Undercounter Dishwasher
IMPORTANT:
Installer: Leave Installation
Instructions with the homeowner.
Homeowner: Keep Installation
Instructions for future reference.
Save Installation Instructions for
local electrical inspector's use.
Part No. 4171206
Before you start...
Proper installation is your
responsibility. Make sure you
have everything necessary for
correct installation. It is the
personal responsibility and
obligation of the customer to
contact a qualified installer to assure
that electrical and plumbing
installation meet national and local
codes and ordinances.
Check location where dishwasher
will be installed. The location should
provide :
l
Easy access to water, electricity
and drainage.
l
Convenient loading - the best
position is left or right of kitchen
sink.
l
Opening that is square for proper
dishwasher operation and
appearance.
l
Cabinet front that is perpendicular
to floor.
. Protection against freezing to
prevent the water inlet valve,
water lines to dishwasher, water
lines in dishwasher, and drain from
rupturing. (Ruptures from freezing
are not covered by the warranty.)
l
l/4" minimum clearance between
motor and flooring to prevent
motor overheating.
