- Page 1 E4H-CE AND E8-CE SERIES WATER PURIFICATION MACHINES /hr to 45 m 18,000 gpd to 288,000 gpd Operation and Maintenance Manual...
-
Page 3: Table Of Contents
INSTRUCTIONS FOR E4H-CE AND E8-CE OPERATION AND MAINTENANCE MANUAL DESCRIPTION Definitions 1.1.1 Permeate Rate 1.1.2 Concentrate Rate 1.1.3 Feed Rate 1.1.4 Reverse Osmosis 1.1.5 Membrane Elements 1.1.6 Clean-In-Place 1.1.7 Flow Control Center 1.1.8 Average Pressure 1.1.9 Concentration 1.1.10 Salt (Ionic) Passage 1.1.11 Recovery 1.1.12 Salt (Ionic) Rejection Machine Nomenclature... - Page 4 MACHINE OPERATION AND MAINTENANCE Daily Log Sheets Pre-Filter Cartridge Cleaning Draining Machine for Shipment Membrane Element Replacement Membrane Element Removal FIELD INSTALLED ACCESSORIES Pretreatment Shutdown Permeate Flush Chemical Pump Clean-In-Place Installation TROUBLESHOOTING FORMS Return Goods Authorization (RGA) Start-Up Data Sheet Daily Log Sheet WARRANTY/GUARANTEE Warranty Terms...
- Page 5 Figure Title Normal Versus Cross Flow Filtration Membrane Element With Interconnectors Principles of Operation Figure Title Flow Specifications for E-CE Reverse Osmosis Machines Minimum/Maximum Boost Pressure Membrane Element Specifications Feed Water Requirements Connections LIST OF FIGURES LIST OF TABLES Page...
-
Page 6: Description
DESCRIPTION E-CE Series Reverse Osmosis (RO) machines are durable pieces of equipment, which, with prop- er care, will last for many years. These instructions give operation and maintenance details vital to the sustained performance of the machine. Please read completely before operating your machine. -
Page 7: Membrane Elements
1.1.5 Membrane Elements Membrane elements are interleaved layers of semi-permeable membrane, spacer, and permeate carrier spiraled around a central permeate tube make up the mem- brane element. Membrane Element with Interconnectors 1.1.6 Clean-In-Place The abbreviation for Clean-In-Place is CIP. 1.1.7 Flow Control Center The Flow Control Center features a concentrate flow control valve, a recycle flow control valve, and a pressure gauge. -
Page 8: 1.1.10 Salt (Ionic) Passage
Feed Concentration Permeate Concentration Concentrate Concentration Average Concentration in Machine 1.1.10 Salt (Ionic) Passage Ionic Salt Passage equals the percent of dissolved salts passed through the mem- brane element or 100% minus rejection. 1.1.11 Recovery Recovery equals permeate rate divided by feed rate and is expressed as a per- centage. - Page 9 Rejection [(237.5 mg/L) + (8.3 mg/L)] x 100 96.5% Passage ) x 100 (8.3 mg/L) x 100 (237.5) 3.5% Recovery ) x 100 (18 gpm) x 100 (24gpm) ) - (C )] x 100 (237.5)
-
Page 10: Machine Nomenclature
Machine Nomenclature E-CE Series water purification machines are numbered in such a way as to indicate the permeate flow you can expect from the machine and other specifications: Example: RE, E8-CE-9, 400, 5, 66 - 75 Machine Type (Reverse Osmosis) Machine Series CE-E Series (E8: 8-inch housings/membrane elements) - Page 11 · Multi-stage centrifugal pump, SS construction (SS end castings and wetted parts, Noryl* internals) on the 3 to 3 to 34m on the 45m · Electrical package includes Programmable Logic Controller (PLC), IEC66 control enclosure with a 24VDC control circuit, Siemens TP070 operator interface terminal, and a Siemens S7-200 PLC.
-
Page 12: Specifications For E-Ce Series Machines
Specifications for E-CE Series Machines The machine flow specifications listed, Table 1.1 below, are based on 25°C (77°F) and 2000 ppm NaCl. MODEL E4H-CE-3 E4H-CE-% Recovery 50-75% Units LPM/GPM Permeate 47.4/12.5 Rate Concentrate 47.4/12.5 Rate (50-66%) Concentrate 15.8/4.2 Rate (75%) Feed Rate 94.7/25.0 (50-66%) -
Page 13: Feed Water Specifications
1.4.1 Feed Water Specifications The feed water requirements listed in Table 1.1 must be met to ensure quality per- meate and extended membrane element life. 1.4.2 Permeate Flow Rate Stated in Table 1.1 and on the machine serial number label (assumes no permeate back pressure, 2000 mg/L Total Dissolved Solids (TDS) maximum feed concen- tration, and rated temperature). -
Page 14: Reverse Osmosis Membrane Element Rejection
1.4.5 Reverse Osmosis Membrane Element Rejection E8-CE RO machines use Fiberglass Reinforced Plastic (FRP). E4H-CE RO machines use tape wrapped membrane elements. For more information, refer to the Spare Parts List (P/N 1233377). Specification Outer Cover Material Typical Ionic Rejection (TDS) Nominal Permeate Flow Rate [at 7.6 bar (110 psi)] Typical Feed Water... -
Page 15: Installation
INSTALLATION The following installation guidelines will help you install your new E-CE RO machine. Feed Water Requirements The following feed water requirements must be met before installing your new E-CE RO machine to ensure quality permeate and extended membrane element life. Temperature Inlet Pressure Chlorine (continuous feed) -
Page 16: Plumbing
membrane element housings for removal and loading of membrane elements. If 114 cm (45-inches) are not available, the entire membrane element housing may need to be removed for membrane element replacement. Plumbing The E4H-CE and E8-CE come with flanged connections installed on all isolation valves. MACHINE E4H-CE Model... -
Page 17: Preparation For Start-Up
If the machine is to be run at a different location than was originally intended, a new water analysis is required for warranty considerations and should be sent to GE Osmonics for review and recommen- dations for operation of the machine. - Page 18 STEPS Recheck the function and integrity of your pretreatment equipment. Ensure that your water softener, activated carbon filters, and iron filters (where applicable) have been leaked checked, back washed, and thoroughly rinsed for service before starting up your RO unit. Attach the feed water pipe to the inlet of the machine.
- Page 19 It is also important to understand the relationship of these two valves, the pressure gauge, and your RO pump. The pump has a fixed amount of flow produced, and the valves are the control devices to distribute this fixed flow amount. The pres- sure gauge is an indicator of applied membrane element pressure a the flows set by the valves Press the Fill Button on the OIT so it is in the ON position.
- Page 20 Sheet (Section 7.3), including general operating conditions (pressures, flow, con- centrations, pH, and pretreatment conditions) and routine or special maintenance (flushing or cleaning as needed) must be kept. GE Osmonics will require these Log Sheets if a warranty question arises.
-
Page 21: Daily Start-Up
Daily Start-Up Check the machine to insure isolation valves are in the proper positions for operation. To turn the RO ON, press the RO button so it is in the ON position. If the alarm light is lit, push the “Alarm Reset” switch on the control enclosure and the alarm button on the OIT. -
Page 22: Machine Operation And Maintenance
A pressure drop across the filter of 0.6 barg (8.7 psig) or more during operation indicates that the pre-filters cartridge(s) need chang- ing. Use only GE Osmonics approved filters rated for 5 microns or less. Do not attempt to clean used filters. Install new replacements. - Page 23 GE Osmonics recommends cleaning at least every month to assure good membrane element performance and long membrane element life. GE Osmonics offers a full line of chemical cleaners for specific cleaning needs. Refer to the Spare Parts List (P/N 1233377).
-
Page 24: Draining Machine For Shipment
Draining Machine for Shipment Prior to shipping or outside storage of a GE Osmonics E-CE RO machine, the system should be cleaned with the appropriate cleaner, flushed with water, and protected from biological attack with the appropriate solution. - Page 25 Cut the bag open as close as possible to the seal at the end of the bag, so that the bag may be reused if necessary. Remove the membrane element from the bag and remove the foam protectors from each end of the membrane element. Remove the parts from the parts container (if included) and inspect.
-
Page 26: Membrane Element Removal
Membrane Element Removal As time progresses, the efficiency of the membrane element will be reduced. In general, the salt rejection does not change much until two or three years after installation, when operated on properly pretreated feed water and routine maintenance performed. The per- meate flow rate will begin to decline slightly after one year of operation, but can be extended with diligent flushing and cleaning of the machine. -
Page 27: Field Installed Accessories
FIELD INSTALLED ACCESSORIES Pretreatment Shutdown E-CE Series RO machines are equipped with Pretreatment Shutdown control capability. Pretreatment Shutdown is the ON/OFF control of the RO via a signal from a remote device. External Control can be used when Permeate Flush is not desired prior to RO shutdown (Permeate Flush, Section 5.2). - Page 28 RO shutdown. Level control of a permeate storage tank is GE Osmonics’ standard external control device which activates the purge shutdown. Any other remote device(s) can be used where per- meate purge is desired prior to RO shutdown.
-
Page 29: Chemical Pump
Permeate Purge Cycle. Chemical Pump GE Osmonics offers a stand-alone chemical pump and tank that can be used to control the pH of the RO system. Refer to the Spare Parts List (P/N 1233377) for ordering informa- tion. -
Page 30: Troubleshooting
The operator can easily correct many of these problems, howev- er, for those that persist or are not understood you should contact the GE Osmonics Customer Support Center. Have the following information available when calling the Customer Support Center: 1. - Page 31 SYMPTOM Low operating pressure (continued) Low permeate flow rate TROUBLESHOOTING POSSIBLE CAUSES Insufficient electrical power Pump not operating correctly Low operating pressure Dirty or fouled membrane elements Operating on cold water less than 13°C (55°F) Membrane elements installed backward or damaged concen- trate seal Flow meter inaccurate REMEDIES...
- Page 32 SYMPTOM Low permeate flow rate (continued) Low concentrate flow rate, normal or higher than normal pressure TROUBLESHOOTING POSSIBLE CAUSES Operating on cold water less than 13°C (55°F) Membrane elements installed backward or damaged concen- trate seal Concentrate valve plugged Concentrate outline line restricted Flow meter inaccurate Dirty concentrate valve...
- Page 33 SYMPTOM High operating pressure Water flowing when machine is turned OFF Declining rejection (high permeate conductivity) TROUBLESHOOTING POSSIBLE CAUSES Recycle or concentrate valve plugged Inaccurate pressure gauge Restricted flow after pump outlet Telescoped membrane ele- ment covering membrane ele- ment housing outlet port Inlet solenoid valve not clos- ing or seating properly Severely fouled or dirty...
- Page 34 Open the concentrate valve and flush. Test the water for pH, hardness, TDS, and iron content. A water analysis should be sent to GE Osmonics for review. Calibrate the monitor with a DS standard solution or check the readings with another conductivity meter.
- Page 35 Check the fuses or circuit breakers, measure the voltage. See Tonkaflo pump instruc- tions. Contact GE Osmonics for possible repair or replacement. Check for minimum inlet pressure and push alarm reset switch. Restart the machine by pushing the alarm bypass.
- Page 36 SYMPTOM Electrical machine shut down (continued) Conductivity drifts or changes after calibration Display is blank pH reading is off by more than 1pH unit TROUBLESHOOTING POSSIBLE CAUSES Motor starter overloaded, heater tripped. Calibration may have been done before the reading stabi- lized The stable line may contain electrical noise...
- Page 37 TROUBLESHOOTING SYMPTOM POSSIBLE CAUSES REMEDIES Chemical pump will not Pumping may be affected by Is the relay turned ON or feed chemical other software variables OFF? Is the CIP input activated? You must have permeate or concentrate flow for a relay configured as a set point to function and trigger the pump.
-
Page 38: Forms
GE Osmonics. Call GE Osmonics at (800) 848 - 1750 and ask to speak with Customer Service. A GE Osmonics Customer Service representative will provide instructions and a return goods authorization number, which needs to be clearly written on the outside of the box used to ship your materials. -
Page 39: Start-Up Data Sheet
Start-Up Data Sheet E - S E R I E S S T A R T - U P D A T A S H E E T Customer: Model Number: Serial Number: Units (Circle One) Permeate Rate Total Flow Rate Pre-Filter Pressure Post-Filter Pressure Primary Pressure... -
Page 40: Daily Log Sheet
Daily Log Sheet... -
Page 41: Warranty/Guarantee
WARRANTY Warranty Terms Subject to the terms and conditions set forth hereinafter, Seller (GE Osmonics, Inc. or any of its authorized subsidiaries) warrants to the original purchaser (hereafter the “Buyer”) that the products manufactured by Seller are free from defects in material and in work-... -
Page 42: Voidability Of Warranty
discretion, be the sole judge of whether a returned product or component is defective in material or workmanship. Required or replaced products or components shall be returned freight. In genuine emergency situation, Seller will (at Seller’s sole option) forward replacement parts to Buyer without waiting for authorized return of the questionable part(s). - Page 43 REMEDIES FOR BREACH OF ANY WARRANTY OR OTHER OBLIGATION HERE- UNDER EXPRESS OR IMPLIED OR FROM THE OPERATION OF LAW. Any questions about this Warranty and all warranty service returns should be addressed GE OSMONICS, INC. Minnetonka Operations Attn: Customer Service Center...
