Black & Decker QS900 Instruction Manual

PALM GRIP SANDER
INStRuctIoN MANuAl
catalog Number QS900
T
hank you for choosing
g .B
o To www lackanD
To regisTer your new proDucT
BefoRe RetuRNING tHIS PRoduct
foR ANy ReASoN PleASe cAll
1-800-544-6986
bEfORE YOU CALL, hAVE ThE CATALOG No. AND DATE CODE AVAILAbLE. IN mOST CASES, A
BlAck & deckeR REPRESENTATIVE CAN RESOLVE ThE PRObLEm OVER ThE PhONE. If YOU
hAVE A SUGGESTION OR COmmENT, GIVE US A CALL. YOUR fEEDbACk IS VITAL TO
key INfoRMAtIoN you SHould kNoW:
• Do not push down—let the sander do the work.
• Extended drywall sanding is not recommended for this product.
SAve tHIS MANuAl foR futuRe RefeReNce.
veA el eSPA—ol eN lA coNtRAPoRtAdA.
INSTRUCTIVO DE OPERACIÓN, CENTROS DE SERVICIO Y PÓLIZA DE GARANTÍA.
AdveRteNcIA: LÉASE ESTE INSTRUCTIVO ANTES DE USAR EL PRODUCTO.
catalog Number QS900
copyright © 2012 Black & decker
SAfety GuIdelINeS - defINItIoNS
It is important for you to read and understand this manual. The information it contains
relates to protecting YOUR SAfETY and PREVENTING PRObLEmS. The symbols below
are used to help you recognize this information.
dANGeR:
Indicates an imminently hazardous situation which, if not avoided, will result
in death or serious injury.
WARNING:
Indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
cAutIoN:
Indicates a potentially haz ard ous situation which, if not avoided, may
result in minor or mod er ate injury.
NotIce:
Used without the safety alert symbol indicates potentially hazardous
situation which, if not avoided, may result in property damage.

General Safety Rules

WARNING: Read all safety warnings and all instructions. Failure to follow the warnings
and instructions may result in electric shock, fire and/or serious injury.
SAve All WARNINGS ANd INStRuctIoNS foR futuRe RefeReNce
The term "power tool" in the warnings refers to your mains-operated (corded) power tool or
battery-operated (cordless) power tool.
1) WoRk AReA SAfety
a) keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) do not operate power tools in explosive atmospheres, such as in the presence
of flammable liquids, gases or dust. Power tools create sparks which may ignite the
dust or fumes.
c) keep children and bystanders away while operating a power tool. Distractions can
cause you to lose control.
2) electRIcAl SAfety
a) Power tool plugs must match the outlet. Never modify the plug in any way. do not
use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body is
earthed or grounded.
c) do not expose power tools to rain or wet conditions. Water entering a power tool
will increase the risk of electric shock.
d) do not abuse the cord. Never use the cord for carrying, pulling or unplugging
the power tool. keep cord away from heat, oil, sharp edges or moving parts.
Damaged or entangled cords increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for out-
door use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a ground fault circuit
interrupter (GfcI) protected supply. Use of a GFCI reduces the risk of electric shock.
3) PeRSoNAl SAfety
a) Stay alert, watch what you are doing and use common sense when operating a
power tool. do not use a power tool while you are tired or under the influence of
drugs, alcohol or medication. A moment of inattention while operating power tools
may result in serious personal injury.
b) use personal protective equipment. Always wear eye protection. Protective equip-
ment such as dust mask, nonskid safety shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. ensure the switch is in the off position before
connecting to power source and/ or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or energizing power tools that have
the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or
a key left attached to a rotating part of the power tool may result in personal injury.
e) do not overreach. keep proper footing and balance at all times. This enables better
control of the power tool in unexpected situations.
f) dress properly. do not wear loose clothing or jewelry. keep your hair, clothing
and gloves away from moving parts. Loose clothes, jewelry or long hair can be
caught in moving parts.
B & D
lack ecker
D . /n o
ecker com ew wner
.
bLACk & DECkER.
foRM No. 90590031 JuNe '12
Printed in china
g) If devices are provided for the connection of dust extraction and collection
facilities, ensure these are connected and properly used. Use of dust collection can
reduce dust-related hazards.
4) PoWeR tool uSe ANd cARe
a) do not force the power tool. use the correct power tool for your application. The
correct power tool will do the job better and safer at the rate for which it was designed.
b) do not use the power tool if the switch does not turn it on and off. Any power tool
that cannot be controlled with the switch is dangerous and must be repaired.
c) disconnect the plug from the power source and/or the battery pack from the power
tool before making any adjustments, changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfa-
miliar with the power tool or these instructions to operate the power tool. Power
tools are dangerous in the hands of untrained users.
e) Maintain power tools. check for misalignment or binding of moving parts, break-
age of parts and any other condition that may affect the power tool's operation.
If damaged, have the power tool repaired before use. Many accidents are caused
by poorly maintained power tools.
f) keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cut-
ting edges are less likely to bind and are easier to control.
g) use the power tool, accessories and tool bits, etc. in accordance with these
instructions, taking into account the working conditions and the work to be per-
formed. Use of the power tool for operations different from those intended could result
in a hazardous situation.
5) BAtteRy tool uSe ANd cARe
a) Recharge only with the charger specified by the manufacturer. A charger that is suitable
for one type of battery pack may create a risk of fire when used with another battery pack.
b) use power tools only with specifically designated battery packs. Use of any other
battery packs may create a risk of injury and fire.
c) When battery pack is not in use, keep it away from other metal objects like paper
clips, coins, keys, nails, screws, or other small metal objects that can make a
!
connection from one terminal to another. Shorting the battery terminals together
may cause burns or a fire.
d) under abusive conditions, liquid may be ejected from the battery, avoid contact. If
contact accidentally occurs, flush with water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the battery may cause irritation or burns.
6) SeRvIce
a) Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.

SPecIfIc SAfety RuleS

• Hold tool by insulated gripping surfaces when performing an operation where the
cutting tool may contact hidden wiring or its own cord. Contact with a "live" wire will
also make exposed metal parts of the tool "live" and shock the operator.
WARNING: AlWAyS use safety glasses. everyday eye glasses are Not safety
glasses. Also use face or dust mask if operation is dusty. AlWAyS WeAR
ceRtIfIed SAfety eQuIPMeNt:
• ANSI Z87.1 eye protection (CAN/CSA Z94.3)
• ANSI S12.6 (S3.19) hearing protection
• NIOSH/OSHA/MSHA respiratory protection
• Sanding of lead-based paint is not recommended. See Sanding lead Based Paint for
additional information before sanding paint.
• Clean your tool out periodically.

extension cords

When using an extension cord, be sure to use one heavy enough to carry the current your
product will draw. An undersized cord will cause a drop in line voltage resulting in loss of
power and overheating. The following table shows the correct size to use depending on cord
length and nameplate ampere rating. If in doubt, use the next heavier gage. The smaller the
gage number, the heavier the cord.
volts
120V
240V
(0-15,2m) (15,2-30,4m) (30,4-60,9m) (60,9-91,4m)
Ampere Rating
more
Than
0
6
10 -
12 -
The label on your tool may include the following symbols.
V ........................... volts
Hz ......................... hertz
min ........................ minutes
...................... direct current
.......................... Class II Construction
......................... safety alert symbol
WARNING:
other construction activities contains chemicals known to the State of california to
cause cancer, birth defects or other reproductive harm. Some examples of these
chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement and other masonry products, and
• arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type of
work. To reduce your exposure to these chemicals: work in a well ventilated area, and
work with approved safety equipment, such as those dust masks that are specially
designed to filter out microscopic particles.
• Avoid prolonged contact with dust from power sanding, sawing, grinding, drilling,
and other construction activities. Wear protective clothing and wash exposed areas
with soap and water. Allowing dust to get into your mouth, eyes, or lay on the skin may
promote absorption of harmful chemicals.
WARNING:
serious and permanent respiratory or other injury. Always use NIOSH/OSHA approved
respiratory protection appropriate for the dust exposure. Direct particles away from face and
body.

functional description

figure A
1. On/Off Switch
2. Sanding Pad
3. Paper Clamp
4. Dust Canister housing
with filter
5. Paper Punch
Minimum Gage for cord Sets
total length of cord in feet
0-25 26-50 51-100
(0-7,6m) (7,6-15,2m) (15,2-30,4m) (30,4-45,7m)
0-50 51-100 101-200
Not more American Wire Gage
Than
- 6 18 16 16
- 10 18 16 14
12 16 16 14
16 14 12 Not Recommended
Some dust created by power sanding, sawing, grinding, drilling, and
use of this tool can generate and/or disburse dust, which may cause
A
1
2
101-150
201-300
14
12
12
A ......................... amperes
W ........................ watts
.......................alternating current
n o ....................... no load speed
........................ earthing terminal
.../min ..................revolutions or
reciprocations per minute
4
3
5
