- Page 1 Room Conditioners GE Appliances Owner’s Manual & Installation Instructions AVM14 AVM22 AVM15 AVM24 AVM18 AVN24 AVP24 Part. No. 23-11-2129N-002 Pub. No. 49-7374-2 CG 12-98...
-
Page 2: Table Of Contents
Installation Instructions Preparing to Install the Air Conditioner ....7 Window Installation ..8–12 Through-the-Wall ... .13... -
Page 3: Important Safety Information
This air conditioner must be properly installed in accordance with the Installation Instructions before it is used. Never unplug your air conditioner by pulling on the power cord. Always grip plug firmly and pull straight out from the receptacle. Repair or replace immediately all electric service cords that have become frayed or otherwise damaged. -
Page 4: Use Of Extension Cords
If the adapter ground terminal breaks, DO NOT USE the air conditioner until a proper ground has been established. Attaching the adapter ground terminal to a wall outlet cover screw does not ground the appliance unless the cover screw is metal, and not insulated, and the wall outlet is grounded through the house wiring. -
Page 5: Controls
About the controls on the air conditioner. The controls will look like one of the following. (Features and appearance will vary.) HIGH HIGH COOL COOL Controls Mode Controls HIGH COOL, MED COOL and LOW COOL provide cooling with different fan speeds. -
Page 6: Care And Cleaning Of The Air Conditioner
The coils on the outdoor side of the air conditioner should be checked regularly. If they are clogged with dirt or soot they may be professionally steam cleaned, a service available through your GE service outlet. Air Filter The air filter behind the front grille should be checked and cleaned at least every 30 days or more often if necessary. -
Page 7: Preparing To Install The Air Conditioner
NOTE TO CONSUMER: Keep this Owner’s Manual and Installation Instructions for future use. IMPORTANT NOTES: For personal safety, this air conditioner must be properly grounded. It is important to have the wall outlet and circuit checked by a qualified electrician if there is any doubt as to whether a proper ground exists. -
Page 8: Window Installation Instructions
Window Installation Instructions Parts Included 2 sill brackets 2 filler panels 5/8 machine screws (2) 5/8 carriage bolts (2) and nuts (2) 2 support brackets 1 screws (4) and nuts (2) Foam top window gasket Case Window locking bracket 3/8 hex head 5/8 screws (5) screws (8) - Page 9 These instructions are for a standard double- hung window. You will need to modify them for other types of windows. The air conditioner can be installed without the filler panels if needed to fit in a narrow window. See the window opening dimensions to the right.
- Page 10 Case Remove screw Slide the air conditioner out of the case by grasping the rear of the evaporator cover and pulling forward while bracing the case. NOTE: The air conditioner is very heavy. It may...
- Page 11 Install the Case in the Window Open the window and mark the centerline on the stool. Mark centerline Carefully place the case in the window and align the center of the bottom tie bar with the centerline on the window stool. Do not release your grip on the case until the window is in its final position.
- Page 12 Extend the filler panels to fill the window opening. Secure the panels using four 5/8 long screws. Install the Window Gasket and Replace the Air Conditioner Cut the foam top window gasket to the window width. Stuff the foam between the glass and the window to prevent air and insects from getting into the room.
-
Page 13: Through-The-Wall Installation
The room side of the case must project into the room at least 1 The case must be installed level from side-to-side and with a 1/ 4 tilt from front to rear. Remove the air conditioner from the case. For specific instructions, refer to the Window Installation Instructions. -
Page 14: Troubleshooting Tips
• Clean the filter at least every 30 days. See the Operating Instructions section. • When the air conditioner is first turned on you need to allow time for the room to cool down. • Check for open furnace floor registers and cold air returns. -
Page 15: Air Conditioner Warranty
Any part of the air conditioner which fails due to a defect in materials or workmanship. One Year During this full one-year warranty, GE will also provide, free of charge, all labor From the date of the and in-home service to replace the defective part. -
Page 16: Service Telephone Numbers
Expert GE repair service is only a phone call away. Special Needs Service 800-TDD-GEAC (800-833-4322) GE offers, free of charge, a brochure to assist in planning a barrier-free kitchen for persons with limited mobility. Service Contracts Purchase a GE service contract while your warranty is still in effect and you’ll receive a substantial discount.
