Sanyo PLC-WXU30 Command List

PLC-WXU30 IR Command List
□ Transmission format of LCD projector operation key
: NEC Format (single command / command pipelining mode)
□ Transmission format of PC mouse operation button (mouse cursor button) / L / R key
: Interlink Mouse Code Format (Includes 3 bit of ID)
□ Format for the transmission of OSD Laser operation button (mouse cursor button)
: Interlink OSD Mouse Code Format (Includes 3 bit of ID)
□ Custom Code + Custom Code
: 8 patterns as below
33h+00h(Default; code1), 33h+11h(code2), 33h+22h(code3), 33h+33h(code4),
33h+44h(code5), 33h+55h(code6), 33h+66h(code7), 33h+77h(code8)
Key
No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
OB1
*1･･･ Transmit code for Mouse *2･･･ Transmit code to set Laser Pointer / OSD Laser to
ON/OFF
Data Code
(HEX)
*1 L-CLICK ※ Back-side Click Trigger Key
00 ON-OFF
38 COMPUTER
05 VIDEO
08 NETWORK
89 AUTO PC
5B KEYSTONE
17 AUTO SET
8C CURSOR UP
1E CURSOR LEFT/VOLUME -
1D CURSOR RIGHT/VOLUME +
8D CURSOR DOWN
1C MENU
0F SELECT
*1 R-CLICK
43 FREEZE
84/85 *2 LASER
8B NO SHOW
59 PAGE +
01 D.ZOOM +
8A P-TIMER
5A PAGE -
02 D.ZOOM -
0B MUTE
18 LAMP CONTROL
0C IMAGE
*1 MOUSE CURSOR BUTTON
2008/1/9
Function
1/1
