Battery Replacement Battery Cover The UtilityPRO has a coin cell Assembly battery that retains the time and date during a power failure. Under normal circumstances the coin cell should last five years. Coin cell Should the time and date need battery tray to be reset after a power failure, this is an indication that the coin...
Page 4
FCC Part 15 Notice This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. Operation is subject to the following two conditions: 1) This device may not cause harmful interference. 2) This device must accept any interference received, including interference that may cause undesired operation.
UtilityPRO Series Table of contents About your new thermostat Special Features ........17 Screen Lock ..........18 Thermostat Features ........2 Screen Cleaning ........19 Getting Started Advanced Functions ......20-23 Quick Reference to Controls ..... 3 Troubleshooting ........24-25 Quick Reference to Status Display ... 4 Subscription Services Demand Control .........
Operating Manual UtilityPro Features Congratulations! You’ve just purchased the world’s most advanced, easy-to-use thermostat. It has been designed to give you many years of reliable service and touchscreen climate control. Features • Provides Utility information messages. • Provides Utility billing information. •...
UtilityPRO Series Quick Reference to Controls Press day(s) to set program schedule (see page 11) Press to view messages Displays the current tier rate Press to adjust temperature settings Press to select fan operation Press to select system type Press to view the subscribed service Press to set program messages...
Operating Manual Quick Reference to Status Display Current inside temperature Temperature setting TIER VIEW MEDIUM Fan setting Inside Set To Program schedule ON (does not display AUTO when off) System setting Following SYSTEM 8:10 Schedule Recovery HEAT Adaptive Intelligent Recovery in effect SCHED HOLD CLOCK SCREEN...
UtilityPRO Series Demand Control This is an energy saving device. At times, thermostat operation may be temporarily adjusted by a small amount as outlined in your energy provider’s associated program literature. This is normal operation and is part of the program for which you have enrolled. Thank you for your participation.
Operating Manual UtilityPro Utility Usages Features ® Usage is a service provided by the utility provider. Depending on the various services provided by the utility provider, Usage may contain vital information for your use. It may display your electricity bill, water consumption bill, gas bill, and so on. Usage also has a feature wherein you can compare your present consumption against your last year’s consumption for the same time period.
UtilityPRO Series Getting Started View Messages Press on your screen. Good Morning! The message icon blinks when you receive a new message. The Message screen appears. Use the arrow buttons to view the messages. There can be a maximum of five messages. The message scrolls automatically if it has more than 21 characters.
Operating Manual UtilityPro Usage and Billing Features Press on your screen. ELECTRICITY BILL The Usage screen appears. Navigate using the arrow buttons to view the billing consumption of water, gas, electricity, and so on*. In case there are no utility messages, the utility message icon does not appear.
UtilityPRO Series Getting Started UtilityPro Fan Settings Features ® Press FAN to select fan operation, then press DONE. Inside Set To • ON: Fan is always on. AUTO • Auto: Fan runs only when the heating or cooling system is ON. Following SYSTEM 6:01...
Operating Manual System Settings Press the SYSTEM button to select one of the following, then press DONE. • Heat: Thermostat controls only the heating system. Inside Set To • Cool: Thermostat controls only the cooling system. AUTO • Off: Heating and cooling systems are SYSTEM Following OFF.
UtilityPRO Series Schedule Settings Press SCHED 1. Press SCHED, then EDIT. 2. Press day buttons to select day(s). There SCHED HOLD CLOCK SCREEN USAGE are three groups (MON-FRI), (SAT), and (SUN). 3. Press to set Wake time for selected Press EDIT day(s).
Operating Manual Program Schedule Override (Temporary) Adjust temperature Press to immediately adjust the temperature. This temporarily overrides the temperature setting for the current time period. The new temperature is maintained only until the next programmed time period begins Inside Set To (see page 15).
UtilityPRO Series Program Schedule Override (Permanent) Adjust temperature Press HOLD to permanently adjust the temperature. This turns off the program schedule. Whatever temperature you set is maintained Inside 24 hours a day until you manually change it or Set To press CANCEL (or SCHED) to cancel “Hold”...
Operating Manual Clock Settings Press CLOCK To set the current time display, press CLOCK, then press to adjust the time. Press and hold to advance the time more 6:01 quickly. Press DONE to save & exit (or press CANCEL to SCHED HOLD CLOCK...
UtilityPRO Series Save Money by Setting Program Schedules It is easy to program your system for maximum energy savings. You can program four time periods each day, with different settings for weekdays and weekends. WAKE Set to the time you awaken and the temperature you want 6:00 am during the morning, until you leave for the day.
Page 20
Operating Manual EnergyStar Settings for Maximum Cost Savings ® This thermostat is pre-set to use EnergyStar program settings. We recommend these ® settings, since they can reduce your heating/cooling expenses by as much as 33%. Heat (Mon-Fri) Cool (Mon-Fri) Heat (Sat-Sun) Cool (Sat-Sun)
UtilityPRO Series Special Features Auto Changeover: When set to Auto, the thermostat automatically selects heating or cooling depending on the indoor temperature. Adaptive Intelligent Recovery: This feature allows the thermostat to “learn” how long the furnace and air conditioner take to reach programmed temperature settings, so the temperature is reached at the time you set.
Operating Manual Screen Lock To prevent tampering, the screen can be partially or fully locked. SCREEN LOCKED When partially locked, the screen displays Inside Set To AUTO SCREEN LOCKED for several seconds if a locked key is pressed. To unlock the screen, press any Following SYSTEM Schedule...
UtilityPRO Series Screen Cleaning Press SCREEN Press SCREEN to go to the cleaning screen. Press OK to lock the screen for cleaning. The 6:00 screen remains locked for 30 seconds so you can clean the screen without disturbing any SCHED HOLD CLOCK SCREEN...
Operating Manual Advanced Functions 2. Press and hold 1. Press SYSTEM. HEAT blank center key 6:01 until the display changes. DONE CANCEL SYSTEM Function Setting HEAT 3. Change settings as required (see pages 0120 21-23). DONE 4. Press DONE to exit & Press Press save changes.
Page 25
UtilityPRO Series Advanced Functions Year setting (first two digits) Function Press to change the first two digits of the year: 0120 Options: = Year 20xx = Year 21xx Year setting (second two digits) Function Press to change the last two digits of the year: 0130 Options: (i.e., 2001 - 2099)
Page 26
Operating Manual Advanced Functions Program schedule ON/OFF Function Press to turn the program schedule ON or OFF: 0160 Options: 5/2 [programmable weekdays and weekends]. 5/1/1 [weekdays, saturday, and sunday programmable]. Temperature format (°F/°C) Function Press to set the temperature display format: 0320 Options: Fahrenheit...
UtilityPRO Series Advanced Functions Program schedule periods Function Press to set the number of program periods: 0540 Options: 4-4 program periods (WAKE, LEAVE, RETURN, SLEEP) 2-2 program periods (WAKE and SLEEP) 3-2 program periods (LEAVE and RETURN) Clock format Function Press to set the clock display format: 0640...
Operating Manual Troubleshooting If you have difficulty with your thermostat, please try the following. Most problems can be corrected quickly and easily. Display is blank • Check circuit breaker and reset if necessary. • Make sure power switch at heating & cooling system is ON. •...
Page 29
UtilityPRO Series Troubleshooting Heating or cooling • Press SYSTEM to set system to Heat. Make sure the temperature is set system does not higher than the Inside temperature. respond • Press SYSTEM to set system to Cool. Make sure the temperature is set lower than the Inside temperature.
