Details screens are available for a variety of things besides equipment, too. The Equipment Details
screen (and others) can have the following sub-panels:
•

Performance Indicators

• Interfaces
• Top Configuration Backups (see Top Configuration Backups on page 277)
• Alarms
• Ports
• Details
You can also right-click to open further Details screens about some subcomponents like Interfaces
and Ports. These display a Reference Tree (like Snap Panels (Reference Tree) on page 85) too. You
can even right-click nodes in that reference tree to drill down to additional details.
Tip
Notice the breadcrumb trail at the top of the Equipment Detail panel tracks the levels through which you
drill down. You can click a level that appears in this trail to return to a previous screen. If you click Return
to previous in the upper right corner of the screen, you will return to the original screen from which you
selected the basic equipment.
Some fields may be truncated onscreen. Workaround: hover the cursor over the truncated field so
the text appears as a tooltip or drill down to see the detail.
Performance Indicators
These gauges display CPU and Memory Utilization. The
numbers indicate percentage of capacity. These rely on
Flash.
