Panasonic TY-FB8HM Product Specification

HDMI Terminal Board
Product summary
• Enables full digital playback of signals from digital video equipment via an HDMI terminal, for displaying
on a plasma display without bleeding or blurring.
• It enables transfer of video and audio with a single cable.
Product specification (design and specification subject to change without notice)
Slot Compatibility
2 Slot model
3 Slot model
INPUT
Compatible video format
Compatible audio format
Weight
Included Accessories
Dimensions
Slot 1, Slot 2
Slot 1, Slot 2 (Slot 3 is not compatible)
HDMI TypeA x 1
525/60p, 625/50p, 750/60p, 1125/60i, VGA60, 750/50P, 1125/50i
Linear PCM : 48/44.1/32 kHz
Approx. 250 g (0.55 lbs.)
Terminal function label x 1, Terminal board replacement instructions x 1,
Slot cover x 1
104.5 (4.11)
HDMI INPUT terminal
TY-FB8HM
Cautions: This drawing is not a scale.
Units : mm (inches)
TY-FB8HM (
EU_M070913
