Hitachi CMPAK345 Installation Instructions Manual

Hitachi Plasma Screen Tilting Wall-mount Unit
Model
CMPAK345
Thank you for purchasing the Hitachi Plasma Screen Wall-mount Unit.
To ensure correct usage, please read this instruction manual thoroughly. After reading, please store this
manual in a safe place for future reference.
This plasma screen wall-mount unit is for use only with the following models:
HITACHI Plasma Screens: CMP307XE, CMP4121, CMP42PMA400E, CMP4202E, CL42PD2100,
SUPPORTING VISION LTD
Manufactured in the UK
E-mail: info@supporting-vision.com
MOUNTING INSTRUCTIONS
Wall Bracket for HITACHI Plasma Screen Models: CMP307XE, CMP4121,
CMP42PMS400E, CMP4202E, CL42PD2100, 42PD3000, CMP5000WXE.
CONSULT AUTHORIZED SERVICE PERSONNEL FOR THE INSTALLATION OF THIS UNIT.
INSTRUCTIONS MUST BE FOLLOWED PRECISELY FOR SAFE AND STABLE INSTALLATION.
SUPPORTING VISION LTD ARE NOT LIABLE FOR ANY DAMAGE OR INJURY CAUSED BY
MISHANDLING OR IMPROPER INSTALLATION.
Features
• Suspension system allows quick and easy
installation.
• Flat Installation – 22mm distance, wall to rear of
Plasma display
• Tilt – 0 to 10 degrees.
• Width adjustment – 30mm side to side screen
movement.
• Cable access – Pull bottom of screen away from
wall for Plasma connection access.
• Security bolt – Prevents removal of screen after
installation.
INSTALLATION
Installation of this unit should be carried out by
qualified technicians. Install in an appropriate
location only after checking wall structure and
durability for accident prevention. Consult a
qualified builder if in any doubt of wall structural
.
integrity
42PD3000 & CMP5000WXE.
TEL: 0845 6023109
Installation Instructions
FAX: 01283 792300
List of Components
