Sony XC-ST30 User Manual

Ccd black-and-white video camera module
Hide thumbs Also See for XC-ST30:
Table of Contents

Advertisement

Quick Links

See also: Technical Manual
CCD B/W VIDEO
CAMERA MODULE
XC-ST50/50CE
XC-ST30/30CE
User's
G
uide
(Ver. 1.0) — English —

Advertisement

Table of Contents
loading

Related Manuals for Sony XC-ST30

Summary of Contents for Sony XC-ST30

  • Page 1 CCD B/W VIDEO CAMERA MODULE XC-ST50/50CE XC-ST30/30CE User’s uide (Ver. 1.0) — English —...

  • Page 2: Table Of Contents

    XC-ST50/50CE XC-ST30/30CE Table of Contents OUTLINE ......................... 1 MAIN FEATURES ....................1 SPECIFICATIONS COMPARISON ................2 SYSTEM CONFIGURATION ................... 2 MAIN SPECIFICATIONS ..................3 CONNECTION DIAGRAM ..................4 LOCATION OF PARTS AND OPERATION ............. 5 PHASE CONDITIONS OF EXTERNAL SYNCHRONIZATION ........ 6 ELECTRONIC SHUTTER ..................

  • Page 3: Outline

    XC-ST50/50CE XC-ST30/30CE OUTLINE The XC-ST50/50CE and XC-ST30/30CE are compact, lightweight, black-and-white camera modules of a new concept, which are produced as input devices for image processing by using the latest technology. These models inherit the basic functions of the XC-75 (installing a 1/2-inch CCD) and the XC-73 (installing a 1/3-inch CCD), which are used in various types of devices and systems and win popularity in the machine vision field.

  • Page 4: Specifications Comparison

    XC-ST50/50CE XC-ST30/30CE SYSTEM CONFIGURATION The components making up the system based on XC-ST50/ST50CE or XC-ST30/ST30CE video camera are as follows. Camera cables Video camera module Camera adaptor CCXC-12P02N (2 m) XC-ST50/50CE DC-700/700CE CCXC-12P05N (5 m) XC-ST30/30CE CCXC-12P10N (10 m) CCXC-12P25N (25 m) Junction box Tripod adaptor C-mount lenses...

  • Page 5: Main Specifications

    XC-ST50/50CE XC-ST30/30CE MAIN SPECIFICATIONS Image pickup device Gain AGC/Manual/Fixed XC-ST50/50CE: 1/2-inch interline transfer CCD (Can be selected using the XC-ST30/30CE: 1/3-inch interline transfer CCD switch on the rear panel.) Number of effective pixels Gamma correction ON/OFF XC-ST50/ST30: 768(H) x 494(V) (Can be selected using the XC-ST50CE/ST30CE: 752(H) x 582(V) switch on the rear panel.)

  • Page 6: Connection Diagram

    XC-ST50/50CE XC-ST30/30CE CONNECTION DIAGRAM C-mount lens VIDEO OUT HD/VD VCL-08Y-M TRIG Camera adaptor DC-700/CE (Conforms to new EIAJ and uses 12-pin assignment.) VCL-12Y-M XC-ST50/50CE XC-ST30/30CE VIDEO OUT HD/VD Camera cable VCL-16Y-M Camera adaptor CCXC-12P02N DC-777/CE CCXC-12P05N Tripod adaptor (No trigger input terminal is provided.) CCXC-12P10N VCT-ST70I CCXC-12P25N...

  • Page 7: Location Of Parts And Operation

    1 Lens mount section XC-ST30/30CE A commercial C-mount lens as well as a (XC-ST50 model) Sony standard lens can be used. 2 Camera mounting reference hole These screw holes are positionned with high precision related to CCD sensor. VIDEO CAMERA MODULE...

  • Page 8: Phase Conditions Of External Synchronization

    XC-ST50/50CE XC-ST30/30CE PHASE CONDITIONS OF EXTERNAL SYNCHRONIZATION External synchronization for each mode • For normal video/normal shutter Continuous HD/VD signal (should conform to EIA and CCIR frequencies in the timing shown in the figure below.) • For Restart Reset (RR)/external trigger shutter Continuous HD signal.

  • Page 9: Electronic Shutter

    XC-ST50/50CE XC-ST30/30CE ELECTRONIC SHUTTER Two types of electronic shutter are provided “normal shutter and external trigger shutter”. The electronic shutter speed and type can be set using the DIP switch on the rear panel. DIP switch on the rear panel Rear panel DIP switch Switches 1 to 4: Selects the shutter speed.

  • Page 10: External Trigger Shutter

    XC-ST50/50CE XC-ST30/30CE ELECTRONIC SHUTTER External trigger shutter By inputting an external trigger, a high-speed moving subject can be caught at an exact position. Set DIP switches 6, 7, and 8 on the rear panel to mode 1 or 2. (Refer to the table below.) When the trigger pulse width is 1/3 sec or more, the output signal is switched to a normal video signal.
  • Page 11 XC-ST50/50CE XC-ST30/30CE ELECTRONIC SHUTTER Specifications of trigger pulse When using a trigger pulse like shown below, set the TRIG polarity selector switch on the rear panel to + : A: 2 to 5.0 V B: 0 to 0.6 V T: 2 s to 1/4 s, 100 s to 1/4 s when setting the shutter speed using DIP switch When using a trigger pulse like shown below, set the TRIG polarity selector switch on the rear panel to –...

  • Page 12: Restart Reset (R.r)

    XC-ST50/50CE XC-ST30/30CE RESTART RESET (R.R) The information on one screen can be extracted at any time by inputting a restart/reset signal (HD/VD) from the outside. To enter this mode, set DIP switches 6, 7, and 8 on the rear panel of a camera as shown in the table below. The setting is especially effective for the following operation.
  • Page 13 XC-ST50/50CE XC-ST30/30CE RESTART RESET (R.R) Example 2 of long exposure EXT HD Continuous signal: 15.734 kHz (XC-ST50/ST30), 15.625 kHz (XC-ST50CE/30CE) Allowable frequency value 1% EXT VD VD interval(T): 262.5H or more (XC-ST50/ST30), 312.5H or more (XC-ST50CE/30CE) and 1 second or less (Recommended) Four or more VD pulses are required.

  • Page 14: Frame Image Output With Strobe Light

    XC-ST50/50CE XC-ST30/30CE FRAME IMAGE OUTPUT WITH STROBE LIGHT A full frame image with vertical resolution of 485 lines (XC-ST50/ST30) or 575 lines (XC-ST50CE/ST30CE) can be obtained with a strobe light by firing the strobe when the exposure time of the two fields overlap. Timing and conditions <Timing chart by restart/reset>...

  • Page 15: Output Waveform Timing Chart (Xc-St50 (Eia)/Xc-St30 (Eia))

    XC-ST50/50CE XC-ST30/30CE OUTPUT WAVEFORM TIMING CHART (XC-ST50 (EIA)/XC-ST30 (EIA)) Timing chart of horizontal output waveform 91 (6.36 s) output signal Effective total pixel Dummy 69.8 ns pixel Optical black portion Horizontal transfer stop period Optical black portion Horizontal blanking period (11.0 s) Output video period Camera video output signal...
  • Page 16 XC-ST50/50CE XC-ST30/30CE ELECTRONIC SHUTTER OUTPUT WAVEFORM TIMING CHART (XC-ST50 (EIA)/XC-ST30 (EIA)) Timing chart of vertical output waveform (2:1 interlaced field integration) Odd field (262.5 H) Even field (262.5 H) 253.5 H 253.5 H output signal 242.5 242.5 Empty Empty transfer transfer Camera Optical black portion...
  • Page 17 XC-ST50/50CE XC-ST30/30CE OUTPUT WAVEFORM TIMING CHART (XC-ST50CE (CCIR)/XC-ST30CE (CCIR)) Timing chart of horizontal output waveform (6.91 s) output signal Effective total pixel 752 Dummy 70.5 ns Optical black pixel portion Horizontal transfer stop period Optical black portion Horizontal blanking period (12.1 s) Output video period Camera video output signal...
  • Page 18 XC-ST50/50CE XC-ST30/30CE ELECTRONIC SHUTTER OUTPUT WAVEFORM TIMING CHART (XC-ST50CE (CCIR)/XC-ST30CE (CCIR)) Timing chart of vertical output waveform (2:1 interlaced field integration) Odd field (312.5 H) Even field (312.5 H) 7.5 H 305 H 7.5 H 305 H output signal 287.5 287.5 Empty Empty...

  • Page 19: Timing Chart Of External Trigger Shutter - Mode 1

    XC-ST50/50CE XC-ST30/30CE TIMING CHART OF EXTERNAL TRIGGER SHUTTER - MODE 1 (NON-RESET MODE) For setting the shutter speed using TRG width HD/VD input Continuous HD/VD input Mode transition state External input External trigger inhibition area shutter operation External trigger shutter operation Normal operation (50 ms) Trigger...
  • Page 20 XC-ST50/50CE XC-ST30/30CE TIMING CHART OF EXTERNAL TRIGGER SHUTTER - MODE 1 (NON-RESET MODE) For setting the shutter speed using TRG width HD/VD input Continuous HD input and single VD input Mode transition state External input External trigger inhibition area shutter operation External trigger shutter operation Normal operation (50 ms)
  • Page 21 XC-ST50/50CE XC-ST30/30CE TIMING CHART OF EXTERNAL TRIGGER SHUTTER - MODE 1 (NON-RESET MODE) For setting the shutter speed using TRG width No HD/VD input (Internal synchronization) Mode transition state External input External trigger inhibition area shutter operation External trigger shutter operation Normal operation (50 ms) Trigger...
  • Page 22 XC-ST50/50CE XC-ST30/30CE TIMING CHART OF EXTERNAL TRIGGER SHUTTER - MODE 1 (NON-RESET MODE) For setting the shutter speed using DIP switch HD/VD input Continuous HD/VD input Mode transition state External input External trigger inhibition area shutter operation External trigger shutter operation Normal operation (50 ms) Trigger...
  • Page 23 XC-ST50/50CE XC-ST30/30CE TIMING CHART OF EXTERNAL TRIGGER SHUTTER - MODE 1 (NON-RESET MODE) For setting the shutter speed using DIP switch HD/VD input Continuous HD input and single VD input Mode transition state External input External trigger inhibition area shutter operation External trigger shutter operation Normal operation (50 ms)
  • Page 24 XC-ST50/50CE XC-ST30/30CE TIMING CHART OF EXTERNAL TRIGGER SHUTTER - MODE 1 (NON-RESET MODE) For setting the shutter speed using DIP switch No HD/VD input (Internal synchronization) Mode transition state External input External trigger inhibition area shutter operation External trigger shutter operation Normal operation (50 ms) Trigger...

  • Page 25: Timing Chart Of External Trigger Shutter - Mode 2

    XC-ST50/50CE XC-ST30/30CE TIMING CHART OF EXTERNAL TRIGGER SHUTTER - MODE 2 (RESET MODE) For setting the shutter speed using TRG width Mode transition state External input External trigger inhibition area shutter operation External trigger shutter operation Normal operation (50 ms) Trigger 1/3 s or more Exposure time...
  • Page 26 XC-ST50/50CE XC-ST30/30CE TIMING CHART OF EXTERNAL TRIGGER SHUTTER - MODE 2 (RESET MODE) For setting the shutter speed using DIP switch Mode transition state External input External trigger inhibition area shutter operation External trigger shutter operation Normal operation (50 ms) Trigger 100 us to 250 ms 1/3 s or more...

  • Page 27: Dimensions

    XC-ST50/50CE XC-ST30/30CE DIMENSIONS XC-ST50/50CE XC-ST30/30CE (XC-ST50 model) 2-M3 deep 4 (Unit: mm) VIDEO CAMERA MODULE XC-ST50 57.5 65.5 4-M3 deep 4 50 0.5...

  • Page 28: Spectral Response Characteristics (Typical Value)

    XC-ST50/50CE XC-ST30/30CE SPECTRAL RESPONSE CHARACTERISTICS (TYPICAL VALUE) XC-ST50/ST30 1000 Wavelength (nm) COMPARISON OF SPECTRAL RESPONSE CHARACTERISTICS (TYPICAL VALUE) XC-75/73 and XC-ST50/ST30 XC-ST50/30 XC-75/73 (without IR cut filter) XC-75/73 (with IR cut filter) 1000 Wavelength (nm)

  • Page 29: Various Lens Selection

    XC-ST50/50CE XC-ST30/30CE VARIOUS LENS SELECTION The following shows the various lens specifications of the accessories available. XC-ST50/50CE and XC-ST30/30CE compatibility List of C-Mount Lens Model name VLC-08YM VLC-12YM VLC-16Y-M VLC-25Y-M VLC-50Y-M Focal distance (mm) 1: 1.4 1: 1.8 1: 1.4 1: 1.6 1: 2.8 Maximum aperture ratio...
  • Page 30 Technical information contained herein is for reference only and does not convey any license by any implication or otherwise under any intellectual property right or other right of Sony or third parties. Sony cannot assume responsibility for any right infringements arising out of the use of this information.
  • Page 31 4-14-1 Asahi-cho,Atsugi-shi, Kanagawa,243-0014 Japan Tel: +81-46-227-2346 Fax: +81-46-227-2347 Tel: +81-46-230-5873 Fax: +81-46-230-6243 http://www.sony.com/professional Sony Electronics Inc. 1 Sony Drive Park Ridge, NJ 07656 Tel: +1-800-686-7669 Canada Sony of Canada Ltd. 115 Gordon Baker Rd, Toronto, Ontario M2H 3R6 Tel: +1-416-499-1414 Fax: +1-416-497-1774 Europe http://www.pro.sony-europe.com/ISP...

This manual is also suitable for:

Xc-st30ceXc-st50Xc-st50ce
