which are also available on the monitor’s menu. • SCREEN (See page 23.) • PICTURE (See page 23.) • PICTURE (ADVANCED) (See page 30.) • AUDIO (See page 24.) • SETUP (See page 24.) • OPTION (See page 26.) • SCHEDULE (See page 29.) • MULTI (See page 27.) • PIP/PbyP (See page 27.) • FUNCTION (See page 31.) ■ CONTROL You can control the operations corresponding to the buttons POWER INPUT SIZE...

  • Page 49: Network (Lan Setup)

    Controlling the Monitor with a PC (LAN) ■ NETWORK (LAN SETUP) ■ NETWORK (SECURITY) This screen allows you to set the settings necessary when the This screen allows you to specify the security-related settings. monitor is connected to a LAN. USER NAME / PASSWORD DHCP CLIENT Sets up a user name and password to restrict access to this If your LAN has a DHCP server and you wish to obtain an monitor.

  • Page 50: Network (General)

    Controlling the Monitor with a PC (LAN) ■ NETWORK (GENERAL) ■ MAIL (ORIGINATOR) This screen allows you to specify the general LAN settings. This screen allows you to configure the e-mail sent periodically or when the monitor has an error. The settings depend on the configuration of your LAN. Ask your LAN administrator for details. MONITOR NAME Specify a name for this monitor as it should appear on the SMTP SERVER Internet Explorer screen.

  • Page 51: Mail (Recipient)

    Controlling the Monitor with a PC (LAN) ■ MAIL (RECIPIENT) ■ MAIL (PERIODICAL) This screen allows you to specify the recipients of the e-mail When PERIODICAL for CONDITION of MAIL (RECIPIENT) is sent periodically or when the monitor has an error. checked, set the date and time to send the mail. RECIPIENT E-MAIL ADDRESSES DAY OF THE WEEK Specify the e-mail addresses to send error notification e-mail Specify the day of the week to send the periodical mails.
  • Page 52 Controlling the Monitor with a PC (LAN) ■ SNMP Caution You can configure settings related to SNMP. • After you set SNMP, click [Switch the main power of monitor off and on now.] or turn off the monitor and then turn it on again with the main power switch. When the monitor restarts, wait about 30 seconds and then start the next operation. • If the IP address is changed while the SNMP function is operational, turn off the monitor and then turn it on again with the main power switch. TIPS • Depending on the SNMP settings, a short delay may occur before the SNMP is usable. (About 2 minutes) • Up to 16 alphanumeric letters and symbols can be used for the community name, user name and password.

  • Page 53: Troubleshooting

    Power LED flashes red. • Check the setting of BALANCE for AUDIO menu. (See “STATUS [xxxx]” appears in the corner of the screen. page 24.) • Hardware has a problem. Turn off the monitor and request There is a picture but no sound. repair from your SHARP dealer. • Is the sound muted? (When STATUS ALERT is set to OSD & LED. This varies • Make sure the volume is not set to minimum. depending on the setting.) • Are audio cables connected properly? When “AUTO DIMMING” is displayed.
  • Page 54 The monitor, however, will enter standby mode again if the cause of the temperature rise is not eliminated. - C heck whether the monitor is placed at a location where a quick rise in temperature is likely. Internal temperature rises quickly if the vents on the monitor are blocked. - I nternal temperature rises quickly if dust accumulates inside the monitor or around the vents. Remove dust if possible. Ask SHARP dealer about removing internal dust.

  • Page 55: Specifications

    Specifications nPN-V600A Product Specifications Model PN-V600A LCD component 60" Class [60 inch (152.4cm) diagonal] TFT LCD Max. resolution (pixels) 1366 x 768 Max. colors Approx. 16.77 M colors 0.973 mm (H) × 0.973 mm (V) Pixel pitch Viewing angle 176° right/left/up/down (contrast ratio ≥ 10) Screen active area inch (mm) 52-5/8 x 29-7/16 (1328.8 x 747.1) Computer input signal Digital (DVI 1.0 standard-compliant), Analog RGB (0.7 Vp-p) [75 Ω] Sync signal Horizontal/vertical separate (TTL: positive/negative), Sync-on-green, Composite sync (TTL: positive/negative) NTSC (3.58MHz)/NTSC (4.43MHz)/PAL/PAL-60/SECAM Video color system Plug and play VESA DDC2B Power management...
  • Page 56 [200] 3-5/8 3-15/16 3-15/16 52-5/8 [1335.9] [100] [100] [92.3] Opening width (52-5/16 [1329.4]) When mounting the monitor, be sure to use a wall-mount bracket that complies with the VESA-compatible mounting method. SHARP recommends using M6 screws and tighten the screws. Note that screw hole depth of the monitor is 3/8 inch (10 mm). Loose mounting may cause the product to fall, resulting in serious personal injuries as well as damage to the product. The screw and hole should come together with over 5/16 inch (8 mm) length of thread. Use a bracket which has been approved for UL1678 standard, and which can endure at least 4 times or more the weight of the monitor. nPower management This monitor conforms to VESA DPMS and DVI DMPM. Both your video card and computer must support the same standard in order for the monitor’s power management function to work. DPMS: Display Power Management Signaling DMPM: Digital Monitor Power Management Power...
  • Page 57 Specifications nCompatible signal timing (PC) Digital Analog Screen resolution Hsync Vsync Dot frequency (D-SUB/RGB* DVI* HDMI VESA 640 × 480 31.5kHz 60Hz 25.175MHz 37.9kHz 72Hz 31.5MHz 37.5kHz 75Hz 31.5MHz 800 × 600 35.1kHz 56Hz 36.0MHz 37.9kHz 60Hz 40.0MHz 48.1kHz 72Hz 50.0MHz 46.9kHz 75Hz...
  • Page 58 Specifications nCompatible signal timing (AV) Screen resolution Frequency DVI-D* HDMI Component 1920 × 1080p 24Hz 50Hz 59.94Hz 60Hz 1920 × 1080i 50Hz 59.94Hz 60Hz 1280 × 720p 50Hz 59.94Hz 60Hz 720 × 576p 50Hz 720 × 480p 59.94Hz 60Hz 640 × 480p(VGA) 59.94Hz 60Hz 720(1440) × 576i 50Hz 720(1440) × 480i 59.94Hz 60Hz *1 Displays a reduced image, except in Dot by Dot. In Dot by Dot, the image will be cut down to panel size then displayed. *2 Available when the PN-ZB02 (optional) is attached.
  • Page 59 Specifications PC/AV DVI-D input terminal pins PC/AV HDMI input terminal pins (DVI-D 24 pin) (HDMI Connector) Function Function Function Function TMDS data 2- 13 N.C. TMDS data 2+ TMDS clock shield TMDS data 2+ 14 +5V TMDS data 2 shield 12 TMDS clock- TMDS data 2/4 shield 15 GND TMDS data 2- 13 CEC N.C. 16 Hot-plug detection TMDS data 1+ 14 N.C.

  • Page 60: Mounting Precautions (For Sharp Dealers And Service Engineers)

    Mounting Precautions (For SHARP dealers and service engineers) • When installing, removing or moving the monitor, ensure that this is carried out by at least 2 people. • Be sure to use a wall-mount bracket designed or designated for mounting the monitor. • This monitor is designed to be installed on a concrete wall or pillar. Reinforced work might be necessary for some materials such as plaster / thin plastic board / wood before starting installation. This monitor and bracket must be installed on a wall which can endure at least 4 times or more the weight of the monitor.
