SPECIAL NOTE FOR USERS IN THE U.K.
The mains lead of this product is fitted with a non-rewireable (moulded) plug
incorporating a 3A fuse.
Should the fuse need to be replaced, a BSI or ASTA approved BS 1362 fuse
marked
or
and of the same rating as above, which is also indicated on the
pin face of the plug, must be used.
Always refit the fuse cover after replacing the fuse. Never use the plug without
the fuse cover fitted.
In the unlikely event of the socket outlet in your home not being compatible with
the plug supplied, cut-off the mains plug and fit an appropriate type.
DANGER: The fuse from the cut-off plug should be removed and the cut-off
plug destroyed immediately and disposed of in a safe manner.
Under no circumstances should the cut-off plug be inserted
elsewhere into a 13A socket outlet, as a serious electric shock may
occur.
To fit an appropriate plug to the mains lead, follow the instructions below:
IMPORTANT: The wires in the mains lead are coloured in accordance with the
following code:
As the colours of the wires in the mains lead of this product may not correspond
with the coloured markings identifying the terminals in your plug, proceed as
follows:
—The wire which is coloured blue must be connected to the plug terminal which
is marked N or coloured black.
—The wire which is coloured brown must be connected to the plug terminal
which is marked L or coloured red.
Ensure that neither the brown nor the blue wire is connected to the earth
terminal in your three-pin plug.
Before replacing the plug cover make sure that:
—If the new fitted plug contains a fuse, its value is the same as that removed
from the cut-off plug.
—The cord grip is clamped over the sheath of the mains lead and not simply
over the lead wires.
IF YOU HAVE ANY DOUBT, CONSULT A QUALIFIED ELECTRICIAN.
Blue:
Neutral
Brown: Live

Advertisement

Table of Contents
loading

Related Manuals for Sharp DV-L80S

Summary of Contents for Sharp DV-L80S

  • Page 1 SPECIAL NOTE FOR USERS IN THE U.K. The mains lead of this product is fitted with a non-rewireable (moulded) plug incorporating a 3A fuse. Should the fuse need to be replaced, a BSI or ASTA approved BS 1362 fuse marked and of the same rating as above, which is also indicated on the pin face of the plug, must be used.

  • Page 2: General Information

    OPERATION MANUAL About This Manual • All mentions of “the Player” refer to the DV-L80S Portable DVD Video Player. • All mentions of “the Remote” refer to the remote control unit. • The following table describes the icons used in this Operation Manual.

  • Page 3: Table Of Contents

    Contents GENERAL INFORMATION SAFETY INFORMATION ....................... 4 Disc Handling and Maintenance ....................9 Features ............................10 Accessories ..........................12 Types of Discs that can be played on Your Player ..............13 Discs recorded by PAL system, Discs recorded by NTSC system and Type of TV connection ..16 General Guide ..........................
  • Page 4 Contents To turn off the LCD display ....................67 Playing back a DVD-RW disc ....................68 Other Disc Play Features ......................70 Chapter skip ......................... 70 Track skip ..........................70 To resume disc play after stopping ..................71 Slow-motion play ........................72 Still (Pause) and Frame advance ..................

  • Page 5: Safety Information

    SAFETY INFORMATION Note: This Player can be used only where the power supply is AC 110V-240V, 50/60Hz. It cannot be used elsewhere. CAUTION: USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE. AS THE LASER BEAM USED IN THIS PLAYER IS HARMFUL TO THE EYES, DO NOT ATTEMPT TO DISASSEMBLE THE CABINET.
  • Page 6 SAFETY INFORMATION • This Player is classified as a CLASS 1 LASER product. • “CLASS 1 LASER PRODUCT” label is located at the bottom of the Player. • The laser caution labels are located at the bottom of the Player and printed in the disc compartment.

  • Page 7: Location And Handling

    • Do not remove the Player cabinet. Touching parts inside the cabinet could result in electric shock and/or damage to the Player. For service and adjustment inside the cabinet, call a qualified dealer or service centre approved by SHARP. Nonuse Periods When the Player is not being used, turn it off.
  • Page 8 Player. Service Do not attempt to service this Player yourself. Please refer any service to the nearest service centre approved by SHARP. Copyright For the European Continent except the U.K. Audio-visual material may consist of copyrighted works which must not be recorded without the authority of the owner of the copyright.
  • Page 9 1,000 hours. Note that this period varies depending on the environment (temperature, humidity, dust, etc.) in which the Player is used. Contact your authorized Sharp supplier for details. Do not attempt to clean the pickup lens yourself.

  • Page 10: Disc Handling And Maintenance

    Disc Handling and Maintenance Handling precautions • Hold the disc by the edges so the surface will not be soiled with fingerprints. Fingerprints, dirt and scratches can cause skipping and distortion. • Do not write on the label side with a ball-point pen or other writing utensils.

  • Page 11: Features

    Features This Player can play back DVD video disc, DVD-RW, VIDEO CD and Audio CD. • DVD-RW recorded in Video recording format can be played back. (You may not be able to play back a disc that is not finalized.) 8"...
  • Page 12 Features High-quality surround sound produced by built-in Dolby Digital/Dolby Surround (Pro Logic)/MPEG Audio decoder • Your Player is equipped with Dolby Digital (5.1ch)/Dolby Surround (Pro Logic)/ MPEG Audio decoder as standard. Connecting an amplifier with 5.1ch input jacks to the Player provides richer, more powerful surround sound. QSURROUND is a trademark of QSound Labs, Inc.

  • Page 13: Accessories

    Accessories I Supplied Accessories Remote control unit Audio cable S-video/video cable INPUT OPERATE /DVD – VOLUME TITLE FUNCTION SHIFT MENU ENTER SETUP VIDEO ADJ. RETURN ZOOM PROGRAM DISPLAY VIEW MODE LCD ON/OFF DVD VIDEO PLAYER CR2025 type lithium AC adapter Earphones battery for the Remote unit...

  • Page 14: Types Of Discs That Can Be Played On Your Player

    Types of Discs that Can Be Played on Your Player The unit can play back discs bearing any of the following marks: [8cm (3") disc/ 2 (See page 15.) 12cm (5") disc] • Supports the disc recorded in DVD-RW Video recording format. [8cm (3") disc/ •...
  • Page 15 Types of Discs that Can Be Played on Your Player Discs that Cannot be Played The following types of discs cannot be played back on this Player. In many cases, attempting to play back such discs may result in malfunction and/or damage to this Player.
  • Page 16 Types of Discs that Can Be Played on Your Player Icons Used on DVD Discs Sample Icons 1. English 1. English 16:9 2. Chinese 2. Chinese Number of recorded Type of subtitles Screen Disc with Region code recorded aspect ratio multiple camera indicator audio tracks...

  • Page 17: Discs Recorded By Pal System, Discs Recorded By Ntsc System And Type Of Tv Connection

    Discs recorded by PAL system, Discs recorded by NTSC system and Type of TV connection • The Player can play back discs recorded by NTSC using the modified PAL system, such as DVD-region 2, DVD-RW and VIDEO CD, but cannot play back discs for the use in U.S.A.

  • Page 18: General Guide

    General Guide Player - Right side Numbers in refer to the main pages in this Operation Manual where the topic is explained. VIDEO AUDIO(L/R) AUDIO OUT PHONES IN/OUT DIGITAL OUT(OPTICAL) C/SW SURROUND VIDEO AUDIO(L/R) AUDIO OUT PHONES IN/OUT DIGITAL OUT(OPTICAL) SURROUND C/SW 22, 23...
  • Page 19 General Guide Player - Front Numbers in refer to the main pages in this Operation Manual where the topic is explained. LCD screen Speakers 180° Display panel movement range Disc compartment cover î OPEN OPERATE INPUT/DVD – VOLUME SETUP/ADJ. SHIFT 0°...
  • Page 20 General Guide Important! • The range of movement for the display panel is 0° to 180°. Never try to force it open past 180°. Doing so can seriously damage the display panel and Player. • The range of movement for the disc compartment cover is 0° to 60°. Never try to force it open past 60°.

  • Page 21: Remote Control Unit

    General Guide Remote Control Unit Numbers in refer to the main pages in this Operation Manual where the topic is explained. Select/Enter Mode • The operation buttons have the following Select/Enter functions when Setup screen, Function control screen or another type of setting screen is on the display.

  • Page 22: Using Headphones

    Using Headphones You can connect the earphones that come with the Player or commercially available headphones with a stereo mini plug to the PHONES jack and listen to the audio output. To use the supplied earphones Connect the earphones that come with the Player to the PHONES jack. •...

  • Page 23: Connecting To External Equipment For Input

    Connecting to External Equipment for Input Selecting the INPUT mode using INPUT/DVD on the Player automatically switches the function of its video and audio input/output jacks to input. Then you can view images from a connected VCR or camcorder on the screen of your Player.

  • Page 24: Connecting A Tv With External Terminals

    Connecting a TV with External Terminals You can use the S-video plug of the S-video/video cable to connect your Player to a television equipped with an S-video input jack and enjoy viewing high- quality images on the TV screen. • Be sure to turn both the Player and the TV equipment off before connecting them.

  • Page 25: Connecting To Audio Equipment

    Connecting to Audio Equipment Connecting the Player to audio equipment provides normal stereo sound plus powerful stereo sound enhanced by Dolby Digital (5.1 channel), DTS and MPEG Audio. Playing 2 channel audio The audio analogue input/output jack of the Player also doubles as an optical digital output jack.
  • Page 26 Connecting to Audio Equipment I Digital Connection DIGITAL OUT (OPTICAL) VIDEO AUDIO(L/R) AUDIO OUT PHONES IN/OUT DIGITAL OUT(OPTICAL) SURROUND C/SW To optical Optical digital cable digital input (commercially available) jack DIGITAL IN Audio equipment with optical digital input jack COAXIAL OPTICAL After making the above connection Set the “SPEAKER”...

  • Page 27: Playing Dolby Digital (5.1 Channel), Dts And Mpeg Audio

    Connecting to Audio Equipment Playing Dolby Digital (5.1 channel), DTS and MPEG audio I Analogue Connection • This Player is equipped with the Dolby Digital (5.1ch)/ Dolby Surround (Pro Logic)/MPEG Audio decoder as standard. Connecting an amplifier with 5.1ch input jacks to your Player provides richer, more powerful surround sound.
  • Page 28 Connecting to Audio Equipment • This Player cannot be connected to an amplifier or processor that does not have 5.1ch input jacks. • With an analogue connection, audio cannot be produced from a DVD recorded with DTS, so you should use an optical digital connection to play such discs. •...

  • Page 29: Using The Ac Adapter

    Using the AC Adapter AC Adapter (supplied) DC cord Power socket AC cord (supplied) To power DC output socket plug To DC IN jack To household power outlet For the U.K. and Eire Important! • Make sure that the Player’s power is turned off before attaching or detaching the AC adapter.

  • Page 30: Using The Battery Pack

    Using the Battery Pack CAUTION • Use only SHARP model “BT-L200S” battery pack with this Player. Use of another battery may present a risk of fire or explosion. To attach a battery pack to the Player Be sure to charge a battery pack before using it and make sure the Player’s power is turned off.
  • Page 31 Using the Battery Pack Plug the AC cord into the power socket of the AC adapter (1). • Push the cord straight into the AC adapter as far as it can go. Plug the other end of the AC cord the U.K.
  • Page 32 Using the Battery Pack Charge time Charge time Approximately 5 hours • The charge time noted here is the time required to bring a fully depleted battery pack to full charge. • Cold conditions and the condition of the battery pack may cause the required charge time to be longer.

  • Page 33: Battery Capacity Indicator

    Battery Capacity Indicator • The battery capacity indicator appears only while the display mode is “on”. The indicator appears for a short while and then disappears. • Battery condition, temperature, and operational conditions affect the remaining capacity of a battery. Because of this the battery capacity indicator is intended to be for reference purposes only.

  • Page 34: Turning Power On And Off

    Turning Power On and Off To turn power on and off OPERATE INPUT – VOLUME OPERATE /DVD TITLE FUNCTION SHIFT MENU ENTER SETUP VIDEO ADJ. RETURN Press ZOOM PROGRAM DISPLAY VIEW MODE OPERATE. LCD ON/OFF DVD VIDEO PLAYER POWER (G)/ OPERATE CHARGE (R) lamp For the U.K.

  • Page 35: Using The Remote Control

    Using the Remote Control Installing the battery in the Remote Holding the release tab to the Place a lithium battery into the left, slide the battery holder from battery holder and slide the the Remote with your fingernail battery holder back into place. catching the slit.
  • Page 36 • Should the lithium battery leak, wipe the battery compartment and holder clean, and then insert a new battery. • The lithium battery will last about six months to one year of normal usage. • Purchase the Remote’s replaceable lithium battery from your Sharp autho- rized service centre.

  • Page 37: Switching Operation Buttons To Select/Enter Buttons

    Switching Operation Buttons to Select/Enter Buttons You can use the operation buttons to select options and to enter the currently selected option on a menu screen or Function control screen. Each press of SHIFT cycles the button function. Screen type and button functions Each press of SHIFT cycles the button functions as shown below.
  • Page 38 Switching Operation Buttons to Select/Enter Buttons I Button Functions Operation Select/Enter Number input buttons buttons buttons Playback Enter Enter " Move down " Move down Stop ' Move up ' Move up Still/Pause | Move right Skip forward – \ Move left Skip back –...

  • Page 39: Operation Modes

    Operation Modes Your Player has two operation modes. Select the one that suits the operation you want to perform. • DVD mode for disc playback • INPUT mode for input from external equipment INPUT OPERATE /DVD – VOLUME TITLE FUNCTION SHIFT MENU ENTER...

  • Page 40: Setup

    Setup INPUT – VOLUME OPERATE /DVD TITLE FUNCTION SHIFT MENU ENTER SETUP VIDEO ADJ. RETURN ZOOM PROGRAM DISPLAY VIEW MODE LCD ON/OFF DVD VIDEO PLAYER Initial setup (OSD LANGUAGE SETUP) When you use the Player for the first time, you should set the language to be used for the OSD (On Screen Display).

  • Page 41: Tv Mode Setup Setting

    Setup TV MODE SETUP setting The following describes how to select the DVD playback display format. Viewing on the Player Screen or a Wide Screen TV Using a 16:9 Wide Image Select for wide DVD video output. 16 : 9 •...
  • Page 42 Setup INPUT – VOLUME OPERATE /DVD TITLE FUNCTION SHIFT MENU ENTER SETUP VIDEO ADJ. RETURN ZOOM PROGRAM DISPLAY VIEW MODE LCD ON/OFF DVD VIDEO PLAYER Setting the TV MODE While a disc is stopped, press SETUP to display the Setup screen. Use ' or "...

  • Page 43: Parental Setup Setting

    Setup PARENTAL SETUP setting Parental level Certain discs come preset with country codes and parental level settings that are defined for particular countries. Discs equipped with the parental lock function are rated according to their content. The rated content allowed by a parental lock level and the way a DVD can be controlled may vary from disc to disc.

  • Page 44: Country Codes

    Setup Country Codes This Player supports country codes for the following countries. Country Code List SWEDEN MALAYSIA CANADA HOLLAND INDONESIA JAPAN NORWAY TAIWAN GERMANY DENMARK PHILIPPINE FRANCE FINLAND AUSTRALIA BELGIUM RUSSIA HONG KONG CHINA ITALY SPAIN SINGAPORE – SWISS THAILAND –...
  • Page 45 Setup While a disc is stopped, press SETUP to display the Setup screen. Use ' or " to select the “ PARENTAL SETUP”. Press ENTER to display the password PARENTAL SETUP specification screen. PASSWORD: ???? CODE: Use ', ", \ or | to enter a 4-digit password. •...
  • Page 46 Setup Press " to select “CODE” and then use \ or | to select the desired country code. (See page 43.) Press ENTER to confirm the setting. • To exit the Setup screen and return to the Startup screen, press SETUP or RETURN.
  • Page 47 Setup Temporary parental level setting Some DVDs will prompt the viewer to temporarily change the parental level. In this event, the following screen appears. PARENTAL SETUP TEMPORARY CHANGE? When this screen appears, use the procedure described below to temporarily change the level. Use ' or "...

  • Page 48: Audio Setup Setting

    Setup AUDIO SETUP setting COMPRESSION ..Use this setting for increasing the average volume of Dolby Digital audio when playing a DVD. DIGITAL/MPEG ..Use these settings for specifying the type of digital output when playing a disc recorded using Dolby Digital/MPEG Audio.
  • Page 49 Setup • Use of the “OFF” setting is recommended when the Player is connected to audio equipment. • VIRTUAL DOLBY (QSURROUND) is disabled when “COMPRESSION” is set to “ON”. INPUT – VOLUME OPERATE /DVD TITLE FUNCTION SHIFT MENU ENTER SETUP VIDEO ADJ.
  • Page 50 Setup Setting the DIGITAL OUT When playing a disc recorded using Dolby Digital (5.1ch)/MPEG Audio (5.1ch), you can specify either “BITSTREAM” or “D-PCM”/“PCM” as the digital type output. Setting the DOLBY DIGITAL • At first, set the “SPEAKER” setting in “SPEAKER SETUP” to “2ch”. (See page 56.) While a disc is stopped, press SETUP to display the Setup screen.
  • Page 51 Setup Setting the MPEG • At first, set the “SPEAKER” setting in “SPEAKER SETUP” to “2ch”. (See page 56.) While a disc is stopped, press SETUP to display the Setup screen. Use ' or " to select the “ AUDIO SETUP”. Press ENTER and then use ' or "...
  • Page 52 Setup Setting the PRO LOGIC • At first, set the “SPEAKER” setting in “SPEAKER SETUP” to “5ch” or “5.1ch”. (See page 56.) While a disc is stopped, press SETUP to display the Setup screen. Use ' or " to select the “ AUDIO SETUP”.

  • Page 53: Disc Language Setting

    Setup INPUT – VOLUME OPERATE /DVD TITLE FUNCTION SHIFT MENU ENTER SETUP VIDEO ADJ. RETURN ZOOM PROGRAM DISPLAY VIEW MODE LCD ON/OFF DVD VIDEO PLAYER DISC LANGUAGE setting Use this setting for selecting languages of subtitle, audio track and disc menu. •...
  • Page 54 Setup Select the language you want to use with (Example) Selecting ', ", \ or |. “FRENCH” • If you want to use any languages DISC LANGUAGE which are not on OSD, proceed to step SUB TITLE:ENGLISH ENGLISH CHINESE 1 under “Selecting a language from FRENCH SWEDISH OTHER”...

  • Page 55: Language Code List For Disc Language

    Setup Language code list for Disc Language Code Language Name Code Language Name Code Language Name Code Language Name Afar Frisian Malagasy Slovenian Abkhazian Irish Maori Samoan Afrikaans Scots Gaelic Macedonian Shona Ameharic Galician Malayalam Somali Arabic Guarani Mongolian Albanian Assamese Gujarati Moldavian...

  • Page 56: Osd Language Setup Setting

    Setup INPUT – VOLUME OPERATE /DVD TITLE FUNCTION SHIFT MENU ENTER SETUP VIDEO ADJ. RETURN ZOOM PROGRAM DISPLAY VIEW MODE LCD ON/OFF DVD VIDEO PLAYER OSD LANGUAGE SETUP setting While a disc is stopped, press SETUP to display the Setup screen. Use ' or "...

  • Page 57: Speaker Setup Setting

    Setup SPEAKER SETUP setting SPEAKER ..sets the speaker system to listen to Dolby Digital, or simulated surround sound. DELAY ..sets delay time of the sound from each side and from front and back so that the sound is perfectly in phase when it reaches you. Setting the SPEAKER Using 6 Speakers •...
  • Page 58 Setup INPUT – VOLUME OPERATE /DVD TITLE FUNCTION SHIFT MENU ENTER SETUP VIDEO ADJ. RETURN ZOOM PROGRAM DISPLAY VIEW MODE LCD ON/OFF DVD VIDEO PLAYER While a disc is stopped, press SETUP to display the Setup screen. Use ' or " to select the “ SPEAKER SETUP”.
  • Page 59 Setup Setting the DELAY (speaker delay time) • For the best possible surround sound, you need to specify the distance from your usual listening position to each of the connected speakers. This ensures that the sound from each side and from front and back is perfectly in phase when it reaches you, providing the optimum surround sound experience.
  • Page 60 Setup Press ENTER to confirm the setting. • To exit the Setup screen and return to the Startup screen, press SETUP or RETURN. Delay time settings • The delay time settings are determined in accordance with the Dolby standards. You cannot specify values in which the difference between the distances for the front and centre speakers exceeds 1.7 m (5 ms).

  • Page 61: Screen Size Setting

    Screen Size Setting When viewing a DVD on your Player screen, you select the screen size that best suits the image you are viewing. To set the screen size Software Type Wide 4:3 Letter Box Mode Image is stretched Image is stretched by its SMART Full Screen by its four corners.
  • Page 62 Screen Size Setting INPUT – VOLUME OPERATE /DVD TITLE FUNCTION SHIFT MENU ENTER SETUP VIDEO ADJ. RETURN ZOOM PROGRAM DISPLAY VIEW MODE LCD ON/OFF DVD VIDEO PLAYER Press VIEW MODE. T R E T C H • Each press of VIEW MODE cycles through the screen size settings in the following sequence: STRETCH →...

  • Page 63: Changing The Display Mode

    Changing the Display Mode To change the display mode Press DISPLAY. INPUT • Each press of DISPLAY cycles through the – VOLUME OPERATE /DVD display mode settings in the following sequence: on → off → auto → on. TITLE FUNCTION SHIFT auto ..

  • Page 64: Dvd Mode Operation Indicators

    Changing the Display Mode DVD mode operation indicators The following are examples of display indicators that appear during DVD playback. Player Status Display Indicators Play attempted without a disc NO DISC ‰1:23:4‰ Play attempted with a non-compatible WRONG DISC TYPE disc Loading (data being read from disc) NOW LOADING...

  • Page 65: Playing A Disc

    Playing a Disc This Player can play a DVD, DVD-RW, VIDEO CD, or Audio CD using the procedure described below. INPUT – VOLUME OPERATE /DVD TITLE FUNCTION SHIFT MENU ENTER SETUP VIDEO ADJ. RETURN ZOOM PROGRAM DISPLAY VIEW MODE LCD ON/OFF DVD VIDEO PLAYER VIDEO VIDEO...

  • Page 66: To Play A Disc

    Playing a Disc Close the disc compartment cover and press down at the corner marked “PUSH TO CLOSE” so it locks securely into place. PUSH TO CLOSE Important! • Make sure the disc seats securely when you load it into the Player. An improperly seated disc can result in damage to the disc and malfunction of the Player.

  • Page 67: To Adjust The Volume Level

    Playing a Disc Important! • Do not press down on the disc compartment cover while a disc is playing. • Keep the disc compartment cover closed except when loading or removing a disc. Otherwise, dust getting into the Player can lead to malfunction.

  • Page 68: Gb 2 To Remove The Disc From The Player

    Playing a Disc To remove the disc from the Player Press îOPEN to open the cover. Carefully remove the disc from the Player. • Take care so you do not touch the disc surface with your fingers. As shown in the illustration, place your index finger into the centre hole of the disc and lift up the edge of the disc with your thumb.

  • Page 69: Playing Back A Dvd-Rw Disc

    Playing a Disc INPUT – VOLUME OPERATE /DVD TITLE FUNCTION SHIFT MENU ENTER SETUP VIDEO ADJ. RETURN ZOOM PROGRAM DISPLAY VIEW MODE LCD ON/OFF DVD VIDEO PLAYER DVD-RW DVD-RW Playing back a DVD-RW disc You can use the following procedure to recall header information when playing back a DVD-RW disc that has original titles and a play list recorded on it.
  • Page 70 Playing a Disc • Loading a disc and closing the disc compartment cover starts playback automatically, and displays the DVD-RW menu. • Pressing MENU or TITLE during playback displays the DVD-RW menu. • To exit the title selection screen, press RETURN. This returns to the previous screen.

  • Page 71: Other Disc Play Features

    Other Disc Play Features This section explains how to use skip, resume, slow motion, and other play features. INPUT – VOLUME OPERATE /DVD TITLE FUNCTION SHIFT MENU ENTER SETUP VIDEO ADJ. RETURN ZOOM PROGRAM DISPLAY VIEW MODE LCD ON/OFF DVD VIDEO PLAYER DVD-RW DVD-RW Chapter skip...

  • Page 72: To Resume Disc Play After Stopping

    Other Disc Play Features INPUT – VOLUME OPERATE /DVD TITLE FUNCTION SHIFT MENU ENTER SETUP VIDEO ADJ. RETURN ZOOM PROGRAM DISPLAY VIEW MODE LCD ON/OFF DVD VIDEO PLAYER To resume disc play after stopping While the disc is playing, press Ë (STOP) at the location where you want to stop.

  • Page 73: Slow-Motion Play

    Other Disc Play Features INPUT – VOLUME OPERATE /DVD TITLE FUNCTION SHIFT MENU ENTER SETUP VIDEO ADJ. RETURN ZOOM PROGRAM DISPLAY VIEW MODE LCD ON/OFF DVD VIDEO PLAYER VIDEO VIDEO DVD-RW DVD-RW Slow-motion play While a disc is playing, press (SLOW).

  • Page 74: Fast Forward/Fast Reverse

    Other Disc Play Features To cancel still picture and return to normal play, press û (PLAY). • You may not be able to use still picture and frame advance with some discs. • Frame advance cannot be used with Audio CDs. •...

  • Page 75: Using The Function Control

    Using the Function Control About the Function control screen Using Function control, you can check at a glance and change the current settings of the following items: SUBTITLE, ANGLE, AUDIO, VIRTUAL DOLBY, DIGITAL GAMMA and DIGITAL SUPER PICTURE. Function control also allows you three ways of direct skips (title,chapter and time).
  • Page 76 Using the Function Control Direct chapter skip • The number of the chapter currently played back is displayed. • You can skip directly to the desired chapter. Direct time skip • Elapsed time from the beginning of the disc is displayed. •...

  • Page 77: Direct Title/Track Skip

    Using the Function Control VIDEO VIDEO DVD-RW DVD-RW Direct title/track skip INPUT – VOLUME OPERATE /DVD TITLE FUNCTION SHIFT MENU ENTER SETUP VIDEO ADJ. RETURN ZOOM PROGRAM DISPLAY VIEW MODE LCD ON/OFF DVD VIDEO PLAYER Press FUNCTION during playback. • The Function control screen appears. 8/3‰...

  • Page 78: Direct Chapter Skip

    Using the Function Control • The number of titles or tracks you can input depends on that of the titles or tracks recorded on a disc you play. • The Direct title skip function does not operate on discs on which no titles are recorded.

  • Page 79: Direct Time Skip

    Using the Function Control VIDEO VIDEO DVD-RW DVD-RW Direct time skip Use the following procedure to perform the Direct time skip. Press FUNCTION during playback. • The Function control screen appears. Use ' or " to select and then press ENTER.

  • Page 80: Subtitle Language Setting

    Using the Function Control Subtitle language setting Use the following procedure to perform the Subtitle language setting. Press FUNCTION during playback. • The Function control screen appears. Use ' or " to select and then press ENTER. 2 ENGLISH Press ' or " to select the subtitle language you want to use.

  • Page 81: Angle Setting

    Using the Function Control Angle setting You can change the angle of view when playing a DVD video disc that contains scenes recorded from multiple angles. Use the following procedure to perform the Angle setting. Press FUNCTION during playback. • The Function control screen appears. Use ' or "...

  • Page 82: Audio Setting

    Using the Function Control VIDEO VIDEO DVD-RW DVD-RW Audio setting A number of different methods are used to record audio onto a DVD video disc, including multi-channels (used for voiceovers in other languages), Dolby Digital (5.1ch), DTS, and linear PCM. Your Player provides a number of different audio modes from which you can choose to suit the type of disc you are playing.

  • Page 83: Virtual Dolby (Qsurround) Setting

    Using the Function Control DVD-RW DVD-RW VIRTUAL DOLBY (QSURROUND) setting This function allows you to enjoy a “surround sound” effect when you are using an analogue connection (using AUDIO OUT on the Player) to 2-channel audio equipment (TV, etc.). Preparation: To use the VIRTUAL DOLBY (QSURROUND) function •...
  • Page 84 Using the Function Control Press ' or " to toggle VIRTUAL DOLBY between “ON” and “OFF”. While “ON” is selected, use \ or | to change the level setting. Press ENTER to confirm the setting. • You can exit the Function control screen by pressing FUNCTION or RETURN.

  • Page 85: Digital Gamma Setting

    Using the Function Control VIDEO VIDEO DVD-RW DVD-RW DIGITAL GAMMA setting DIGITAL GAMMA is a digital image quality enhancement function that gives a richer image by brightening the darker and more obscure portions of the image without altering the brightness of the brighter portions, thereby making the entire image easier to see.

  • Page 86: Digital Super Picture Setting

    Using the Function Control VIDEO VIDEO DVD-RW DVD-RW DIGITAL SUPER PICTURE setting DIGITAL SUPER PICTURE is a digital image quality enhancement function that gives a clearer image by sharpening the details and outlines in the image and reducing the amount of picture noise. Use the following procedure to change the setting between “ON”...

  • Page 87: Zoom Function

    Zoom Function To zoom an image While a disc is playing, press ZOOM. • Each press of ZOOM cycles through ZOOM the zoom settings in the following sequence: ZOOM 1 (1.2×) → ZOOM 2 (1.5×) → ZOOM 3 (2.0×) → Off. ZOOM indicator Note that all of the above zoom factors are approximate only.

  • Page 88: Repeat Playback

    Repeat Playback INPUT – VOLUME OPERATE /DVD TITLE FUNCTION SHIFT MENU ENTER SETUP VIDEO ADJ. RETURN ZOOM PROGRAM DISPLAY VIEW MODE LCD ON/OFF DVD VIDEO PLAYER DVD-RW DVD-RW Chapter repeat Example: To repeat play the chapter you are currently viewing Play the chapter you want to repeat.

  • Page 89: Track/Disc Repeat

    Repeat Playback VIDEO VIDEO Track/Disc repeat Example: To repeat play a disc While a disc is playing, press (REPEAT) twice and then press û (PLAY) to start repeat play. • To cancel repeat play, press (REPEAT) again. This clears the “...

  • Page 90: Programmed Playback

    Programmed Playback You can program your Player to play titles, tracks, or chapters in the sequence you want. INPUT – VOLUME OPERATE /DVD TITLE FUNCTION SHIFT MENU ENTER SETUP VIDEO ADJ. RETURN ZOOM PROGRAM DISPLAY VIEW MODE LCD ON/OFF DVD VIDEO PLAYER Title programmed playback This function can be used only with a disc that has been played once, even partially.
  • Page 91 Programmed Playback Press ENTER to start play in the sequence PROGRAM you specified. • Titles are played in the sequence you specified. • Press RETURN if you want to exit the above screens. • You cannot program the play sequence while a disc is playing. •...

  • Page 92: Chapter Programmed Playback

    Programmed Playback INPUT – VOLUME OPERATE /DVD TITLE FUNCTION SHIFT MENU ENTER SETUP VIDEO ADJ. RETURN ZOOM PROGRAM DISPLAY VIEW MODE LCD ON/OFF DVD VIDEO PLAYER If you have a DVD that includes chapter data, you can program your Player to play chapters in the sequence you want.
  • Page 93 Programmed Playback Use ' and " to cycle through numbers at CHAPTER PROGRAM the currently selected (highlighted) =TITLE: 12 =CHAPTER position, and then press | to move the ‰ highlighting to the right. For example, to play the 15th chapters CHAPTER PROGRAM first: =TITLE: 12...

  • Page 94: Track Programmed Playback

    Programmed Playback INPUT – VOLUME OPERATE /DVD TITLE FUNCTION SHIFT MENU ENTER SETUP VIDEO ADJ. RETURN ZOOM PROGRAM DISPLAY VIEW MODE LCD ON/OFF DVD VIDEO PLAYER VIDEO VIDEO Track programmed playback This function can be used only with a disc that has been played once, even partially.
  • Page 95 Programmed Playback Press ENTER to start play in the sequence PROGRAM you specified. • Tracks are played in the sequence you specified. • Press RETURN if you want to exit the above screens. • You cannot program the play sequence while a disc is playing. •...

  • Page 96: Selecting Titles From The Title Menu

    Selecting Titles from the Title Menu Some DVDs have a title menu that you use to select the title you want to play. INPUT – VOLUME OPERATE /DVD TITLE FUNCTION SHIFT MENU ENTER SETUP VIDEO ADJ. RETURN ZOOM PROGRAM DISPLAY VIEW MODE LCD ON/OFF DVD VIDEO PLAYER To select a title from the title menu...

  • Page 97: Setting Play Parameters Using The Disc Menu

    Setting Play Parameters Using the Disc Menu Some DVDs include a disc menu that you can use to select subtitle set, audio channel, and Dolby Digital (5.1 channel) or DTS audio. You can also turn disc menu on and off. INPUT –...

  • Page 98: Adjusting Display

    Adjusting Display Use the procedures described here to adjust the brightness and contrast of the colours that appear on the display, and the overall brightness of the display. INPUT – VOLUME OPERATE /DVD TITLE FUNCTION SHIFT MENU ENTER SETUP VIDEO ADJ. RETURN ZOOM PROGRAM DISPLAY VIEW MODE...

  • Page 99: Viewing Images From An External Equipment

    Viewing Images from an External Equipment Use the following procedure to set up the Player for use as a monitor for viewing images from a VCR or camcorder. INPUT – VOLUME OPERATE /DVD TITLE FUNCTION SHIFT MENU ENTER SETUP VIDEO ADJ. RETURN ZOOM PROGRAM DISPLAY VIEW MODE...

  • Page 100: References

    References Precautions Use & Care • After operation, remove the battery pack from the Player. • Avoid magnetic sources. Using the Player near strong fluorescent lights, motors, televisions, or other magnetic sources may adversely affect recorded images. • Remember to remove the disc, turn off the power when the Player is not in use.
  • Page 101 As a general rule, the life of the fluorescent tube is about 10,000 hours of continuous use under normal temperatures. If the display appears dark, if it flickers, or if it fails to light, contact your original retailer or your nearest Sharp service centre for replacement.

  • Page 102: Ac Adapter

    • Avoid using the adapter in humid or extremely hot places. • If the AC adapter is misplaced or needs to be replaced, obtain the same type of adapter from a Sharp service centre or your dealer. Care Cleaning and Maintenance •...
  • Page 103 References Warning! 1. Never drop the battery pack or otherwise subject it to strong impact. 2. Use and store the battery pack in areas that is out of the reach of small children. 3. Never place the battery pack inside a microwave oven or a washing machine. 4.

  • Page 104: Troubleshooting

    Troubleshooting Whenever you are having problems with your Player, check the following points before requesting service. Problem Recommended Action Page Power does not • Make sure the power plug of the AC adapter is turn on or plugged into a power outlet. suddenly turns off.
  • Page 105 Troubleshooting Problem Recommended Action Page Nothing appears • Make sure the “PICTURE” setting of “VIDEO on the screen. ADJUST” is not set to “0”. • Make sure LCD display is turned on. • Make sure the display panel is open. Audio is No audio is output.
  • Page 106 Troubleshooting Problem Recommended Action Page No image from • Make sure the channel of the connected TV is the Player set to VIDEO or AV. appears on the • Make sure video and audio cables are screen of a connected correctly. connected device.
  • Page 107 Troubleshooting Problem Recommended Action Page POWER (G)/ • Try disconnecting the AC adapter DC cord from – CHARGE (R) the battery pack and then reconnecting it. If the lamp is battery pack is attached to the Player, first flashing red at disconnect the battery pack DC cord from the high speed.

  • Page 108: Error Indicators And Warnings

    Error Indicators and Warnings The error indicators and warnings described below appear on the display whenever there is a disc play problem, operational problem, etc. Display Meaning • The disc you are attempting to play is not compatible with this WRONG DISC TYPE Player.

  • Page 109: Specifications

    Specifications Product Portable DVD Video Player Model DV-L80S Signal System NTSC/PAL Supported Disc Types DVD (Region Number 2, ALL), DVD-RW (Video recording format), VIDEO CD, Audio CD Video Input/Output Input/Output Jack: Mini jack × 1 (accepts supplied S-video/video cable) Input/Output Levels: 1Vp-p (75Ω) S-Video Output Y Output Level: 1Vp-p (75Ω)
  • Page 110 Specifications Dimensions 211 (W) × 157 (D) × 24.7 (H) mm (except for projections) Weight (approx.) 840g Operating Temperature 5°C to 35°C Operating Humidity 80% RH maximum Storage Temperature –20°C to 40°C AC Adapter Specifications Power Requirements 110 to 240V AC, 50/60Hz Rated Input Capacity DVD Operation: 55VA Charging (110V): 55VA Rated Output DVD Operation: 10V DC...

  • Page 111: Glossary

    Glossary Region number Number identifying a geographic region of compatibility for a DVD. The list below shows the countries covered by region number 2. Common Names Names of Nations and Areas Common Names Names of Nations and Areas Albania Republic of Albania Monaco Principality of Monaco Andorra...
  • Page 112 Glossary Pickup Laser device that reads the data from a disc for playback. Title When a DVD contains multiple movies, each movie is called a “title”. Chapter A section inside a title. Track One tune on an Audio CD. DVD mode The Player mode for playing DVDs.
  • Page 113 Glossary DELAY Time This refers to the delay time resulting from the positioning of the speakers, and is the setting used to compensate for the differences in the distances from the different speakers (front, centre and surround (rear)) to the listening position. Screen size This setting makes it possible to fit an image onto the screen by cutting off the top and bottom, cutting off the...

Table of Contents
