Parts Guide - Sharp MD-MX30 Service Manual

To have your order filled promptly and correctly, please furnish the
following information.
1. MODEL NUMBER
3. PART NO.
MARK: SPARE PARTS-DELIVERY SECTION
Explanation of capacitors/resistors parts codes
Capacitors
VCC ....................... Ceramic type
VCK ........................ Ceramic type
VCT ........................ Semiconductor type
VC • • MF ............... Cylindrical type (without lead wire)
VC • • MN ............... Cylindrical type (without lead wire)
VC • • TV ................ Square type (without lead wire)
VC • • TQ ............... Square type (without lead wire)
VC • • CY ............... Square type (without lead wire)
VC • • CZ ............... Square type (without lead wire)
VC • • • • • • • • • J .. The 13th character represents capacity difference.
("J" 5%, "K" 10%, "M" 20%, "N" 30%,
"C" 0.25 pF, "D" 0.5 pF, "Z" +80-20%.)
If there are no indications for the electrolytic capacitors, error is 20%.
NOTE:
Parts marked with " " are important for maintaining the safety of the set.
Be sure to replace parts with specified ones for maintaining the safety and performance of the set.

PARTS GUIDE

MODEL
"HOW TO ORDER REPLACEMENT PARTS"
2. REF. No.
4. DESCRIPTION
"CAUTION:FOR CONTINUED PROTECTION AGAINST
FIRE HAZARD, REPLACE ONLY WITH SAME TYPE
F801,F802 4A, 125V / F803 2.5A, 125V or 250V FUSES."
"ATTENTION:POUR ASSURER UNE LONGUE
PROTECTION CONTRE UN INCENDIE, REMPLACER
SEULEMENT PAR UN FUSIBLE DE TYPE F801,F802 4A,
125V / F803 2.5A, 125V ou 250V"
– 91 –
MD-MX30
MODEL
MD-MX30 MD Compact Component System
consisting of MD-MX30(main unit) and CP-
MX30(speaker system).
MD-MX30W
MD-MX30W MD Compact Component System
consisting of MD-MX30W(main unit) and CP-
MX30W(speaker system).
For U.S.A. only
Contact your nearest SHARP Parts Distributor to order.
For location of SHARP Parts Distributor,
Please call Toll-Free;
1-800-BE-SHARP
Resistors
VRD ....................... Carbon-film type
VRS ........................ Carbon-film type
VRN ....................... Metal-film type
VR • • MF ............... Cylindrical type (without lead wire)
VR • • MN ............... Cylindrical type (without lead wire)
VR • • TV ................ Square type (without lead wire)
VR • • TQ ............... Square type (without lead wire)
VR • • CY ............... Square type (without lead wire)
VR • • CZ ............... Square type (without lead wire)
VR • • • • • • • • • J .. The 13th character represents error.
("J" 5%, "F" 1%, "D" 0.5%.)
If there are no indications for other parts, the resistors are 5%
carbon-film type.
MD-MX30/MX30W
