Summary of Contents for Panasonic PT-AE7000U
- Page 1 PT AE7000 P ro d u c t N u m b e r : Full High-Definition Home Cinema Projector P ro d u c t N a m e : As of September 2011. Specifications and appearance are subject to change without notice. 1 / 1 3 SFL11M007...
- Page 4 231 (9-1/8) (3-3/4) 470 (18-17/32)
- Page 5 Upper edge of projected image Projected image (8-1/32) Lower edge of projected image 65 (2-9/16) Projected image Projection size (16:9) Projection distance (L) Height from the edge of screen Width from the right edge of screen to center of lens to center of lens Diagonal length Min (Wide)
- Page 6 Projection size (16:9) Projection distance (L) Height from the edge of screen Width from the right edge of screen to center of lens to center of lens Diagonal length Min (Wide) Max (Telephoto) 1.0 2 m 4 0 ˝ 1. 2 3 m 4´0 ˝...
- Page 7 (Width of projected image) 0.26H 0.26H Standard position of projected image...
- Page 8 Compatible signal Display mode Display Scanning frequency Dot clock Format Plug-and- resolution frequency play HDMI (dots) (kHz) (kHz) (MHz) NTSC/NTSC4.43/PAL-M/PAL60 720 × 480i 15.7 59.9 VIDEO/S-VIDEO – PAL/PAL-N/SECAM 720 × 576i 15.6 50.0 – 525i (480i) 480i 720 × 480i 15.7 59.9 13.5...
- Page 9 Mode Format of 3D video signals Frame packing Side by side Top and bottom 750 (720)/60p 750 (720)/50p (Yes) 1125 (1080)/60i – – 1125 (1080)/50i – – 1125 (1080)/24p 1125 (1080)/60p – – 1125 (1080)/50p – (Yes) –...
- Page 10 C1 C2 C3 P1 P2 ... Pn Start Colon (1 byte) (1 byte) (1 byte) Parameters Command (undefined length) (3 bytes) (Control and/or query commands) Projector PC (DTE)
- Page 11 Command Parameter Function Standby power on – Standby power off – Input signal selection CP1, SVD, VID, HD1, HD2, HD3, RG1 Menu – Enter – Return – Cursor up – Cursor down – Cursor left – Cursor right – The same function as “LENS” button –...
- Page 12 Command Description Parameter Standby power status 000 = off, 001 = on Input signal status CP1 = component, SVD = S-video, VID = video, HD1 = HDMI1, HD2 = HDMI2, HD3 = HDMI3, RG1 = computer Picture mode status NOR = normal, DYN = dynamic, 709 = Rec. 709, DCN = D-cinema, CN1 = cinema 1, CN2 = cinema 2, GM1 = game Blank function status...
- Page 13 100 mm ( 3-15/16 ˝ ) 100 mm ( 3-15/16 ˝ ) 100 mm ( 3-15/16 ˝ ) or more or more or more...
