- Page 1 SR13 Cable Management Kit 1. Place a clip-nut in an appropriate position on the enclosure mounting angle. 2. Attach the bracket #4 to a mounting angle using screw #3 and spacer #2. 3. Thread the hook & loop strip #5 through the bracket #4.
- Page 2 SR13 Required Tools: Phillips drive screwdriver Fasteners That Are Required: black nylon spacer #10-32 x 5/8” Phillips Pan Head Screw w/Nylon Washer Parts List Item Description Qty. 10-32 x 5/8 screw Nylon Spacer 10-32 Clip-Nut Bracket #10-32 Clip Nut Hook & loop strip Bracket Hook &...
