Press the Temp Set button on the

control panel (Fig. G) to set the

d e s i r e d t e m p e r a t u r e . T h e

temperature range for this deep

fryer is 300°F to 375°F. each time

you press the Temp Set button, the

temperature will increase by 25°F.

The recommended setting for most

frying is 375°F; therefore, to set the

fryer to 375°F, press the Temp Set

button four times. (See page 5 for

proper frying temperatures.)

Press the Heat Start/Cancel button

on the control panel (Fig. G) to start

heating the oil. (The unit will beep

once whenever the Heat Start/Cancel

button is pressed.) The red signal light will come on, indicating that the unit is heating. (Preheat time is approximately 15 to 17

minutes.)

10.

While oil is heating:

A. Prepare food for cooking, making sure to remove excess moisture from food by blotting with toweling — moist foods cause

excess foaming, spattering, and/or overflow.

B. Assemble basket handle for frying, see page 3.

To insure against accidental detachment of handle from basket during use, always make sure both pegs are in the bracket

holes and the handle bars are in the brackets (Fig. C and D, page 3).

C. Place basket on countertop and fill basket up to ⅔ full with food. For raw fries, only fill basket ½ full.

Note: The black cover vents may expand and appear to change shape when the fryer is heating. When the cover cools, the

vents will contract and appear to return to their original position. Both the expansion and contraction are normal.

11.

When the selected temperature is reached, the red light will go out, the green light will come on, and the unit will beep five times.

The unit is now ready to cook food.

Set the timer by pressing the "+" or "–" buttons on the control panel (Fig. G). Holding down either of these buttons will increase

12.

or decrease the display time rapidly. The timer can be set for 1 to 30 minutes. Refer to page 5 for recommended times.

Note: The timer works independently from the unit; it does not turn on or off power to the heating element.

13.

Remove cover.

14. Attach the filled fry basket to the removable pot using the drain hooks. Position cover over basket so that the cover vents are on

the opposite side of the basket handle. Now start the timer by pressing the Time Start/Cancel button on the control panel (Fig. G).

The unit will beep once and the display will begin to count down. you will notice the second digits as well as the minute digits

will now be displayed.

15. Lift up slightly on the basket handle to disengage the drain hooks. Then slowly lower the filled basket into the preheated oil until

the bottom of the basket rests on top of the heating element. If frying french fries or other high moisture foods, immediately

remove cover after lowering basket into oil.

For crisper foods, fry without the cover.

warning: To prevent the risk of severe personal injury or property damage, use caution when cooking with hot oil.

It is normal for steam to escape from the cover vents during frying. To prevent steam burns, keep hands and face away

from the vents.

16.

When frying time has elapsed, the unit will start beeping. The timer will immediately begin to count up to show how much time

has elapsed since the timer sounded. Press the Time Start/Cancel button to stop the beeping and count-up time and reset to zero.

17.

Check that the food is golden brown. If additional cooking time is needed, set the timer for additional time.

18.

once the food is golden brown, lift the basket and hook it onto the fryer rim to allow oil to drain from food.

19.

empty the food onto absorbent paper. Season to taste.

20.

If frying additional food, repeat steps 10C through 19. If red signal light is on, allow oil to reheat until red signal light goes out

and green light comes on.

When frying is completed, press the Heat Start/Cancel button and remove plug from wall outlet and then from deep fryer. Allow

21.

oil and fryer to cool completely before removing control assembly and before cleaning.

Red/Green

signal lights

Temp
