Grizzly H8097 Operating And Maintenance Manual

Specifications

Maximum Lifting Capacity .....................4000 lbs.
Lifting Range ..........................................4"–17
Weight .......................................................38 lbs.
Machine
Label
Saddle
Figure 1. Model H8097 Identification.
Operation
To raise the saddle:
Turn the handle clockwise as far as it will turn
and pump the handle up and down. Turning the
handle clockwise will close the release valve.
To lower the saddle:
Slowly turn the jack handle counterclockwise.
WARNING: NO PORTION OF THIS MANUAL MAY BE REPRODUCED IN ANY SHAPE
OR FORM WITHOUT THE WRITTEN APPROVAL OF GRIZZLY INDUSTRIAL, INC.
1
Jack Handle
COPYRIGHT © DECEMBER, 2006 BY GRIZZLY INDUSTRIAL, INC.
#JC8828 PRINTED IN CHINA
MODEL H8097
Aluminum Jack
⁄ "
Failure to follow these instructions could
4
result in serious personal injury or death:
1. DO NOT overload this jack beyond its
rated capacity. Overloading can cause
the jack to collapse and drop the load.
2. ALWAYS support the vehicle with
appropriately rated support stands
before working under it.
3. DO NOT attempt to move the vehicle
while the jack is in use.
4. Use only on hard level surfaces like
concrete or asphalt. Other surfaces are
potentially unstable.
5. Center the load on the jack to maintain
proper balance and stability.
6. DO NOT use jack if it begins leaking
fluid or if it sinks when placed under
load. These are indications that the jack
needs to be immediately serviced.
If you need help with the Model H8097, call our
Technical Support line at: (570) 546-9663.
2 Ton
