6.
Insert the dipstick all the way back
into the transmission securely as
shown in the illustration.
The automatic transmission should
be drained and refilled with new fluid
when this service is indicated by a
maintenance message on the
information display.
If you are not sure how to add fluid,
contact your dealer.
Table of Contents
Automatic Transmission Fluid, Manual Transmission Fluid
Manual Transmission Fluid
FILLER BOLT
Except U.S. Si
Check the fluid level with the
transmission at normal operating
temperature and the vehicle sitting
on level ground. Remove the
transmission filler bolt, and carefully
feel inside the bolt hole with your
finger. The fluid level should be up
to the edge of the bolt hole. If it is
not, add Honda Manual
Transmission Fluid (MTF) until it
starts to run out of the hole. Reinstall
the filler bolt, and tighten it securely.
FILLER BOLT
Correct Level
U.S. Si
If Honda MTF is not available, you
may use an SAE 10W-30 or 10W-40
viscosity motor oil with the API
Certification seal that says ''FOR
GASOLINE ENGINES'' as a
temporary replacement. However,
motor oil does not contain the proper
additives, and continued use can
cause stiffer shifting. Replace as
soon as it is convenient.
Correct Level
CONTINUED
233
